    Inconel 625 / DIN 2.4856 Alloy Plate Hot Rolled 3.0 - 30.0mm Thickness 625 Alloy Plate

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : inconel 625
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Inconel 625 / DIN 2.4856 Alloy Plate Hot Rolled 3.0 - 30.0mm Thickness 625 Alloy Plate


    Inconel 625 / DIN 2.4856 Alloy Plate Hot Rolled 3.0 - 30.0mm Thickness 625 Alloy Plate


    Material
    Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
    Shape
    Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
    Grade
    Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
    Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
    Alloy : Alloy 20/28/31
    Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
    Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
    Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
    Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
    Haynes: Haynes 230/556/188
    Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
    Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
    Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
    UNS N06600 / DIN W. Nr. 2.4816
    Incoloy: Incoloy 800/800H/800HT/825/925/926;
    GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
    Monel: Monel 400/K500/R405
    Nitronic: Nitronic 40/50/60;
    Nimonic: Nimonic 75/80A/90/A263 ;
    Specification
    Wire: 0.01-10mm
    Strip: 0.05*5.0-5.0*250mm
    Bar: φ4-50mm;Length 2000-5000mm
    Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
    Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

    Alloy 625 is perfectly suited to the most demanding applications, from sub-zero to extremely high-temperature environments. It achieves these levels of high strength as a result of the solid solution effects of molybdenum and niobium (also known as Colombium) from room temperatures up to 800°C. Alloy 625 is usually supplied in the hot worked and annealed condition.

    Alloy 625 is particularly useful in situations where oxidation resistance and avoidance of pitting are required. In the annealed condition, this Inconel Alloy is fully austenitic and suitable for machining. It provides excellent corrosion resistance in a wide variety of severely corrosive environments due to its high alloy content. With nearly 60% nickel composition it is virtually immune from stress corrosion cracking.

    Alloy 625 is non-magnetic and able to operate over a wide temperature range, from cryogenic temperatures up to 980degC. This supports applications in jet engines, heat exchangers, furnace hardware and chemical plant equipment.

    Chemical Composition:

    CrNiMoCoNb (+Ta)TiWCuCMnNSiPSFeAl
    Min20.0058.008.003.15
    Max23.0010.001.004.150.400.100.500.500.0150.0155.000.40

    Mechanical Properties:

    Bars up to and including 4” diameter or sectionBars above 4” diameter or section
    0.2% Proof Stress415 N/mm260ksi345 N/mm250ksi
    Tensile Strength830 N/mm2120ksi760 N/mm2110ksi
    Elongation, 5.65√S0 and 4D30%25%
    Reduction of Area35%35%
    Hardness (Brinell)

    Key Features:

    • Good strength/ductility properties from sub-zero temperatures to over 980°C
    • Excellent corrosion and fatigue resistance in a wide variety of corrosive environments including seawater and industrial acids
    • Non-magnetic and spark resistant
    • Resistant to high temperature oxidation and carburisation
    • Excellent resistance to stress corrosion cracking

    Applications:

    • Wellhead components
    • Sheathing, Fasteners, Clamps
    • Downhole equipment for corrosive/sour service
    • Propellers and Shafts
    • Propulsion Motors
    • Fasteners
    • Reactor core & control rod components
    • Chemical process equipment

    FAQ


    Q: Are you trading company or manufacturer ?
    A: We are a professional manufacturer with 20 years' experience and have took part in international trade for 10 years.

    Q: How about your quality and how do you guarantee the quality?
    A: All products we supply is primary as you need, Our company is certificated to ISO9001: 2008, and every product will be tested for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.

    Q: Do you provide samples ? Is it free or extra ?
    A: Yes, we could offer the sample for free charge.

    Q: How long is your delivery time?
    A: For Stocks, we can send the goods to loading port within 7 days after receiving the deposit ;
    For production period, it usually needs about 15 days ~30 days after receiving the deposit.

    Q: What is your terms of payment ?
    A: Usually 30% deposit by TT in advance and balance against copy pf BL or L/C at sight.
