    Hastelloy C276 UNS N10276 Nickel Alloy Plate Sheet Thickness 0.4 - 30.0mm

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : hastelloy c276
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Hastelloy C276 UNS N10276 Nickel Alloy Plate Sheet Thickness 0.4 - 30.0mm

    Hastelloy C276 UNS N10276 Nickel Alloy Plate Sheet Thickness 0.4 - 30.0mm


    Products Namehastelloy C276 nickel alloy plate sheet
    Thickness

    Cold rolled:

    0.5 - 3.0mm Hot rolled 4.0 - 30.0mm

    Standard Size1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm
    Surface2B NO.1
    MOQ50 kgs
    ServiceCutting, Surface Finishing
    PackingWaterproof paper and wooden pallets
    Loading PortShanghai Port
    Price termFOB CFR CIF EXW
    Payment term30% TT in advance , 70% TT balance against copy of B/L
    Other GradeHastelloy C22 C4 X C276
    Monel 400 K500
    Incoloy 800 800H 800HT 825 925
    Inconel 600 601 625 716 718
    Stainless Steel Grade201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA

    Hastelloy C276 ASTM Standard B575 Plate is a nickel-molybdenum-chromium superalloy with an enhancement of tungsten made to have superb deterioration resistance in a wide variety of extreme atmospheres. Although there are a number of variations of the nickel alloy, Hastelloy C276 Plate is without a doubt the most commonly used. Alloy C276 Plate shows superb deterioration resistance in a range of extreme settings and also media. Like lots of other nickel alloys, it is pliable, easily developed and also welded.

    ASTM B575 UNS N10276 Hastelloy C276 Sheet is frequently utilized in several industries, consisting of petrochemical, chemical oil and gas, power generation, pharmaceutical, pulp and paper manufacturing and drainage treatment. Hastelloy C276 Coil has superior resistance to matching, tension deterioration breaking as well as oxidizing environments. ASME SB 575 UNS N10276 material likewise displays resistance to deterioration by salt water in crevice conditions, which can generate hostile attack in other commonly utilized materials. UNS N10276 Plate is usually remedy heat-treated at 2050 Degree F and fast quenched.


    Hastelloy C276 Plate /Sheet Thickness

    Cold rolled Hastelloy C276 ASTM B575 thin Plates0.2-4mm
    Hot rolled ASTM B575 C276 Alloy medium Plates4-20mm
    Hot rolled ASTM B575 UNS N10276 thick Plates20-60mm
    Hot rolled Alloy C276 extra thick Plates60-115mm

    2.4819 Alloy C 276 Plate equivalent

    EuropeAmericaJapanRussiaEuropeRussia
    STANDARD

    WERKSTOFF

    NR.

    UNSJISGOSTENOR
    Alloy C2762.4819N10276NW 0276ХН65МВУNiMo16Cr15WЭП760

    Hastelloy C276 ASTM B575 chemical composition

    Hastelloy C276Analysis
    NiBal
    Mo15 – 17
    Cr14.5 – 16.5
    Fe4 – 7
    W3 – 4.5
    Co2.5 max
    Mn1.0 max
    C0.01 max
    v0.35 max
    P0.04 max
    S0.03 max
    Si0.08 max

    UNS N10276 Plates mechanical properties

    Density8.89 g/cm3
    Melting Range1370 °C (2500 °F)
    Tensile StrengthPsi – 1,15,000
    MPa – 790
    Yield Strength (0.2%Offset)Psi – 52,000
    MPa – 355
    Elongation40 %
