    EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : hastelloy c276
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing

    EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing


    Product TypeHastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate
    SpecificationASTM B575 / ASME SB575
    Tolerances (width / thickness)
    • EN 10258/ DIN 59381)
    • EN 10151 2.4819 Hastelloy C-276 Strips
    • EN 10088 Hastelloy C276 SB575 strips
    Dimensions
    • Cold rolled Alloy C276 Plates 0.5-6.4 mm
    • Hot rolled Alloy C276 Plates 3.0–10.0 mm
    Thickness0.1 to 100 mm Thk
    Width10-2500mm
    Length2m, 2.44m, 3m, or as required
    FinishSATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc.
    HardnessSoft, Hard, Half Hard, Quarter Hard, Spring Hard
    variety of shapesCoils, Foils, Plates, Sheet, Strip, Plain Sheet, Checker Plates, Rolling Sheet, Flats, Clad Plates, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), Rolling Plates, Flat Shim, soft annealed, descaled, tread Plates, sheared, annealed

    Hastelloy C276 Sheet is a high-quality, corrosion-resistant alloy made from nickel, molybdenum, and chromium. It has excellent resistance to hot oxidizing and reducing media, as well as to a wide range of other contaminants.

    Hastelloy C276 Sheets is used in many industries, including the pulp and paper industry, oil and gas production, and chemical processing.


    Equivalent Grades of Hastelloy C-276 Shim


    STANDARDWERKSTOFF NR.UNSJISENDINISOGOSTOR
    Hastelloy C2762.4819N10276NW 0276NiMo16Cr15W177506208ХН65МВУЭП760

    Chemical Composition of Hastelloy C276 Sheet

    CMnSiS

    Co

    NiCrFeMoP
    0.010 max1.00 max0.08 max0.03 max2.50 max50.99 min*14.50 – 16.504.00 – 7.0015.00 – 17.000.04 max

    Mechanical Properties of B575 Hastelloy C276 Sheet


    DensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
    8.89 g/cm31370 °C (2500 °F)Psi – 1,15,000 , MPa – 790Psi – 52,000 , MPa – 35540 %

    Hastelloy C276 Application

    There are many sectors and industries consuming ASTM B575 Hastelloy C276 Sheet like:

    Organic chloride process equipmentEvaporators, heat exchangers, filters and mixers used in sulfuric acid environments
    Equipment for flue-gas desulfurisation plantsEquipment for processes utilizing halide or acid catalysts
    Digesters and bleach plants in the paper industrySulfuric acid reactors
    Components exposed to sour gasMilitary
    Defence & Aerospace industriesUsed for Oil and Gas

    EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 FinishingEN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 FinishingEN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 FinishingEN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
