Alloy 347 / 347H Stainless Steel Pipe Tube SS Pipe EN DIN JIS GB ASTM in 5.8m 6m Length

Ask Lasest Price
Brand Name :	DELTA
Model Number :	347 / 347H
Certification :	ISO
Price :	4650-5760 USD/Ton
Payment Terms :	T/T, Western Union, L/C
Supply Ability :	10 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

Alloy 347 / 347H Stainless Steel Pipe Tube SS Pipe EN DIN JIS GB ASTM in 5.8m 6m Length

Alloy 347 / 347H Stainless Steel Pipe Tube SS Pipe EN DIN JIS GB ASTM in 5.8m 6m Length

Item	seamless stainless steel pipe/tube
Steel grade	300 series
Standard	ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605,GB13296
Material	304,304L,309S,310S,316,316Ti,317,317L,321,347,347H,304N,316L, 316N,201,202
Surface	Polishing,annealing,pickling,bright
Type	hot rolled and cold rolled
Stainless steel round pipe/tube
Size	Wall thickness	1mm-150mm
	Outer diameter	6mm-2500mm
Package	Standard export seaworthy package,or as required.
Application	It is widely used in the fields of petroleum, food, chemical industry, construction, electric power, nuclear energy, energy,machinery, biology, papermaking, shipbuilding and boilers. Pipes can also be made according to customer requirements.
Contact	If you have any questions,please feel free to contact me.
Container size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM

Stainless Steel Pipe Grade

Austenitic Stainless Steel	201, 301, 304, 305, 310, 314, 316, 321, 347, 370, etc
Martensitic Stainless Steel	410, 414, 416, 416, 420, 431, 440A, 440B, 440C, etc
Duplex Stainless Steel	S31803, S32101, S32205, S32304, S32750, etc
Ferritic Stainless Steel	429, 430, 433, 434, 435, 436, 439, etc

347 Stainless Steel Pipe is columbium stabilized austenitic stainless steel pipe with good general corrosion resistance and somewhat better resistance in strong oxidizing conditions than 321 (UNS S32100). It has excellent resistance to intergranular corrosion after exposure to temperatures in the chromium carbide precipitation range of 800 – 1500°F (427 – 816°C). The alloy has good oxidation resistance and creep strength to 1500°F (816°C). It also possesses good low temperature toughness.

Benefits of 347 Stainless Steel

Higher creep stress and rupture properties when compared with 304
Ideal for high temperature service
Overcomes sensitization and intergranular corrosion concerns
Can be used in elevated temperature applications for ASME Boiler and Pressure Vessel Code applications
Due to stabilisation the material offers better overall corrosion resistance when compared to 304/304L
Excellent mechanical properties
A high carbon version (347H) is also available

Typical Uses

Heat exchangers
High temperature steam service
High temperature chemical process

Both 347/347H are used primarily in elevated temperature applications.

Stainless Steel DIN 1.4550 / 1.4961 Seamless TubesStockist, SS UNS S34700 / S34709 Seamless Tubing, SS 347 Cold Drawn Tubes, SS 347H Seamless Tubes, SS 347 Seamless Tubing

Stainless Steel Round Tube
Steel Grade	302, 303,303Cu, 304, 304L, 304H,310S, 316, 316L, 317L, 321,310S,309S, 410, 410S,420, 430, 431,4L
Standard	ASTM A240/A240M, ASME SA- 240/SA-240M, JIS G 4305, EN 10028-7, EN10088-2
Wall thickness	1mm-150mm
Outer diameter	6mm-2500mm
Length(mm)	2000-6000
deviation	≤0.1%

Stainless Steel Square Tube
Steel Grade	302, 303,303Cu, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S, 410, 410S,420 , 430, 431, 4L
Standard	ASTM A240/A240M, ASIffi SA-240, SA-24OM, JIS G 4304, EN 10028-7,EN 10088-2
Wall thickness	1mm-150mm
Outer diameter	6mm-2500mm
Length(mm)	2000-6000
deviation	≤0.1%

Stainless Steel Welded Pipe
Steel Grade	302, 303,303Cu, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S ,309S, 410, 410S,420, 430, 431, 4L
Standard	ASTM A240/A240M, ASIffi SA-240,SA-24OM, JIS G 4304, EN 10028-7,EN 10088-2
Wall thickness	1mm-150mm
Outer diameter	6mm-2500mm
Length(mm)	2000mm-6000mm
deviation	≤0.1%

FAQ

Q:Can you send samples?

A:Of course, we can send samples to all parts of the world, our samples are free, but customers

need to bear the courier costs.

Q:What are the shipping ports?
A:You can choose other ports according to your needs.

Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.

Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications.

Q:How long does your delivery time take?
A:In general, our delivery time is within 7-45 days, and may be delayed if the demand is extremely

large or special circumstances occur.

Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.

Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging.

Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.

Q:What is your working time?
A:In general, our online service time is: 8:00-22:00, after 22:00, we will reply to your inquiry during

the next working day.
