EN 10088 1.4404 / 316L / AISI316 Stainless Steel Bar / Stainless
Steel 316L Round Rod in 6m Length
| Products | Stainless Steel Bar |
| Grade | 321 |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade | 201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
About 316L Stainless Steel
Grade 316L is very similar to 316 stainless steel. It is still
considered a molybdenum-bearing grade and has properties that make
it highly resistant to corrosive degradation. 316L grade stainless
steel differs from 316 in that contain lower levels of carbon. The
decreased level of carbon in this stainless steel makes this grade
immune from sensitisation or grain boundary carbide precipitation.
Because of this unique property, Grade 316L tends to be commonly
used in heavy gauge welding situations. Additionally, the lower
carbon levels make this grade easier to machine. Like 316 stainless
steel, 316L because of its austenitic structure is extremely tough,
even in the most extreme of temperatures.
Composition of 316L Stainless Steel
Table 1. Composition ranges for 316L stainless steel.
| Grade | | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|
| 316L | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 |
Mechanical Properties of 316L Stainless Steel Bar
Table 2. Mechanical properties of 316L stainless steel.
| Grade | Tensile Str (MPa) min | Yield Str 0.2% Proof (MPa) min | Elong (% in 50 mm) min | Hardness |
|---|
| Rockwell B (HR B) max | Brinell (HB) max |
|---|
| 316L | 485 | 170 | 40 | 95 | 217 |
Features of 316L Stainless Steel
- 316L Stainless Steel is easily welded by all commercial processes.
If forging or hammer welding it is recommended to anneal after
these processes to help avoid unwarranted corrosion.
- Not hardenable by heat treatment, however often cold working the
alloy has proven to increase hardness and tensile strength.
- Sometimes know by industry professionals as marine grade stainless
for its uncanny ability to resist pitting corrosion.
Our products of 316L Stainless Steel
316L Plate, 316L Sheet, 316L Round Bar, 316L Flat Bar, 316L Equal
Leg Angle, 316L Unequal Leg Angles, 316L Pipe Tube & Fittings, 316L
Beam, 316L Channel, 316L Hex Bar, 316L Square Bar, 316L Square
Tube, 316L Rectangular Tube
Application of 316L Stainless Steel Bar
Common uses of Stainless Steel Round Bar 316/316L include:
- Boat Fittings
- Brewery Equipment
- Chemical Transportation Containers
- Chemical & Petrochemical Equipment
- Coastal Architectural Paneling
- Coastal Balustrading
- Food Processing Equipment
- Heat Exchangers
- Medical Implants
- Mining Screens
- Nuts & Bolts
- Laboratory Benches & Equipment
- Springs
