    SAE8620/SAE8620H/20CrNiMo Alloy Steel Bar Structure Application Alloy Steel Rod

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : SAE8620/SAE8620H/20CrNiMo
    Certification : ISO
    Price : 612-884USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 1 Ton
    • Product Details
    • Company Profile

    SAE8620/SAE8620H/20CrNiMo Alloy Steel Bar Structure Application Alloy Steel Rod

    SAE8620/SAE8620H/20CrNiMo Alloy Steel Bar Structure Application Alloy Steel Rod

    Products Specification


    Products Name

    SEA8620 / 20CrNiMo Alloy Steel Round Bar

    Diameter10 - 320mm
    Length6m or custom cutting any length as request
    TypeHot Rolled
    BrandBAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc
    MOQ1 Ton
    Loading PortShanghai Port
    Packingpacking by steel wire rope
    Deliver time5 - 7 days for stock materials
    Other Grade

    Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov,

    15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo,

    40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo

    StandardASTM GB EN DIN
    ApplicationStructure and Industrial

    Regular Standard Size of our SAE8620 Round Bar in Stock


    Standard Diameter10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300

    Other Alloy Steel Round Bar We Can Supply:


    40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7

    AISI SAE 8620 Steel (UNS G86200)

    AISI SAE 8620 steel is a commonly used low-alloy material for carburizing, with excellent carburizing response, good hardenability for most section sizes, it has many extensive applications due to its low cost, better machinability, and availability.

    Chemical Composition

    AISI SAE 8620 steel chemical composition is listed in the table below.

    SAE AISI 8620 Chemical Composition, %
    StandardSteel Grade (UNS)CSiMnP, ≤S, ≤CrNiMoCu, ≤O, ≤Al, ≤
    ASTM A322;
    ASTM A29/A29M
    8620 (UNS G86200)0.18-0.230.15-0.350.70-0.900.0350.0400.40-0.600.40-0.700.15-0.25
    ASTM A5348620H0.17-0.230.15-0.350.60-0.950.0250.0150.35-0.650.35-0.750.15-0.250.30.0020.05

    Mechanical Properties

    AISI SAE 8620 material mechanical properties are listed in the following tables including yield strength (yield stress), tensile strength, impact strength and hardness, etc.

    Notes:

    • 1 MPa = 1 N/mm2
    • 1 GPa = 1 kN/mm2
    8620 alloy steel mechanical properties
    Steel (UNS)Tensile strength, Mpa (ksi), ≥Yield strength, Mpa (ksi), ≥Elongation in 50 mm (2 in.), %, ≥Reduction in area, %, ≥Hardness, HBIzod impact strength, J (ft·lbf)Condition or treatment
    8620 (UNS G86200)633 (92)357 (52)26.359.7183100 (74)Normalized at 915 °C (1675 °F)
    536 (78)385 (56)31.362.1149115 (83)Annealed at 870 °C (1600 °F)

    Applications

    The applications of AISI SAE 8620 steel including: Differentials (automotive and off-highway), drives (industrial, tractor accessory), engines, equipment (off-highway, steel or paper mill, mining), starters. Gears, steering mechanism, gear box and transmission components for cars.

    Carburized gears, pinions, shafts, differential rings, steering worms, engine crankshafts, spline shafts, chains, air drill parts, chuck jaws, oil well bit and reamer cutters, piston pins, pneumatic chucks, heavy-duty bolts, fasteners, and hand tools.

    SAE AISI 8620 Equivalent Material

    SAE AISI 8620 material equivalent to European EN (Germany DIN, British BSI, French NF…), ISO, Japanese JIS and Chinese GB standard (For reference).

    USChinaJapanEuropean UnionISO
    StandardGrade (UNS)StandardGrade (UNS)StandardGradeStandardStandard
    AISI SAE;
    ASTM A322;
    ASTM A29/A29M
    8620 (UNS G86200)GB/T 307720CrNiMo (A50202)JIS G4053SNCM220

    Products Show
