Hastelloy C22 Nickel Alloy Round Bar / Black Pickled Rod in 6m
Length With EN 10204-3.1 Certificate
| Form | Nickel Alloy Bars |
| Grade | Alloy C22 |
| Outer Diameter | 6mm-250mm or according to customer’s requirement |
| Length | 1meter, 3 meters and 6 meters or customer’s requirement |
| Standard | ASTM, ASME, EN, JIS, DIN, GB/T, etc |
| Process Method | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar & Rod |
| Surface Finish | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished,
Polished, Hairline |
| Other Grade | Hastelloy : B2 B3 C22 C276 G30 X Incoloy: 800 800H 800HT 825 925 A286 330 Inconel: 600 601 617 625 718 725 X-750 Monel: 400 k-500 |
| Price Item | EXW FOB CFR CIF |
| Payment | 30% TT inadvance, 70% TT Balance against copy of B/L |
| Delivery Time | It depends on your bars order total quantity and stock of these
mother origin materials. Usually from the start of the order to the
completion of production is about 3-4 weeks |
| Quality Requirement | Mill test certificate will be offered with shipment, the third
party inspection is available |
| Main Markets | Europe, North America, Middle East, Southeast Asia |
| Metal Test | High or low temperature impact test, metallographic analysis |
| Chemical Analysis | As nickel alloy C22 bars standard |
Hastelloy C-22 alloy (UNS N06022) is one of the well-known and
well-proven nickel-chromium-molybdenum materials, the chief
attributes of which are resistance to both oxidizing and
non-oxidizing chemicals, and protection from pitting, crevice
attack, and stress corrosion cracking.
Its high chromium content provides much higher resistance to
oxidizing media than the family standard, C-276
alloy, and imparts exceptional resistance to chloride-induced pitting,
an insidious and unpredictable form of attack, to which the
stainless steels are prone.
Like other nickel alloys, Hastelloy C-22 alloy is very ductile,
exhibits excellent weldability, and is easily fabricated into
industrial components. It is available in the form of plates,
sheets, strips, billets, bars, wires, pipes, tubes, and covered
electrodes. Typical chemical process industry (CPI) applications
include reactors, heat exchangers, and columns.
Features of Hastelloy C-22
HASTELLOY alloy C-22 is a nickel-chromium-molybdenum alloy with
enhanced resistance to pitting, crevice corrosion and stress
corrosion cracking.
It resists the formation of grain boundary precipitates in the
weld-heat affected zone making it suitable for use in the as-welded
condition. C-22 has outstanding resistance to both reducing and
oxidizing media and because of its resistibility can be used where
“upset” conditions are likely to occur.
Hastelloy C-22 Alloy Applications
Alloy C-22 can be used in a variety of applications including:
- Springs
- Fasteners
- Seals
- Medical devices and components
- Flue gas equipment
- UNS Number: N06022
- Werkstoff Number: 2.4602
- Standards: ASTM B622, B619, B575
