ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall

Product Categories

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall

Ask Lasest Price
Brand Name :	DELTA
Model Number :	Carbon Steel , Alloy Steel
Certification :	ISO
Price :	610 - 820 USD/Ton
Payment Terms :	L/C, Western Union, T/T
Supply Ability :	20Ton per week
Delivery Time :	5 - 10 days based on the quantity
MOQ :	2 Ton

Add to Cart

Product Details
Company Profile

ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall

ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall

AISI 1020 Tube Specifications and Thickness

Name	SAE1020 Hot Rolled Seamless Steel Pipe
Surface	Bare,oiled
Material	ASTM A106B, ASTM A53B, API 5L Gr.B, ST52, ST37, ST44 SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140
MOQ	5 tons for normal size and material
WT	As customer's requests
Payment terms	TT deposit + the balanced against BL copy / LC or 100% LC at sight
Trade terms	FOB,C&F,CIF,EXW
Length	fixed or random,as customer request.
End Treatment	Plain(can be beveled, threaded,punch,shrink,extension... )
Lead time	within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty

ASTM A519 Grade 1020 Specification

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings are Low Carbon Steel Tubings with 0.18-0.23 % carbon content with combination of 0.30-0.60 % manganese. These Tubings are also known as mild steel pipes and tubes. ASTM A519 Grade 1020 Tubings are low-cost Tubings easy to form and shape. These pipes are manufactured as per ASTM Specification and commercially referred as cs pipes or ms pipes. Low Carbon Steel Pipes are not as hard as hig carbon steel pipes,Though carburizing can increase its surface hardness.

ASTM A519 Grade 1020 Properties

Chemical Properties
Carbon	Silicon	Manganese	Phosphorous	Sulphur	Molybdenum	Nickel	Chromium	Copper	Others
0.18-0.23	–	0.30-0.60	0.04	0.05	–	–	–	–	–

Mechanical Properties
Yield Strength		Tensile Strength			Elongation A5 min
MPa min	ksi min	MPa min	MPa min	ksi min	Percentage
		345	–	50	25

Equivalent Designation
DIN	EN	BS	NFA	ASTM	ASME
DIN 23912) Grade St 45	–	–	ASTM A519 Grade 1020	ASME SA 519 Grade 1020

ASTM A519 Grade 1020 specification covers several grades of carbon and alloy steel seamless mechanical tubing. When welding is used for joining the weld able mechanical tube grades, the welding procedure shall be suitable for the grade, the condition of the components, and the intended service. Recommended pipe size will be developed by FerroPipe upon receipt of your inquiry. A print or sketch of the part to be produced should be included. Grade, chemical analysis and surface condition are carefully considered, and production processes are tailored to achieve the best tubing for the end use.

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings stockist in Mumbai, India.Ferropipe stocks a complete range of IBR Certified ASTM A519 Grade 1020 Carbon Steel Seamless Tubings in outer diameter tube sizes ½”-24” and Nominal bore NB sizes 15NB-600NB in China. Exporting Carbon Steel Pipes and Alloy Steel Pipes to countries worldwide including IRAN, IRAQ, KUWAIT, QATAR, South Africa, Nigeria, Saudi Arabia, Australia, Canada & Mexico.

Delivery Executions of ASTM A519 Grade 1020 Carbon Steel Seamless Tubings

Tube Ends

All tubes are supplied with clean, square cut ends.Deburring and/or chamfering can be carried out on request.

Tube surface

Tubes are supplied normally without anti-corrosive treatment, but anti-corrosive treatment is available and is carried out on request.

Protection

Black and Bare
External Varnished with Black or Clear LAcquer

Mill test certificate

MTC is issued in accordance with EN 10204.

Packaging

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings are bundled as standard, with steel straps into hexagonal bundles with one end flush.Length sorting can be carried out on request. Tubes can also be bundled in multiples. Bundle weights are adjusted as requested by the customer. Each bundle contains tubes from a single cast/heat only.

Marking

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings is marked with tube type, heat number, steel grade and size. Information is repeated along the whole length of the tube. Other markings, such as stamping, can be made on request. Bundles are also labeled with a tag having info both alphanumeric and by bar code.

Labelling

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings delivered direct from our mill is labeled in accordance with automotive standard, ie with both alphanumeric and bar code information. Customer specific data can be added on request.

ASTM A519 Grade 1020 / CK20 / S20C Carbon Steel Pipe Seamless Tubing in Heavy Wall
