Brand Name : | BAOSTEEL WISCO |
Model Number : | S350GD+Z40-Z275 |
Certification : | ISO |
Price : | 625-870 USD/Ton |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 20Ton per week |
Delivery Time : | 5 - 12 days based on the quantity |
Regular Spangle S350GD+Z275 Glavanized Steel Roll 0.6 - 3.0mm Thickness Width 1250mm 1500mm
Specification of our galvanized steel coil
Product Name | S350GD+Z275 Galvanized steel coil |
Width | 1000mm 1250mm 1500 or other width according to customer's
requirement |
Thickness | 0.3 - 3.0mm |
Zinc Coating | Z40 Z60 Z80 Z100 Z120 Z150 Z180 Z275 |
Standard Size | 1000*2000mm 1250*2500mm 1500*3000mm |
Surface Structure | Normal spangle coating(NS),minimized spangle
coating(MS),spangle-free(FS) |
Standard | ASTM JIS EN GB |
Type of Coating | Hot Dipped Galvanized Steel |
Service | Slit Cutting any size as request |
Packing | packing on wooden frame |
S350GD + Za, S350GD + ZFa is a kind of hot dipped galvanized steel
under the standard Q/BQB 420-2003 and it is a kind of low alloy
steel. The products are widely used in the automotive, appliance,
construction, machinery manufacturing and other industries.
The grade StE345-2Z is same with S350GD+Z for the chemical
composition and mechanical property. If you need StE345-2Z,
S350GD+Z also can meet your requirement. The figure 350 also means
the minimum yield strength for S350GD+Z, S350GD+ZF IS 350Mpa, same
as S220GD+Z, S220GD+ZF, S250GD+Z, S250GD+ZF, S280GD+Z, S280GD+ZF,
S320GD+Z, S320GD+ZF.
S350GD + Za, S350GD + ZFa Chemical composition:
Grade | Chemical composition % | |||||
C max | Si max | Mn max | P max | S max | Alt min | |
S350GD + Za, S350GD + ZFa | 0.25 | --- | 1.5 | 0.035 | 0.035 | 0.015 |
S350GD+Z, S350GD + ZF Mechanical Property:
STEEL GRADE | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation% min (Lo=80mm b=20mm) | The coating adhesion (The heart bending diameter ) | |
min | min | <0.7mm | 0.7mm | a=thickness | |
S350GD + Za, S350GD + ZFa | 420 | 350 | 14 | 16 | 3a |
Packing | When each plate weight is under 1 tons, it will be in bundle with steel strips 2-4. When each plate weight is over 1 ton, it will be piece by piece. |
20 feet container contains dimension | Width under 2300mm, length under 6000mm |
40 feet container contains dimension | Width under 2300mm, length under 12000mm |
By bulk vessel | Freight charge is low by bulk cargo, and large heavy sizes can not be loaded into containers can shipping by bulk cargo |
Product Advantages
![]() |
