Brand Name : | DELTA |
Model Number : | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 |
Certification : | ISO |
Price : | 2400 - 3500 USD/Ton |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 20Ton per week |
Delivery Time : | 5 - 12 days based on the quantity |
Products | Stainless Steel Bar |
Grade | 321 |
Diameter | 5 - 350mm |
Length | 6m or custom cutting any length as request |
Finishing | Bright Bar / Black Surface |
Heat Treatment | Solid Solution , ageing |
Surface Process | Polishing , Peeling |
Other Grade | 201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
MOQ | 500 Kgs |
Loading Port | Shanghai Port |
Processing | Cutting |
Packing | Wooden box or wrapping by PP bag |
321 Stainless Steel Bar / UNS S32100 (Grade 321)
321 stainless steel bar, also known as UNS S32100 and Grade 321, is primarily comprised of 17% to 19% chromium, 12% nickel, .25% to 1% silicon, 2% maximum manganese, traces of phosphorus and sulfur, 5 x (c + n) .70% titanium, with the balance being iron. With regards to corrosion resistance, 321 is equivalent to Grade 304 in the annealed condition and is superior if the application involves service in the 797° to 1652° F range. Grade 321 combines high strength, resistance to scaling and phase stability with resistance to subsequent aqueous corrosion
Chemical Properties of our 321 Stainless Steel Bar
% | Cr | Ni | C | Si | Mn | P | S | N | Ti | Fe |
---|---|---|---|---|---|---|---|---|---|---|
321 | min:17.0 max:19.0 | min: 9.0 max:12.0 | max:0.08 | max:0.75 | max:2.0 | max:0.045 | max:0.03 | max:0.10 | min:5*(C+N) max:0.70 | Balance |
321H | min:17.0 max:19.0 | min: 9.0 max:12.0 | min:0.04 max:0.10 | min:18.0 max:20.0 | max:2.0 | max:0.045 | max:0.03 | max:0.10 | min:5*(C+N) max:0.70 | Balance |
Mechanical Properties of 321 Stainless Steel Bar
Grade | Tensile Strength ksi (min.) | Yield Strength 0.2% Offset ksi (min.) | Elongation - % in 50 mm (min.) | Hardness (Brinell) MAX |
---|---|---|---|---|
321 | 75 | 30 | 40 | 217 |
Physical Properties of 321 Stainless Steel Bar
Denstiy lbm/in^3 | Coefficient of Thermal Expansion (min/in)-°F | Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)^2-psi | |
---|---|---|---|---|---|
at 68 °F | at 68 – 212°F | at 68 – 1832°F | at 200°F | at 32 – 212°F | in tension (E) |
0.286 | 9.2 | 20.5 | 9.3 | 0.12 | 28 x 10^6 |
Application of 321 Stainless Steel Bar
![]() |
