    EN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data Sheet

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : EN 1.4659
    Certification : ISO
    Price : 4650 - 5850 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 300 kgs
    • Product Details
    • Company Profile

    EN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data Sheet


    EN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data Sheet


    Quick Informations


    Products Name1.4659 Stainless Steel PlateStandardEN 10088-2
    Thickness0.4 - 40.0mmSurface2B NO.1 BA NO.4 8K
    Standard Size1219*2438mm 1500*6000mmServiceCutting, surface processing

    More Informations of our Products


    ItemStainless Steel Plates / Stainless Steel Sheets
    Main Grades201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc.
    StandardASTM GB JIS EN DIN BS
    Thickness0.4mm-40mm
    Stock Thickness0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm
    Width1000mm 1219mm 1500mm or cutting any size as request
    Standard size1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm
    Finish2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc.
    PackageStandard export package

    EN 1.4659 (X1CrNiMoCuNW24-22-6) Stainless Steel


    EN 1.4659 stainless steel is a superaustenitic (highly alloyed) stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the solution annealed (AT) condition. 1.4659 is the EN numeric designation for this material. X1CrNiMoCuNW24-22-6 is the EN chemical designation.

    It has the highest ductility among wrought superaustenitic stainless steels. In addition, it has a very high tensile strength and a moderately high base cost.

    The graph bars on the material properties cards below compare EN 1.4659 stainless steel to: wrought superaustenitic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.

    Chemical Composition of 1.4659 Stainless Steel

    Among wrought stainless steels, the composition of EN 1.4659 stainless steel is notable for including tungsten (W) and containing a comparatively high amount of manganese (Mn). Tungsten interacts with other alloying elements to a greater extent than usual, which makes it hard to broadly characterize its effects. Manganese is used to improve ductility at elevated temperatures. It also permits a higher nitrogen content than would otherwise be possible.

    GradeCSiMnPSCrNiMoNCu
    EN 1.46590.020.702.00-4.000.030.0123.00-25.0021.00-23.005.50-6.500.35-0.501.00-2.00

    Mechanical Properties of 1.4659 Stainless Steel


    GradeYield / MpaTensile / MpaElongation A(%)Brinell Hardness(HBW)
    EN 1.465968419134444

    Standard Size of our 1.4659 Stainless Steel Sheets & Plates


    Cold Rolled 1.4659 Stainless Steel Sheets
    0.4*1000*2000mm0.5*1000*2000mm0.6*1000*2000mm0.8*1000*2000mm1.0*1000*2000mm1.2*1000*2000mm
    1.5*1000*2000mm2.0*1000*2000mm2.5*1000*2000mm3.0*1000*2000mm
    0.4*1219*2438mm0.5*1219*2438mm0.6*1219*2438mm0.8*1219*2438mm1.0*1219*2438mm1.2*1219*2438mm
    1.5*1219*2438mm2.0*1219*2438mm2.5*1219*2438mm3.0*1219*2438mm
    0.8*1500*3000mm1.0*1500*3000mm1.2*1500*3000mm1.5*1500*3000mm2.0*1500*3000mm2.5*1500*3000mm
    3.0*1500*3000mm4.0*1500*3000mm5.0*1500*3000mm
    Hot Rolled 1.4659 Stainless Steel Plates
    4.0*1500*6000mm5.0*1500*6000mm6.0*1500*6000mm8.0*1500*6000mm10.0*1500*6000mm12.0*1500*6000mm
    14.0*1500*6000mm16.0*1500*6000mm18.0*1500*6000mm20.0*1500*6000mm22.0*1500*6000mm25.0*1500*6000mm
    30.0*1500*6000mm35.0*1500*6000mm40.0*1500*6000mm45.0*1500*6000mm50.0*1500*6000mm55.0*1500*6000mm

    Advantage of our company

    • 1.Quality guaranteed:Strict factory quality inspection.Years of trade experience in the steel industry.
    • 2.24 hours online service: Professional customer service answers your questions online, please feel free to inquire at any time.
    • 3.Professional team: Rich trade experience,support product customization and complete service system

    EN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data SheetEN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data SheetEN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data SheetEN 1.4659 Stainless Steel Sheet & Plates SS Plate X1CrNiMoCuNW24-22-6 Stainless Steel Data Sheet
