    317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 317L
    Certification : ISO
    Price : 2400 -3220 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 200 kgs
    • Product Details
    • Company Profile

    317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm

    317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm


    Material
    200 300 400 Series stainless steel
    Grade
    201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
    Standard
    AISI ASTM JIS DIN EN BS
    Tech
    Cold rolled / Hot rolled
    Thickness
    Hot rolled: 3mm-16mm 16-150mm
    Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
    As per customer's request: 16-150mm
    Cold rolled: 0.3-6mm
    Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0
    As per customer's request: 4.0/5.0/6.0
    Width&Length
    1000mm-6000mm, or as per customer's request
    Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft)
    1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft)
    1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft)
    Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft)
    1500*3000mm (5*10ft)
    1800 available 2000 available
    Place of Origin
    Jiangsu China
    Processing Service
    Bending, Welding, Recoiling, Punching, Cutting
    Tolerance
    ±1%
    Surface Treatment
    N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
    Payment
    T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
    Delivery Time
    5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request

    Designed as per international and national standards, these UNS S31700, S31703 Sheet & Plate are offered in customized length sizes and shapes to our esteemed clients. Also referred as WNR 1.4449, 1.4438 Sheet & Plate these are available at best possible rates in the market.
    We are an authorized Dealer, as well as Supplier of Stainless Steel 317 / 317L Sheet & Plate of various Approved Manufacturing companies like Jindal Steel Works, Acreinox, Columbus Stainless, Outokumpu, Thyssenkrupp etc.

    SS 317 / 317L SHEETS AND PLATES SPECIFICATIONS :

    Dimensions317L Stainless Steel Plate
    StandardASTM A240 / ASME SA240
    Width1000mm, 1219mm, 1500mm, 1800mm, 2000mm
    Thickness4mm-40mm
    Length2000mm, 2440mm, 3000mm, 5800mm, 6000mm,
    FormCoils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
    Surface Finish2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
    HardnessSoft, Hard, Half Hard, Quarter Hard, Spring Hard etc

    EQUIVALENT GRADES FOR STAINLESS STEEL 317 / 317L SHEET & PLATE

    STANDARDWERKSTOFF NR.UNSJISEN
    SS 3171.4449S31700SUS 317–
    SS 317L1.4438S31703SUS 317LX2CrNiMo18-15-4

    CHEMICAL COMPOSITION OF SS 317 / 317L SHEETS & PLATES

    GradeCMnSiPSCrMoNiFe
    SS 3170.08 max2.0 max1.0 max0.045 max0.030 max18 – 203 – 411 – 1557.845 min
    SS 317L0.035 max2.0 max1.00 max0.045 max0.030 max18 – 203 – 411 – 1557.89 min

    MECHANICAL PROPERTIES FOR SS 317 / 317L SHEETS & PLATES

    DensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
    7.9 g/cm31400 °C (2550 °F)Psi – 75000 , MPa – 515Psi – 30000 , MPa – 20535 %

    TYPES OF SS 317 / 317L SHEET & PLATE

    • Stainless Steel 317 Cold Rolled Sheets Supplier
    • 317L Stainless Steel Sheets and Plates Dealer
    • SS 317 Round Sheet Exporter
    • 317L Stainless Steel Cold Rolled Plates
    • ASME SA240 SS Sheet Stockist
    • Stainless Steel SA240 TP317L Embossed Plates
    • UNS S31703 Cold Rolled Plates
    • 1.4438 SS Sheets Manufacturer
    • AISI 317 Steel Sheets / Plates
    • TP 317L SS Embossed Sheets Manufacturer in India
    • Stainless Steel 317 Hot Rolled Plates
    • ASTM A240 TP317 Cold Rolled Sheet Supplier in Saudi Arabia
    • UNS S31700 SS Finish Plates Stockist in Riyadh
    • ASTM A240 TP317 Finish Stainless Sheet
    • 317 Austenitic Stainless Steel 2D Finish Sheets
    • Stainless Steel 317 Sheet / Plates / Coils Exporter
    • SS 317L Plates Dealer
    • 317 Stainless Steel Plates Stockholder
