    17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19
    Certification : ISO
    Price : 2400 - 3500 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm

    17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm

    ProductsStainless Steel Bar
    Grade17-4PH
    Diameter5 - 350mm
    Length6m or custom cutting any length as request
    FinishingBright Bar / Black Surface
    Heat TreatmentSolid Solution , ageing
    Surface ProcessPolishing , Peeling
    Other Grade

    201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431

    2205 2507 904L 254SMO 416 431 440A/B/C.etc

    MOQ500 Kgs
    Loading PortShanghai Port
    ProcessingCutting
    PackingWooden box or wrapping by PP bag

    This grade of stainless steel has a typical density of 7.75kg/dm³ and can be magnetised. 17 4PH finds specific use in applications where a combination of unusually high strength and moderate corrosion resistance is a determining factor. The alloy has similar corrosion resistance characteristics when compared to 304 stainless steel.

    Chemical Composition of 17-4PH Stainless Steel

    Carbon0.07% (Max)
    Silicon1.00% (Max)
    Manganese1.00% (Max)
    Phosphorous0.040% (Max)
    Sulfur0.030% (Max)
    Chromium15%-17.5%
    Molybdenum0.50% (Max)
    Nickel3%-5%
    Copper3%-5%

    Physical Properties of 17-4PH Stainless Steel

    ConditionTensileYieldEnlongationReduction of AreaHardness
    H900190KSI170KSI10%35%35 HRC
    H1025155KSI145KSI12%45%40 HRC
    H1075145125134533-39 HRC
    H1150135105165028-37 HRC
    H1150D125105165025-33 HRC

    17-4 Stainless Steel Processing

    Achieve superior hardness from welding after heat treatment. Machining conditions differ with the firmness of the element. Different levels of strength and hardness can be achieved depending on the temperature it is heat treated at. The ASTM designation is A564 and common conditions are H900, H1025, H1075, H1150, and H1150D.

    TYPICAL APPLICATIONS

    17-4 stainless steel is known for its high strength, corrosion resistance, and toughness. Because of these traits, it is often used in the aerospace, medical, and food processing industries, as well as in construction, oil and gas, and transportation.

    Additionally, 17-4 PH stainless steel is often used in the manufacturing of gears, valves, pumps, and fasteners, as well as in the production of molds and dies. The alloy's high strength and corrosion resistance properties make it an ideal material for use in harsh and demanding environments.

    About Our company
    We are a world-class supplier ofstainless steel raw materials. Our objective is to provide all our customers, from the small machine shop to the large multi-national corporation, a supply path that continuously delivers the highest levels of service, quality and value.
