    Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

    Ask Lasest Price
    Brand Name : TISCO
    Model Number : 316L
    Certification : ISO
    Price : 1300 - 1480 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

    Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel


    Products Specification


    Products Name316L Stainless Steel Sheet
    StandardASTM EN JIS GB BIS
    Thickness

    0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm

    Surface2B 2D NO.1 or process other surface as request
    Standard Size1219*2438mm 1000*2000mm
    ServiceSlit Cutting, bending , surface treatment
    Other Grade200 Series: 201 202
    300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347
    400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446
    Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy
    MOQ500 kgs
    PackingWooden Pallets and waterproof paper

    Introduce of 316L Stainless Steel

    Grade 316L is very similar to 316 stainless steel. It is still considered a molybdenum-bearing grade and has properties that make it highly resistant to corrosive degradation. 316L grade stainless steel differs from 316 in that contain lower levels of carbon. The decreased level of carbon in this stainless steel makes this grade immune from sensitisation or grain boundary carbide precipitation. Because of this unique property, Grade 316L tends to be commonly used in heavy gauge welding situations. Additionally, the lower carbon levels make this grade easier to machine. Like 316 stainless steel, 316L because of its austenitic structure is extremely tough, even in the most extreme of temperatures.


    More details of 316L Stainless Steel Sheets


    Products316 stainless steel sheet/plate
    Width500-2000mm
    Length1000-12000mm
    ThicknessCold Rolled:0.3-3 mm, Hot Rolled:3-120mm
    Materials316
    StandardASTM A240 ,ASTM A167,ASTM A176,GB/T3280,JIS4304, EN10088-2,etc
    Surface FinishNo.1, No.4, 2B, BA, HL, No.8, Mirror finish, and so on.

    Composition Specification (%):

    GradeCMnAndPSCrMoInN
    316min. max.– 0.082.0– 0.75– 0.045– 0.03018.03.0014.0– 0.10
    316Lmin. max.– 0.030

    2.0

    – 0.75– 0.045– 0.03016.0

    18.0

    2.00

    3.00

    10.0

    14.0

    – 0.10
    316Hmin. max.0.10

    2.0

    – 0.75– 0.045– 0.03016.0

    18.0

    2.00

    3.00

    10.0

    14.0

    Mechanical Property Specification:

    GradeTensile Strength (MPa)

    min

    Yield Strength 0.2% Proof (MPa)

    min

    Elongation (% in 50mm)

    min

    Hardness
    Rockwell B (HR B)

    max

    Brinell (HB)

    max

    3165152054095217
    316L4851704095217
    316H5152054095217
    316H also has a requirement for a grain size of ASTM No 7 or coarser.

    DIMENSION FOR STOCK SHEET

    No.T*W*L(mm)No.T*W*L(mm)No.T*W*L(mm)
    10.3*1000*2000201.5*1219*24383924.0*1500*6000
    20.3*1219*2438212.0*1000*20004025.0*1500*6000
    30.4*1000*2000222.0*1219*24384130.0*1500*6000
    40.4*1219*2438232.5*1000*20004235.0*1500*6000
    50.5*1000*2000242.5*1219*24384340.0*1500*6000
    60.5*1219*2438253.0*1000*20004445.0*1500*6000
    70.6*1000*2000263.0*1219*24384550.0*1500*6000
    80.6*1219*2438273.0*1500*60004655.0*1500*6000
    90.7*1000*2000284.0*1500*60004760.0*1500*6000
    100.7*1219*2438295.0*1500*60004865.0*1500*6000
    110.8*1000*2000306.0*1500*60004970.0*1500*6000
    120.8*1219*2438318.0*1500*60005075.0*1500*6000
    130.9*1000*20003210.0*1500*60005180.0*1500*6000
    140.9*1219*24383312.0*1500*60005285.0*1500*6000
    151.0*1000*20003414.0*1500*60005390.0*1500*6000
    161.0*1219*24383516.0*1500*60005495.0*1500*6000
    171.2*1000*20003618.0*1500*600055100.0*1500*6000
    181.2*1219*24383720.0*1500*600056105.0*1500*6000
    191.5*1000*20003822.0*1500*600057110.0*1500*6000

    Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel
