    20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Bar Diameter 10 - 300mm Custom Cutting for Shaft

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 20CrMo5 / 1.7264 / 20CrMnMo
    Certification : ISO
    Price : 602-874USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 1 Ton
    • Product Details
    • Company Profile

    20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Bar Diameter 10 - 300mm Custom Cutting for Shaft

    20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Bar Diameter 10 - 300mm Custom Cutting for Shaft

    Products Specification


    Products Name

    20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Round Bar

    Diameter10 - 320mm
    Length6m or custom cutting any length as request
    TypeHot Rolled
    BrandBAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc
    MOQ1 Ton
    Loading PortShanghai Port
    Packingpacking by steel wire rope
    Deliver time5 - 7 days for stock materials
    Other Grade

    Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov,

    15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo,

    40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo

    StandardASTM GB EN DIN
    ApplicationStructure and Industrial

    Regular Standard Size of our 20CrMo5 Round Bar in Stock


    Standard Diameter10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300

    Other Alloy Steel Round Bar We Can Supply:


    40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7


    Chemical Composition of 1.7264 / 20CrMo5 (in weight %)


    CSiMnCrMoNiVWOthers
    0.210.251.051.250.25----

    DIN 1.7264 Mechanical

    Yield
    Rp0.2 (MPa)
    Tensile
    Rm (MPa)
    Impact
    KV/Ku (J)
    Elongation
    A (%)
    Reduction in cross section on fracture
    Z (%)
    As-Heat-Treated ConditionBrinell hardness (HBW)
    554 (≥)349 (≥)432323Solution and Aging, Annealing, Ausaging, Q+T,etc213

    Products Range of 20CrMo5 / 1.7264 Alloy Steel

    • Round bar / Wire rod (Diameter): 5.5mm to 800mm

    • Square bar / Flat bar: 3mm to 800mm

    • Length: Fixed length or random length or based on the customer's special requirement.

    • Heavy/middle plate via hot rolled: T6 - 200mm X W1000- 2500mm X L1000-12000mm

    • Sheet steel via cold rolled: T0.5 - 6mm X W600- 1000mm X L1000 - 2000mm

    • Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)

    • Forging piece: stepped shafts, and other different shapes based on OEM.

    Application of 20CrMo5 / 1.7264 Alloy Steel

    • Alloy structural steels are widely used in the filed of ship, vehicle, airplane, guided missile, weapons, railway, bridges, pressure vessel, machine tools, mechanical components with a bigger sectional size and so on.

    • Power generation – turbine fasteners – boiler support rods.

    • Process plant – fasteners, Mechanical gears, gear shaft, main axis, valve rod.

    • Mechanical parts - connecting rod, bolt and nut, Multidiameter shaft, Pressure vessel.
