    Copper Plate and Sheet C11000 / 110 Copper Plate CNC Cutting Width 500mm 600mm 1000mm

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : C11000
    Certification : ISO
    Price : 8 - 9 USD/Kg
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 15 Tons per month
    Delivery Time : 5 - 10 days
    • Product Details
    • Company Profile

    Copper Plate and Sheet C11000 / 110 Copper Plate CNC Cutting Width 500mm 600mm 1000mm

    Copper Plate and Sheet C11000 / 110 Copper Plate CNC Cutting Width 500mm 600mm 1000mm


    Product name
    Copper Plate & Sheet
    Copper and copper alloy grade
    C11000,C10100,C12200
    H59, H60, H62, H65, H68, H70, H80, H85, H90, H96, C2100, C2200,C2300, C2400, C2600, C2680, C2720, C2800, C3560, C3601, C3713, C3771, C3561 , CuZn30, CuZn32, CuZn35, CuZn37, CuZn40 ,TU1, T2, TP2, H96, H90, H85, H80, H70, H65, H63, H62, H59, HPb63-3, HPb66-0.5, HPb62-2, HPb62-3, HPb59-3, HSn70-1, HSn62-1,QSn8-0.3, QSn4-4-4, QAl9-4, QSB-1 etc.
    WidthWithin 1500mm Custom Cutting any width as request
    Thickness0.5 - 200.0mm

    Length

    1m 2m 3m 6m or custom cutting any length as request
    StandardASTM EN DIN JIS GB
    Other productsPlate, Sheet, Coil , Pipe, Round Bar, Square Bar, Flat Bar, Hexagonal Bar.etc

    Our C11000 Copper Plate & Sheet Thickness

    0.3mm0.4mm0.5mm0.6mm0.7mm0.8mm
    0.9mm1.0mm1.2mm1.5mm2.0mm2.5mm
    3.0mm4.0mm5.0mm6.0mm8.0mm10.0mm
    12.0mm14.0mm16.0mm20.0mm22.0mm24.0mm
    25.0mm28.0mm30.0mm35.0mm40.0mm45.0mm
    50.0mm55.0mm60.0mm65.0mm70.0mm75.0mm
    80mm85.0mm90.0mm95.0mm100.0mmwithin200mm

    The most common grade specification for ETP copper sheets is C11000, which is often referred to as Oxygen-Free High Conductivity (OFHC) copper. The C11000 grade is recognized for its exceptional electrical conductivity and is widely used in the production of electrical conductors, bus bars, connectors, and various electronic components.

    Here are the general characteristics of ETP (C11000) copper:

    Chemical Composition (Typical):

    • Copper (Cu): 99.90% minimum

    Physical Properties:

    • Density: 0.323 lb/in³ (8.94 g/cm³)
    • Melting Point: Approximately 1,981°F (1,083°C)
    • Thermal Conductivity: 231 Btu·ft/(hr·ft²·°F) at 68°F (401 W/m·K at 20°C)
    • Electrical Conductivity: Approximately 100% IACS (International Annealed Copper Standard) at 68°F (20°C)

    Mechanical Properties:

    • Tensile Strength (annealed): 32,000 psi (220 MPa) minimum
    • Yield Strength (annealed): 5,000 psi (35 MPa) minimum
    • Elongation (in 2 inches, annealed): 40% minimum

    Additional Information:

    • Grain Size: ETP copper typically has a small, uniform grain size, contributing to its excellent electrical properties.
    • Corrosion Resistance: ETP copper exhibits good corrosion resistance in various environments.

    Sizes Available

    SHEETS (COLD ROLLED) . . . up to 1/4" thick max

    PLATES (HOT ROLLED) . . . . cut to size, up to 6" thick

    C11000 Copper Alloy Specifications

    End ProductSpecification
    PlateAMS 4500, ASTM B152, SAE J461, J463
    SheetAMS 4500, ASTM B152, B694, SAE J463, J461
    Sheet, Building ConstructionASTM B370
    Sheet, CladASTM B506
    Sheet, Lead CoatedASTM B101
    Sheet, Printed CircuitsASTM B451
    StripAMS 4500, ASTM B694, B152, SAE J463, J461
    Strip, Building ConstructionASTM B370
    Strip, CladASTM B506
    Strip, Printed CircuitsASTM B451
