EN 10088-2 EN1.4435 Stainless Steel Plates High Nickel 316L
Stainless Steel from BAOSTEEL
More Informations of our Products
| Item | Stainless Steel Plates / Stainless Steel Sheets |
| Main Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410,
410S, 420, 430, 904L, etc. |
| Standard | ASTM GB JIS EN DIN BS |
| Thickness | 0.4mm-40mm |
| Stock Thickness | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm,
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as request |
| Standard size | 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed,
etc. |
| Package | Standard export package |
1.4435 Stainless Steel
1.4435 is an austenitic-ferritic chromium-nickel stainless steel
that contains molybdenum and nitrogen as additional alloying
elements. This combination makes it resistant to corrosion in many
harsh environments, such as marine applications or those involving
intense acids or chemicals. It also offers good weldability and
formability, making it an ideal choice for a wide variety of
projects.
Difference Between 1.4435 and 316L Stainless Steel
The main difference between 1.4435 vs 316L stainless steel comes
down to their composition; while both offer superior strength and
durability, 1.4435 has higher levels of chromium, nickel,
molybdenum, and nitrogen than 316L, which gives it better corrosion
resistance overall. Additionally, while both are acceptable choices
for medical implants, 316L is the preferred choice due to its lower
carbon content which allows it to better resist oxidation when
exposed to repeated sterilization cycles or long-term exposure to
body fluids or tissue cultures (such as in dental procedures).
Chemical Composition
One of the primary differences between 1.4435 and 316L stainless
steel is their chemical composition. 1.4435 stainless steel
contains chromium, nickel, and molybdenum, while 316L stainless
steel contains chromium, nickel, molybdenum, and silicon. The
addition of silicon to 316L stainless steel makes it more resistant
to corrosion than 1.4435 stainless steel.
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N | Fe |
| 1.4435 | 0.03 | 1.00 | 2.00 | 0.045 | 0.015 | 17.0-19.0 | 12.50-15.00 | 2.50-3.00 | 0.10 | Bal |
Tensile Strength
Another difference between 1.4435 and 316L stainless steel is their
tensile strength. 1.4435 stainless steel has a higher tensile
strength than 316L stainless steel, meaning that it is better
suited for applications where high levels of stress are present.
Yield Strength
1.4435 stainless steel also has a higher yield strength than 316L
stainless steel, meaning that it can withstand more force before
deforming. This makes 1.4435 stainless steel ideal for applications
where high levels of force are present, such as in the construction
industry.
Application of 1.4435 Stainless Steel
Construction encasement, doors, windows and armatures, offshore
modules, cisterns and pipes for chemical tanks, production,
warehousing and over land transportation of chemicals, food and
beverages, pharmacy, synthetic fibre, paper and textile plants and
pressure vessels. Due to the low C-content, the resistance to
intergranular corrosion is also guaranteed in the welded condition.
