ASTM A269 / A270 Stainless Steel Pipe TP316L SS Pipe for Medical Industrial

Ask Lasest Price
Brand Name :	DELTA
Model Number :	TP304 TP316L TP310S TP904L TP321.etc
Certification :	ISO
Price :	3410- 4200 USD/Ton
Payment Terms :	T/T, Western Union, L/C
Supply Ability :	10 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

ASTM A269 / A270 Stainless Steel Pipe TP316L SS Pipe for Medical Industrial

ASTM A269 / A270 Stainless Steel Pipe TP316L SS Pipe for Medical Industrial

Products Name	ASTM A269 Stainless Steel Pipe
Pipe Type	Seamless Pipe . Welded Pipe
Surface	Pickling , polishing
Out Diameter	6 - 508mm
Wall Thickness	1.0 - 50.0mm
Length	6m or cutting any length as request
Standard	ASTM / GB / EN / DIN / JIS / BS / BIS
Mainly Grade	304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy
Service	Cutting, Polishing, Hairline Finishing
MOQ	200 Kgs
Packing	standard packing for export
Application	Industrial , food , medical, househould

Stainless Steel Pipe

We are a professional supplier of stainless steel pipe and tubing in China, we provides both stainless steel seamless pipe and stainless steel welded pipe and other ss pipes.
Our product covers full 300 series and duplex stainless steel, nickel-based alloy and super austenitic stainless steel etc, including material 304/L, 316/L, 317L, 321, 310S, 347H, 904L, 254 SMO, Duplex 2205, 2507, Monel, Inconel, Hastelloy etc.
We are also ability to supply titanium alloy tube and copper alloy tubes in ASME / EN norms. All of our tubings are qualified and a third party inspection are available for them.

What Is The Technology for Seamless Stainless Steel Pipes

Cold Rolling is a preferred production process for high precision seamless stainless steel tube. Most of our heat exchanger tubes and precision tubes are cold rolled tubing. This technique provides a high forming rate, narrow tolerances and good turnouts. At present, the largest diameter we can get is 114.3mm for this processing.
Cold drawing is the common process for our ss tubings and pipes. Cold drawn stainless steel pipe will get a very narrow tolerance ranges, and keep the chemical element in a good condition. Additionally, the cold drawing process is the perfect choice for situations which place high requirements on the quality of the surface structure.

Materials of Stainless Steel Pipe

Material	Grade
Stainless Steel	TP304, 304L, 304H, 316, 316L, 316H, 316Ti, 317, 317L, 310S, 310H, 347, 347H, 321, 321H, 904L, S31254(254SMO) (mat.1.4301,1.4307,1.4948,1.4401,1.4404,1.4571,1.4438,1.4438, 1.4833,1.4841,1.4845,1.4845,1.4450,1.4541,1.4878,1.4539, ,1.4547) etc.
Duplex & Super Duplex Steel	UNS S31803, S32205, S32750, S32760, S32304 (Mat.1.4462,1.4410,1.4501,1.4362)etc.
Nickel Alloy	Monel 400, Inconel 600, Inconel 625, Incoloy 800, Incoloy 800H, Incoloy 825, Hastelloy B2, Hastelloy C-22, Hastelloy C-276, 15-5PH, 17-7PH, Cu70Ni30(C71500/B30), Cu90Ni10(C70600/B10) etc.

Range Covers - Stainless Steel Pipe Dimensions

Materials	Size*	Wall Thickness**	SMLS	Welded
Stainless Steel 304, 304L, 309S, 310S, 310H, 316/L, 316H, 316Ti, 317/L, 347/H, 904L, S31254(254SMO)	1/2″-24″	SCH10S, SCH20, SCH40S/STD, SCH80S/XS, SCH30, SCH60, SCH80, SCH100, SCH120, SCH160, XXS	√
	1/2″-104″	SCH5S~80S/XS		√
Duplex & Super Duplex S31803, S32205, S32750, S32760,etc.	1/2″-16″	SCH10S, SCH20, SCH40S/STD, SCH80S/XS	√
Duplex & Super Duplex S31803, S32205, S32750, S32760,etc.	1/2″-104″	SCH5S~80S/XS		√
Nickel Alloy-Alloy20,28,31, Monel400,K500, Inconel 600,601,625, Incoloy800, 800H, 800HT, 825, Hastelloy C22, C276, B2 etc.	1/2″-16″	SCH10S, SCH40S, STD, SCH60, SCH80S, XS, SCH100, SCH120	√
	1/2″-104″	SCH5S~80S/XS		√
Other materials	Please make a specific enquiry to us, our team will make the best to you asap.

Inspection & Quality

Our factory are ISO 9001 and CE-PED approved manufacturer. We believe that the quality is the life of company. To provide quality product is the things we are doing.

PMI test to ensure the material quality
Dimension controlling during fabricating and finished
100% Visual and surface examination
NDT test (Eddy Current and Hydro Test)
Other requirement on request

Inspection and Testing for Stainless Steel Pipe

Eddy Current Test
Hydrostatic Test
Radiography Test (for welded pipe)
Liquid Dye Penetrant Test
Ultrasonic Test

Tensile Test
Bending Test
Flaring Test
Flattening Test
Hardness Test

Positive Material Identification (PMI)
Surface Roughness
Hardness Test
Dimension Examination
Visual Checking

Impact Test
Intergranular Corrosion Test
Grain Size Test
Chemical Analysis
Other test on requirement

Our Strength of Stainless Steel Pipe

Full grades of austenitic stainless steel, duplex stainless steel and nickel based alloy
Small order quantity available from 200 kgs
Large diameter seamless stainless steel pipe, up to 36″
Thin wall thickness seamless stainless steel pipe, like o.d.273×w.t.4mm
Double quality control system – first from our approved factory, second from our owned QA
Fast delivery of 20~40days for general grades
Flexible and professional service and operations
Both seamless and welded pipe are available

Application

With its excellent performance, stainless steel pipe and tubes have been extended from industrial fields such as petrochemicals, aviation, pharmaceuticals and food industry, to construction, municipal engineering and other areas of life, and are increasingly extended.

Ship building
Petrochemical
Steel plant
Chemical
Paper Mill & Fertilizers
Power plant
Shipyard
Construction
Oil & gas

Machinery
Railway
LNG
Aircraft
Civil Project
Water Treatment
Food and Beverage
Pharmaceutical

ASTM A269 / A270 Stainless Steel Pipe TP316L SS Pipe for Medical Industrial
