    High Temperature Resistant 310S / 1.4845 Stainless Steel Seamless Pipe SCH40 SCH80 in 6m Length

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc
    Certification : ISO
    Price : 4000-5000 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    High Temperature Resistant 310S / 1.4845 Stainless Steel Seamless Pipe SCH40 SCH80 in 6m Length

    High Temperature Resistant 310S / 1.4845 Stainless Steel Seamless Pipe SCH40 SCH80 in 6m Length


    Austenitic Stainless Steel 310/310S offers excellent resistance to oxidation up to 2000oF. Itis a low grade steel that prevents embrittlement and sensitization. It offers mediumstrength and hardness at the very low temperature even below -450oF. Outstanding heatresistant alloy. It offers superior corrosion resistance properties however poor than Inconel600 and Incoloy 800. Steel 310 is commonly employed in power reactors, thermal treatmentand food processing applications.It is utilized at temperature 1150oC in the continuous operations and 1035oC in theintermittent operations. 310S grade is a steel comprising of low concentration of carbon


    Benefits of Using ASME SA213 TP 310S Stainless Steel

    310S Stainless Steel Pipe is a highly alloyed austenitic stainless steel used for high temperature application. The high chromium and nickel content give the steel excellent oxidation resistance as well as high strength at high temperature. This grade is also very ductile, and has good weldability enabling its widespread usage in many applications.

    Typical Applications Grade 310/310S is used in fluidised bed combustors, kilns, radiant tubes, tube hangers for petroleum refining and steam boilers, Stainless Steel Reheater Tubes and Superheater Tubes for Boiler, coal gasifier internal components, lead pots, thermowells, refractory anchor bolts, burners and combustion chambers, retorts, muffles, annealing covers, saggers, food processing equipment, cryogenic structures.

    310S Stainless Steel combining excellent high temperature properties with good weldability and ductility, is designed for high temperature service. 310S stainless steel resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulfur gases are not present. 310S is also used for intermittent service at temperatures up to 1040°C.

    ASTM A213 TP310S Stainless Steel Pipe Tubes Sizes

    ASTM A312 TP310S Seamless Pipes / ASTM A213 ASME SA 213 TP310S TP310H TP310 Seamless Tubes

    • Size: 6NB – 1200NB
    • OD: 1/8″ – 12″ NPS
    • Wall Thickness : 0.6 – 63.5mm
    • Length: Fixed Length, Double Random & Cut Length

    ASTM A312 A249 TP310S ERW / Welded Pipes

    • Size: 1/8″ – 36″ NB, 1/4″ – 36″ OD
    • OD: 6.35 -508 mm
    • Wall Thickness : 0.8 – 63.5mm
    • Length: up to 25 Meters

    ASME SA213 TP310S TP310H EN10088-1 1.4841 Chemical Composition

    GradeUNS DesignationCMnPSSiCrNi
    S310020.02 max2.0 max0.020 max0.015 max0.15 max24.0 – 26.019.0 – 22.0
    310SS310080.08 max2.0 max0.045 max0.030 max1.00 max24.0 – 26.019.0 – 22.0
    310HS310090.04-0.102.0 max0.045 max0.030 max1.00 max24.0 – 26.019.0 – 22.0
    1.48410.20
    max
    2.0 max0.045 max0.015 max1.50-2.5024.0 – 26.019.0 – 22.0

    ASME SA213 TP310S TP310H Stainless Steel Mechanical Properties

    1. 310S Stainless Steel Pipe Mechanical Properties at Room Temperature

    TP310HTP310HTP310STP310S
    TypicalMinimumTypicalMinimum
    Tensile Strength, MPa645515595515
    Yield Stress (0.2 % offset), MPa355205295205
    Elongation (Percent in 50mm)52355235
    Hardness (Rockwell)90 HRB Max90 HRB Max

    2. 310S Stainless Steel Tubes Properties at Elevated Temperatures
    The values quoted are those for 310.
    Enquire for data on 310S .

    Short Time Elevated Temperature Tensile Strength

    Temperature, °C5506507508509501050
    Tensile Strength, MPa5504302801809050

    Creep data
    Stress to develop a creep rate of 1% in the indicated time at the indicated temperature.

    TimeTemperature °C550600650700750800
    10 000 hStress MPa1109070403015
    100 000 hStress MPa907550302010

    Creep Rupture Stress

    TimeTemperature °C6007008009001000
    1 000 hStress MPa190110503515
    10 000 hStress MPa17070352010
    100 000 hStress MPa1105525102

    TP310S Stainless Steel Physical Properties

    AlloyUNSSpec.Density Specific Gravity kg/dm³Modulus of Elasticity (x106 psi)Mean Coefficient of Thermal Expansion (IN./IN./°F x 10-6)Thermal Conductivity
    (BTU-in/ft2-h-°F)
    310SS31008A213, A3127.9829.09.2116
    310HS31009A213, A3127.9829.09.2116
    Weight calculation coefficient: 0.02507

    ASTM A312 TP310S Stainless Steel Pipe Standard Specifications

    310S is the low carbon version of 310 and is suggested for applications where sensitisation, and subsequent corrosion by high temperature gases or condensates during shutdown may pose a problem. 310 is manufactured in accordance with ASTM A 167 and 310S to ASTM A 213.

    310S Stainless Steel Pipe Range

    AlloyUNS DesignationWerkstoff NR.Specifications*
    310SS31008EN 10216 – 5 1.4845A/SA249, A/SA312, A/SA213
    310HS31009EN 10216 – 5 1.4845A/SA249, A/SA312, A/SA213

    ASME SA213 TP310S Stainless Steel Tubes and Pipes Application

    310S 310H have wide application in all high-temperature environments where scaling and corrosion resistance, as well as high temperature strength and good creep resistance, are required

    310S Stainless Steel Pipe Applications Oven linings, Stainless Steel Reheater Tubes and Superheater Tubes for Boiler, boiler baffles, kilns, lead pots, radiant tubes, annealing covers, saggers, burners, combustion tubes, refractory anchor bolts, fire box sheets, furnace components and other high temperature containers.

    Maximum internal pressure of TP310S Stainless Steel Tubes

    Maximum internal pressure of ASTM A312 A269 310S Size: OD 19.05mm WT 1.651mm Wall Thickness Tolerance: ± 10%

    GradePressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Remark
    100°F200°F300°F400°F500°F600°F700°F
    310S229229229229229221214A 312 and A 269 tube

    Maximum internal pressure of ASTM A312 A269 310S Size: OD 19.05mm WT 2.11mm Wall Thickness Tolerance: ± 10%

    GradePressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Remark
    100°F200°F300°F400°F500°F600°F700°F
    310S298298298298298288279A 312 and A 269 tube

    Maximum internal pressure of ASTM A312 A269 310S Size: OD 25.4mm WT 1.65mm Wall Thickness Tolerance: ± 10%

    GradePressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Remark
    100°F200°F300°F400°F500°F600°F700°F
    310S169169169169169169158A 312 and A 269 tube

    Maximum internal pressure of ASTM A312 A269 310S Size: OD 25.4mm WT 2.11 mm Wall Thickness Tolerance: ± 10%

    GradePressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Pressure
    bar
    Remark
    100°F200°F300°F400°F500°F600°F700°F
    310S219219219219219211205A 312 and A 269 tube

    ASTM A213TP310S Stainless Steel Heat Treatment

    Typical Properties in the Annealed Condition
    The properties quoted in this publication are typical of mill production and unless indicated should not be regarded as guaranteed minimum values for specification purposes.

    310S Stainless Steel Pipe Recommended Maximum Service Temperature
    (Oxidising Conditions)
    Continuous 1150 °C
    Intermittent 1035 °C

    310S Stainless Steel Tubing Thermal Processing
    1. Annealing.Heat from 1050 to 1150°C and in water Quenching.

    310S Stainless Steel Tubing Machinability 310S alloy machines similarly to type 304 stainless steel. Its chips are stringy and it will work harden rapidly. It is necessary to keep the tool cutting at all times and use chip breakers.

    310S Stainless Steel Pipe Welding Most of the austenitic stainless steel can be readily welded using fusion or resistance methods. Oxyacetylene welding is not recommended. Filler metal should be AWS E/ER 310.

    310S Stainless Steel Tube Hot Working Most common hot work methods can be successfully performed after uniform heating to 2150°F (1177°C). Do not forge below 1800°F (982°C). Rapid cooling is required to maximize corrosion resistance.

    310S Stainless Steel Tubing Cold WorkingAlthough this alloy has a high work hardening rate, it can be drawn, headed, upset, and stamped. Full annealing is required after cold work to remove internal stress.

    310S Stainless Steel Tube Annealing 1900-2050 °F (1038-1121 °C) water quench.

    310S Stainless Steel Pipe Principal Design FeaturesThe strength of this alloy is a combination of good strength and corrosion resistance in temperatures up to 2100°F (1150°C). Due to its relatively high chromium and nickel content it is superior in most environments to 304 or 309 stainless.

    310S Stainless Steel Pipe Hardening 310S Stianless Steel does not respond to heat treatment. Cold work will cause an increase in both hardness and strength.
