ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers

    Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers
    • Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers
    • Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers
    • Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers
    • Buy cheap ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness from wholesalers

    ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Model Number : 303
    Certification : ISO
    Price : 4000-6000 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness

    ASTM A276 Grade 303 Stainless Steel Plate AOD Annealing SS Plate UNS S30300 0.5 - 10.0mm Thickness

    Specification of SS 303 plate

    specifications
    ASTM A240 / ASME SA240, EN 10088-2
    Standard
    ASME, ASTM, DIN, BS, EN
    Thickness
    1 to 200mm
    Length
    2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
    Surface
    2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand
    blast, etc
    Origin
    China
    Technique
    Cold Rolled and Hot Rolled
    Width
    1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
    Stainless Steel Sheet Finish
    Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D
    MTC
    Available as per EN 10204 3.1, Mill Test Certificate
    Brand Name
    TISCO BAOSTEEL POSCO JISCO LISCO
    Container
    40ft HC: 12032m
    Form
    Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc.
    Price termCFR, Ex-Work, FOB, CNF, CIF
    Size
    40ft GP: 12032mm x 2352mm x 2393mm
    20ft GP: 5898mm x 2352mm x 2393mm

    Detail Size of 303 Stainless Steel Plate We have


    Grade303
    Thickness

    Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm

    Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm

    Standard Size1000*2000mm 1219*2438mm 1500*6000mm

    Alloy 303 (UNS S30300) is anaustenitic stainless steel developedfor applications requiring extensivemachining operations. The alloy hasa sulfur addition which assists inbreaking up turnings while reducingdrag on the cutting tool whencompared to the machiningcharacteristics of the conventional18-8 stainless steels.The alloy is nonmagnetic in theannealed condition, but maybecome slightly magnetic as aresult of cold working. The additionof sulfur negatively impacts thecorrosion resistance of 303 makingit less resistant than 304 to mildlycorrosive environments.

    Grade Specification

    STANDARDS – ALLOY 303

    ASTM/ASME ……………. UNS S30300

    EURONORM ……………. FeMi35Cr20Cu4Mo2

    DIN ………………………… 2.4660

    Chemical Properties:


    %CrNiCSiMnPSMoFe
    303min: 17.0
    max:19.0
    min: 8.0
    max: 10.0
    0.15
    max
    1.00
    max
    2.0
    max
    0.20
    max
    0.15 min0.75balance

    Mechanical Properties:


    GradeTensile Strength
    ksi (min.)
    Yield Strength 0.2%
    Offset ksi (min.)
    Elongation -
    % in
    50 mm (min.)
    Hardness
    (Brinell) MAX
    Hardness
    (Rockwell B) MAX
    303753035228

    APPLICATIONS

    Alloy 303 is frequently used in applications that require parts to be heavily machined. Some examples include:

    • Nuts and bolts
    • Aircraft fittings
    • Gears
    • Screws
    • Shafts
    • Electrical switchgear components
    • Bushings
