    Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 317L
    Certification : ISO
    Price : 2400 -3220 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 200 kgs
    • Product Details
    • Company Profile

    Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets

    Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets


    Material
    200 300 400 Series stainless steel
    Grade
    201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
    Standard
    AISI ASTM JIS DIN EN BS
    Tech
    Cold rolled / Hot rolled
    Thickness
    Hot rolled: 3mm-16mm 16-150mm
    Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
    As per customer's request: 16-150mm
    Cold rolled: 0.3-6mm
    Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0
    As per customer's request: 4.0/5.0/6.0
    Width&Length
    1000mm-6000mm, or as per customer's request
    Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft)
    1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft)
    1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft)
    Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft)
    1500*3000mm (5*10ft)
    1800 available 2000 available
    Place of Origin
    Jiangsu China
    Processing Service
    Bending, Welding, Recoiling, Punching, Cutting
    Tolerance
    ±1%
    Surface Treatment
    N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
    Payment
    T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
    Delivery Time
    5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request

    Alloy 317L is a low-carbon stainless steel with increased additions of chromium, nickel and molybdenum for better corrosion resistance than type 316L. This steel resists attack from sulphurous, acetic, formic, citric and tartaric acids as well as combatting the tendency to pit when in contact with phosphorous acid, chlorides, bromides and iodides.


    Standard Specification of 317L Stainless Steel Products


    TypeSizesSchedulesASTM Standards
    Bar1/2″ thru 6″A276, A479
    Butt Weld Fittings1/2″ thru 12″Sch 10, 40, 80, 160 & XXHA403
    ForgingsA182
    Pipe Welded & Seamless1/4″ thru 16″Sch 10, 40, 80, 160 & XXHA312
    Tube, WeldedA249
    Tube, SeamlessA213
    PlateA240
    Flange & Pressure FittingsAll Descriptions

    Stainless Steel 317L Plate Thickness

    Cold rolled ASTM A240 317L thin plate0.2-4mm
    Hot rolled SS 317L medium plate4-20mm
    Hot rolled 317L SS thick plate20-60mm
    Hot rolled AISI 317L extra thick plate60-115mm

    317L Material Equivalent

    STANDARDUNSWERKSTOFF NR.
    SS 317LS317031.4438

    Applications

    Alloy 317 and 317L stainless steel is a low-carbon, corrosion resistant steel used to handle sulfur, pulp liquor, acid dyestuffs, acetylating and nitrating mixtures, bleaching solutions, severe coal and oil smoke, and many chemical compounds. 317 & 317L Stainless steel pipe, flanges and fittings are typically found in:

    • Paper and pulp handling equipment
    • Textile equipment
    • Food-processing equipment

    Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate SheetsAlloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate SheetsAlloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate SheetsAlloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets
