EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless Steel

More Informations of our Products

Item	Stainless Steel Plates / Stainless Steel Sheets
Grades	201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc.
Thickness	0.4mm-40mm
Stock Thickness	0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm
Width	1000mm 1219mm 1500mm or cutting any size as request
Standard size	10002000mm 12192438mm 15006000mm 20006000mm
Finish	2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc.
Package	Standard export package

Chemical Composition of EN 1.4432 Stainless Steel

C	Si	Mn	Ni	P	S	Cr	Mo	N
max 0.03	max 1	max 2	10.5 - 13	max 0.045	max 0.015	16.5 - 18.5	2.5 - 3	max 0.11

MECHANICAL PROPERTIES OF GRADE1.4432

Proof strength Rp0.2(MPa)	Tensile strength Rm(MPa)	Impact energy KV(J)	Elongation at fracture A(%)	Reduction in cross section on fracture Z(%)	As-Heat-Treated Condition	Brinell hardness(HBW)
176(≥)	215(≥)	11	32	43	Solution and Aging,Annealing,Ausaging,Q+T,etc	311

Equal Grade of 1.4432 Stainless Steel

EU EN	USA -	Japan JIS	France AFNOR	England BS	Sweden SS	Russia GOST
X2CrNiMo17-12-3	316L	SUS316L	Z3CND17-13-03	316S13	2353	03KH17N14M3

1.4432 RANGE OF PRODUCTS


Product type	Products	Dimension	Processes	Deliver Status
Plates/Sheets	Plates/Sheets	0.08-200mm(T)WL	Forging,hot rolling and cold rolling	Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting
Steel Bar	Round Bar,Flat Bar,Square Bar	Φ8-1200mm*L	Forging,hot rolling and cold rolling,Cast	Black,Rough Turning,Shot Blasting,
Coil/Strip	Steel Coil/Steel Strip	0.03-16.0x1200mm	Cold-Rolled&Hot-Rolled	Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting
Pipes/Tubes	Seamless Pipes/Tubes,Welded Pipes/Tubes	OD:6-219mm x WT:0.5-20.0mm	Hot extrusion,Cold Drawn,Welded	Annealed,Solution and Aging,Q+T,ACID-WASHED
