EN 10210 S355J2+N Carbon Steel Seamless Tube Steel Round Pipe Hollow Tubes

S355J2 Tube Specifications and Thickness

Name	S355J2 Hot Rolled Seamless Steel Pipe
Surface	Bare,oiled
Material	ASTM A106B, ASTM A53B, API 5L Gr.B, ST52, ST37, ST44 SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140
MOQ	5 tons for normal size and material
WT	As customer's requests
Payment terms	TT deposit + the balanced against BL copy / LC or 100% LC at sight
Trade terms	FOB,C&F,CIF,EXW
Length	fixed or random,as customer request.
End Treatment	Plain(can be beveled, threaded,punch,shrink,extension... )
Lead time	within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty

S355J2 grade of pipes is a low carbon grade. This S355J2 Pipe has a good chemical composition of silicon, sulfur, manganese, and potassium. These pipes possess good corrosion resistance and don’t erode easily. They don’t dissociate or deform under any levels of pressure or temperature. We are only supplier of S355J2+N pipe which is a welder-friendly pipe that can readily be machined. The pipe is highly versatile and is utilized for critical applications due to its superior strength. These pipes can be availed in lengths up to 18000mm. An S355J2 Carbon Steel Pipe possesses a tensile strength between 490Mpa to 630Mpa and a yield strength between 315Mpa to 355Mpa. They can be elongated by a minimum of 22%. The EN 10210 S355J2+N Carbon Steel Seamless Pipe is designed with high concentrations of carbon. This single piece of metal pipe possesses superior strength and exceptional tolerances in stress-induced environments. An S355J2 Seamless Pipe can be availed in lengths between 4mm to 219mm. All our products are quality tested and performance certified.

EN 10025 S355J2 Tube Dimension chart

Nominal Bore (mm)	O.D. (mm)	Thk. (mm)	Wght (kg/m)
15	21.3	2.00	0.95
		2.60	1.21
		3.20	1.44
20	26.9	2.30	1.38
		2.60	1.56
		3.20	1.87
25	33.7	2.60	1.98
		3.20	0.24
		4.00	2.93
32	42.4	2.60	2.54
		3.20	3.01
		4.00	3.79
40	48.3	2.90	3.23
		3.20	3.56
		4.00	4.37
50	60.3	2.90	4.08
		3.60	5.03
		5.00	6.19
65	76.1	3.20	5.71
		3.60	6.42
		4.50	7.93
80	88.9	3.20	6.72
		4.00	8.36
		4.80	9.90
100	114.3	3.60	9.75
		4.50	12.20
		5.40	14.50
125	139.7	4.50	15.00
		4.80	15.90
		5.40	17.90
150	165.1	4.50	17.80
		4.80	18.90
		5.40	21.30
150	168.3	5.00	20.1
		6.3	25.2
		8.00	31.6
		10.00	39
		12.5	48
200	219.1	4.80	25.38
		6.00	31.51
		8.00	41.67
		10.00	51.59
250	273	6.00	39.51
		8.00	52.30
		10.00	64.59
300	323.9	6.30	49.36
		8.00	62.35
		10.00	77.44

EN 10025-2 S355J2+N Chemical Composition

Grade	C	Si	Mn	P	S
S355J2H (1.0576)	max 0.22	max 0.55	max 1.6	max 0.03	max 0.03

Spec Chart of S355J2 Square Tube

Standard	BS EN 10210
Sizes	300 mm NB
Outside Diameter	21.3 to 457.2 millimeter.
Grade	S355J2+N
Type	Welded \| ERW \| Seamless
Length	6000 - 14000 millimeter, Cut to length
Surface Treatment	Supplier in Black Painted \| Corrosion Resistant Coating \| Galvanized \| FBE
Wall Thickness	1.8 to 14.27mm
Delivery Condition	Annealed & Pickled, Polished, Bright & Annealed, etc

Equivalent Material of EN 10210 S355J2+N Welded Pipe

USA	Germany DIN,WNr	Japan JIS	France AFNOR	England BS	Italy UNI	European old EN	Sweden SS	Czechia CSN
A656	1.0577 ASt52 St52-3N	SS490YA	A52FP	224-460	S355J2G4	Fe510D2 S355J2G4	2134-01	11531

Steel Grade S355J2+N Seamless Tube Dimension Tolerance

Execution	Size Range	O.D. Tolerance	Wall tolerance
Hot-rolled Tube	OD – 80 mmOD > 80 mmWall < 12 mmWall - 12 mm	± 0.4 mm± 0.5 % of OD	± 0.7 mm± (5 % x wallthickness + 0.1 mm
Hot-rolled peeled tube	All sizesWall < 12 mmWall - 12 mm	+ 0.25/- 0 mm	± 0.8 mm± (5 % x wall thickness+ 0.2 mm)
Cold Worked tubecold-rolled or cold-drawn	OD < 40 mmOD 40 - 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 - 8 mm Wall Thickness > 8	+ 0.30/- 0 mm+ 0.35/- 0 mm+ 0.40/- 0 mm*	± 0.30 mm± 0.35 mm± 0.40 mm

Standard length tolerance

Component length (mm)	O.D. 30-100 mm	O.D. 100-254 mm
10-100	+ 1.0/- 0	+ 2.0/- 0
100-600	+ 2.0/- 0	+ 3.0/- 0
600-1200	+ 3.0/- 0	+ 4.0/- 0
1200-5000	+ 5.0/- 0	+ 6.0/- 0

Get Free sample of S355J2 Seamless Pipe, Refer Steel Grade S355J2+N Pipe and EN 10210 S355J2+N Carbon Steel Seamless Pipe Sizing Chart.

EN 1.0577 Hot Finished Structural Hollow Sections Standard Sizes

Size mm	kg/m	Size mm	kg/m
40 x 20 x 2.0	1.68	40 x 20 x 2.5	2.03
40 x 20 x 3.0	2.36	40 x 25 x 1.5	1.44
40 x 25 x 2.0	1.89	40 x 25 x 2.5	2.23
50 x 25 x 2.0	2.21	50 x 25 x 2.5	2.72
50 x 25 x 3.0	3.22	50 x 30 x 2.5	2.92
50 x 30 x 3.0	3.45	50 x 30 x 4.0	4.46
50 x 40 x 3.0	3.77	60 x 40 x 2.0	2.93
60 x 40 x 2.5	3.71	60 x 40 x 3.0	4.39
60 x 40 x 4.0	5.72	70 x 50 x 2	3.56
70 x 50 x 2.5	4.39	70 x 50 x 3.0	5.19
70 x 50 x 4.0	6.71	80 x 40 x 2.5	4.26
80 x 40 x 3.0	5.34	80 x 40 x 4.0	6.97
80 x 40 x 5.0	8.54	80 x 50 x 3.0	5.66
80 x 50 x 4.0	7.34	90 x 50 x 3.0	6.28
90 x 50 x 3.6	7.46	90 x 50 x 5.0	10.11
100 x 50 x 2.5	5.63	100 x 50 x 3.0	6.75
100 x 50 x 4.0	8.86	100 x 50 x 5.0	10.90
100 x 60 x 3.0	7.22	100 x 60 x 3.6	8.59
100 x 60 x 5.0	11.70	120 x 80 x 2.5	7.65
120 x 80 x 3.0	9.03	120 x 80 x 4.0	12.00
120 x 80 x 5.0	14.80	120 x 80 x 6.0	17.60
120 x 80 x 8.0	22.9	150 x 100 x 5.0	18.70
150 x 100 x 6.0	22.30	150 x 100 x 8.0	29.10
150 x 100 x 10.0	35.70	160 x 80 x 5.0	18.00
160 x 80 x 6.0	21.30	160 x 80 x 8.0	27.90
200 x 100 x 5.0	22.70	200 x 100 x 6.0	27.00
200 x 100 x 8.0	35.4	200 x 100 x 10.0	43.60
250 x 150 x 5.0	30.5	250 x 150 x 6.0	38.2
250 x 150 x 8.0	48.0	250 x 150 x 10	59.3
300 x 200 x 6.0	48.10	300 x 200 x 8.0	60.50
300 x 200 x 10.0	75.00	400 x 200 x 8.0	73.10
400 x 200 x 10.0	90.70	400 x 200 x 16	142.00

Various Types of S355J2 Seamless Pipe Test

Radiographic Test
Charpy Impact Test
Ultrasonic Test
Pitting Corrosion Test
Positive Material Recognition
Hydrostatic Test

Call us for discount on DIN EN 10025-2 S355J2 Hollow Section, Find out S355j2 Pipe Heat treatment, Check Carbon Steel s355j2 Tube mechanical property.

EN 10025 S355J2+N Square Tube Heat treatment

Hot Forming		Heat Treatment
Temperature°C	Cooling Type	Normalizing 1″	Stress relieving anneal 2″	Cooling Type
700-750	Air	850-950°C	580-630°C	Air

S355J2+N Steel Line Pipe Processing

Hot rolled
Cold rolled
Cutting
Forming Machining/ Drilling
Grinding
Testing

S355J2 Pipe Mechanical Strength

Specification	EN10210 S355J2H
Tensile Strength Rm N/mm2: 3 ≤ T ≤ 100mm	470 – 630
Yield Strength ReH Min, N/mm2: T ≤ 16mm	355
Min Elongation % T ≤ 40mm on gauge length 5.65. √S0	22
Impact properties Minimum Ave energy (J) at -20°C	27
