nickel plate alloy inconel 600 601 625 X-750 718 825 Monel 500 K500 400 C276 C22 round bar/rod inconel 718

Ask Lasest Price
Brand Name :	DELTA
Model Number :	nickel alloy
Certification :	ISO
Price :	25-30 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

nickel plate alloy inconel 600 601 625 X-750 718 825 Monel 500 K500 400 C276 C22 round bar/rod inconel 718

nickel plate alloy inconel 600 601 625 X-750 718 825 Monel 500 K500 400 C276 C22 round bar/rod inconel 718

Material	Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape	Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
Grade	Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
	Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
	Alloy : Alloy 20/28/31
	Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
	Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
	Haynes: Haynes 230/556/188
	Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
	Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816
	Incoloy: Incoloy 800/800H/800HT/825/925/926;
	GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
	Monel: Monel 400/K500/R405
	Nitronic: Nitronic 40/50/60;
	Nimonic: Nimonic 75/80A/90/A263 ;
Specification	Wire: 0.01-10mm Strip: 0.055.0-5.0250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product Characteristics	1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Standard	GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Inspection	ISO,SGS,BV,PMI and so on.

A nickel alloy plate is a non-ferrous metal with superior strength and toughness. The Nickel Alloy Plate can be alloyed with different alloys like chromium, molybdenum, and other specifications. The Pure Nickel Plate has good corrosion resistance properties across harsh environments. These plates work well in higher temperature conditions and have unique properties. A Nickel Clad Plate has a melting point of 1453 degrees C and a boiling point of 2730 degrees C. The plates have a density of 8.9 g/cm3 and have a young modulus of 200 GPa.

ASTM B162 Nickel Chequered Plate has good mechanical properties that allow it to withstand different conditions. These plates have a Vickers hardness of 638and can be processed in either or cold rolling procedures. A Nickel Hot Rolled Plate is processed at extreme temperatures till they reach its recrystallization limit. This allows the plates to have excellent workability and formability. The Nickel Cold Rolled Plate is processed at room temperature soon after the hot rolling process. Here the plate has a superior surface finish and excellent tolerances in different conditions.

Complete information for pure nickel sheet grade

Nickel Plate Grades	ASTM	AMS	WNR	Temprature	Strength	Nickel content	Lifespan
Nickel 200	ASTM B162 ASME SB-162	AMS 5553	WNR 2.4066	600ºF 315ºC	Yeild: 148 MPa Tensile: 462 MPa	99.6%	25 to 35 years
Nickel 201	ASTM B162 ASME SB-162	AMS 5553	WNR 2.4061 or 2.4068	1250ºF 677ºC	Yeild:103 MPa Tensile: 403 MPa	99.6%	25 to 35 years
Monel 400	ASTM B127 ASME SB127	AMS 4544	WNR 2.4360	1000°F 538°C	Yeild: 172-345 MPa Tensile: 517-620 MPa	66.5%	25 to 35 years
Monel k500	ASTM B127 ASME SB127	–	WNR 2.4375	1600°F 870°C	Yeild: 690 MPa Tensile: 965 MPa	63%	25 to 35 years
Inconel 600	ASTM B168 ASME SB168	AMS 5540	WNR 2.4816	1900 – 2250°F 1040 – 1230°C	Yeild: 172 to 345 MPa Tensile: 655 MPa	72%	30 years
Inconel 601	ASTM B168 ASME SB168	AMS 5870	WNR 2.4851	1600-2250°F 870-1230°C	Yeild: 205 Mpa Tensile:550 MPa	58-63%	over 70 years
Inconel 625	ASTM B443 ASME SB443	AMS 5599/5869	WNR 2.4856	2000°F 1093°C	Yeild: 490 Mpa Tensile: 690 MPa	58%	over 50 years
Inconel 718	ASTM B670 ASME SB670	AMS 5596/5597	WNR 2.4668	-253° to 1300°F -423° to 705°C	Yeild: 725 MPa Tensile: 1035 MPa	52.5%	25 to 35 years
Inconel X-750	ASTM B637 ASME SB637	AMS 5542/5598	WNR 2.4669	2540-2600°F 1393-1427°C	Yeild: 620 MPa Tensile:695 MPa	70%	25 to 30 years
Incoloy 800	ASTM B409 ASME SB409	AMS 5877	WNR 1.4876	1600-2250°F 871-1232°C	Yeild: 240 Mpa Tensile: 520 MPa	30-45%	25 to 35 years
Incoloy 800H	ASTM B409 ASME SB409	AMS 5871	WNR 1.4958	1740 – 2190°F 950 – 1200°C	Yeild:241 Mpa Tensile:552 Mpa	30-35%	25 to 35 years
Incoloy 825	ASTM B424 ASME SB424	–	WNR 2.4858	1600-2150°F 870-1180°C	Yeild: 241 MPa Tensile: 586 MPa	38-46%	upto 30 years
Hastelloy C22	ASTM B575 ASME SB575	–	WNR 2.4602	1121°C 2050°F	Yeild:310 MPa Tensile:690 MPa	56%	25 to 35 years
Hastelloy C276	ASTM B575 ASME SB575	–	WNR 2.4819	2,415-2,500°F 1,323-1,371°C	Yeild: 363 Mpa Tensile:758 Mpa	57%	over 30 years
Hastelloy B2	ASTM B333 ASME SB-333	–	WNR 2.4617	2250-1800°F 1232-982°C	Yeild:350 Mpa Tensile:760 Mpa	68%	25 to 30 years
Hastelloy C4	ASTM B575 ASME SB575	–	WNR 2.4610	1200 – 1900°F 649 -1038°C	Yeild: 492 MPa Tensile: 738 MPa	64%	25 years
Alloy 20	ASTM B463 ASME SB463	–	WNR 2.4660	2,100 – 1,650 °F 1,150 – 900 °C	Yeild: 300 MPa Tensile: 620 MPa	32-38%	25 and 35 years

For larger sizes, please contact the nickel alloy plate suppliers listed above in the United Arab Emirates.
Manufacturing size range of nickel plate/ sheet	Pure nickel strip sizes	Nickel alloy strip edges
Thickness: 1mm – 10 mm Width: 10 – 2500 mm Length: 2000/2500/3000 mm	Gauge: 0.127 – 13 mm Length: upto 15 meter Width: 5 to 1200 mm	Slit edge Rolled edge Deburred
Nickel alloy strip AMS	Standard specification for nickel and nickel-base alloy-clad steel plate	ASTM A265 nickel shim density
AMS 5553	ASTM B162 ASTM A265	8.89 g/cm³
Pure nickel strip maximum operating temperature	Nickel clad plate melting point	Temperature range of ASME SB162 nickel flat shim
870 – 1230°C	1453°C	Up to 600°F
ASME SB162 nickel plate grades	Hardness range of nickel alloy rolling plate	Nickel sheet elongation
200 201	Brinell hardness: 45 – 73 Rockwell hardness: 168.53 BHN	45%
Nickel alloy hot rolled plate surface finish classes	Most common types of ASTM B162 nickel sheet	Manufacturing technique of commercially pure nickel plate
Class A : finest finish Class B: slightly less fine finish Class C : most basic finish	Pure Nickel annealed plate Nickel Alloy Strips ASTM B162 Nickel Clad plate Nickel Coil ASME SB162 Nickel Shim sheet Nickel Alloy Rolls Pure Nickel Sheet Nickel Alloy foils ASTM B162 Nickel Plate Above nickel alloy plate stockist produce corresponds with customer drawings, compare our cost and turnaround time with those of other nickel sheet stockists.	Roll forming Cold rolling Hot rolling
ASME SB162 nickel polished plate features	Nickel alloy shim welding method	Ex-stock of ASTM B162 nickel plate & sheet
Weldability Outstanding heat resistance Strength Metallurgical stability Corrosion resistance	SAW SMAW (MMA) GMAW (MIG/MAG) PLASMA GTAW (TIG)	VDM Columbus Stainless Nippon Yakin Valbruna Stainless Steel Outokumpu Special Metals (SMC) HAYNES International ATI Looking for nickel plate price? Contact verified nickel plate suppliers for ex-stock & buy material at dealer & distributor price in Saudi Arabia, Qatar, Oman & Bahrain
Nickel plate marking	ASTM B162 nickel sheet finish	Pure nickel strip applications
Manufacturer logo / name Material grade Sizes Origin of material ASTM/ ASME standard Manufacturing date	Brushed Glossy Electroless nickel plating Sandblasted Mirror Matte	Vessels Heat exchangers Valves Marine engineering Petrochemical Hydrocarbon Food processing Oil and gas The nickel alloy plate suppliers listed above have ex-stock and supplied to numerous nations in the past, such as Saudi Arabia, Egypt, Middle East, South Africa, United States, and Oman.
Modulus of elasticity of nickel alloy shim	ASME SB162 nickel coil coefficient of thermal expansion	Nickel clad plate velocity
205 GPa	100°C to 1200°C	Up to 170 HV
ASTM B162 nickel hot rolled coil common trade names	Nickel alloy plate welding electrode	Other industry standards SB162 nickel sheet
Hastelloy Incoloy Inconel Nicrofer Nimonic	Nickel welding electrode 141	EN 10204 RR SABRe Edition 2 DFARS Compliant PWA LCS GE Aircraft Engine (GT193) EN 2.4856 EMS95377 GE Aviation S-SPEC-35 AeDMS S-400
Nickel alloy sheet method of cutting	Certification of ASTM B162 nickel rolling plate	Nickel sheet value added services
Oxy-propane flame cutting Plasma cutting Waterjet cutting Laser cutting Direct contact with the above nickel alloy plate distributors, dealers, and stockists specified for the above-mentioned cuts	Certificate of Origin legalized 100% Radiography Test Report Third Party Inspection Report Raw Materials Certificate EN 10204/3.1B	Mechanical processing Blanking Edge preparation Sawing Shearing Slitting Welding Cutting to length Polishing Bending Use chat or email options to get in direct contact with listed nickel alloy plate stockists, stockholders, and distributors for these services.
ASME SB162 nickel cold rolled plate packaging	Nickel alloy rolling plate testing requirements	ASTM B162 nickel flat shim hardness type
Bubble wraps Wooden Pallets Steel Strips Bundled Customized Pallets	Non destructive test pmi test Destructive test Nabl approved lab test Third party inspection test Visual inspection test Mechanical test Flaring Test Chemical test	Half Hard Soft Hard Quarter Hard Spring Hard
ASTM B162 nickel shim processing	ASME SB162 nickel plate characteristics	Electrical conductivity of nickel alloy rolling sheet
Edging Deburring Precision Rerolling Boring Heat Treating Leveling Grinding Trepanning	Resilient Highly resistant to fatigue cracking Thermal distortion Durable material that can withstand harsh operating	50-70µΩ cm
Difference between nickel plate, sheet & Foil	Pure nickel clad plate documentation offered	Nickel hot rolled plate delivery time
Ni Sheet: 0.5mm upto 600 thick Ni Foil: less than 0.2mm thick Ni Plate: 600 or thicker	Bill of Lading Country of Origin Certificate (Original) Copy of Packing List indicating details of Sizes, quantity, weight, thickness etc. Manufacturer’s Mill Test Certificate certifying, Heat No, finish, Chemical Composition, Grade etc., Copy of Invoice	Generally it is 7-10 days if its in stock 15-20 days if its not in stock

Thickness of ASTM B162 nickel clad plate

3/16″	4.8mm
1/4″	6.3
3/8″	9.5
1/2″	12.7
5/8″	15.9
3/4″	19
1″	25.4
1 1/4″	31.8
1 1/2″	38.1
1 3/4″	44.5
2″	50.8
2 1/2″	63.5
3″	76.2

nickel alloy sheet thickness tolerance

Tolerance up to & under nominal thickness t (mm)
Width w (mm)	4.5<t <6.0	8.0<t <10.0	6.0<t <8.0	2.5<t <4.5	10.0<t <12.5	12.5<t <16.0	16.0<t <20.0	20.0<t <25.0	25.0<t <30.0	30<t <40.0
2700< w <3000	0.80	1.0	0.90		1.0	1.0	1.1	1.3	1.4	1.8
1200< w <1500	0.25	0.35	0.30	0.20	0.38	0.80	0.80	0.90	1.0	1.4
w < 1200	0.23	0.32	0.30	0.20	0.35	0.80	0.80	0.80	1.0	1.4
1500< w <1800	0.28	0.38	0.32	0.20	0.40	0.80	0.80	0.90	1.1	1.5
2100< w <2400	0.80	0.80	0.80		0.80	0.80	0.90	1.0	1.1	1.5
1800< w <2100	0.30	0.40	0.36	0.20	0.45	0.80	0.80	0.90	1.1	1.5
2400< w <2700	0.80	0.80	0.80		0.80	0.90	1.0	1.1	1.3	1.7

ASME SB162 nickel flat sheet mechanical properties

Tensile strength	Yield strength	Elongations	Melting point
450 MPa	515 MPa	45%	1453°C

nickel alloy shim equivalent material

Commercial trade name	ASTM	UNS code	China GB	EN code	Unified digital code
Nickel 200	B162	N02200	–	2.4066	–
Nickel 201	B162	N02201	–	2.4068	–
Monel k500 (SMC)	K500	N05500	–	2.4375	–
Monel 400 (SMC)	400	N04400	Ni68Cu28Fe	2.4360	–
Inconel 601(SMC)	601	N06601	1Cr23Ni60Fe13Al	2.4851	NS3103
Nicrofer 6025HT (VDM)	602	N06025	20Cr25Ni60Fe10AlY	2.4633	–
Inconel 600 (SMC)	600	N06600	1Cr15Ni75Fe	2.4816	NS3102
Inconel 625 (SMC)	625	N06625	0Cr20Ni65Mo10Nb4	2.4856	NS3306
Inconel 690 (SMC)	690	N06690	0Cr30Ni60Fe10	2.4642	NS3105
Inconel 617 (SMC)	617	N06617	–	2.4663	–
Hastelloy G35 (Haynes)	G35	N06035	0Cr33Ni55Mo8	2.4643	–
Incoloy 800H (SMC)	800H	N08810	1Cr20Ni32AlTi	1.4958	NS1102
Incoloy 800 (SMC)	800	N08800	0Cr20Ni32AlTi	1.4876	NS1101
Hastelloy C276 (Haynes)	C276	N10276	00Cr15Ni60Mo16W5Fe5	2.4819	NS3304
Incoloy 825 (SMC)	825	N08825	0Cr21Ni42Mo3Cu2Ti	2.4858	NS1402
Hastelloy C22 (Haynes)	C22	N06022	00Cr17Ni57Mo13W3	2.4602	NS3308
Hastelloy B2 (Haynes)	B2	N10665	00Ni70Mo28	2.4617	NS3202
Hastelloy G30 (Haynes)	G30	N06030	00Cr30Ni43Mo5.5W2.5Cu2Nb	2.4603	NS3404
Hastelloy C2000(Haynes)	C2000	N06200	–	2.4675	NS3405
Hastelloy B3 (Haynes)	B3	N10675	00Mo28Ni65Fe1.5Cr1.5	2.46	NS3203
Sanicro 28	alloy 28	N08028	00Cr27Ni31Mo3Cu	1.4563	–
Nicrofer 3127hMo (VDM)	alloy 31	N08031	00Cr27Ni31Mo7CuN	1.4562	NS1404
Incoloy 020 (SMC)	alloy 20	N08020	0Cr20Ni35Mo3Cu3Nb	2.466	NS1403
Hastelloy G3 (Haynes)	G3	N06985	00Cr22Ni48Mo7Cu2Nb	2.4619	NS3403
Inconel X750 (SMC)	X750	N07750	0Cr15Ni70Ti3AlNb	2.4669	GH4145

ASTM B162 nickel hot rolled plate chemical composition

Grade	Cu	Ni+Co	Si	C	Mn	S	Fe
Ni200	0.20	99.0	0.30	0.15	0.30	0.01	0.40
Ni201	≤0.25	99.0	≤0.35	≤0.02	≤0.35	≤0.01	≤0.40

Gauge chart of nickel cold rolled plate

Gauge	Nickel
Gauge	Gauge Decimal (inches)
30	0.0125
26	0.0187
24	0.0250
22	0.0312
20	0.0375
18	0.0500
16	0.0625
14	0.0781
12	0.1094
11	0.1250
10	0.1406
9	0.1562
8	0.1719

ASME SB162 nickel coil tolerances on length

	Nominal length (mm)	2,000 < L < 8,000	L < 2,000	L > 8,000
Tolerance(mm)	Plus	0.005 times L	10	40
Tolerance(mm)	Minus	0	0	0

Pure nickel plate tolerances on width

Tolerance (mm)
	Nominal length (mm)	1200 < w < 1500	w < 1200	w > 1500
Trimmed edge	Plus	5	3	5
Trimmed edge	Minus	0	0	0
Mill edge	Plus	20	20	20
Mill edge	Minus	0	0	0

Size chart of nickel rolling sheet

Nickel plate stocked sizes
Size (in mm)	Size (in inches)
3.40	0.134
3.18	0.125
4.75	0.187
3.96	0.156
7.92	0.312
6.35	0.250
12.7	0.500
9.53	0.375
15.9	0.600
22.2	0.875
19.1	0.750
25.4	1
76.2	3
31.8	1.250
28.6	1.125
38.1	1.500
50.8	2
44.5	1.750
63.5	2.500

Nickel alloy plate hs code

Material	HS code
Nickel alloy plate	75062000

ASTM B162 nickel plate weight chart

Gauge	Nickel
Gauge	Weight (lb/ft2)
30
26	0.756
24	1.008
22	1.26
20	1.512
18	2.016
16	2.52
14	3.15
12	4.41
11	5.04
10	5.67
9
8	6.93

Pure nickel strip dimension

KG P/M2	4.5	6.3	8.1	10.8	14.4	18.0	27.0	28.0
Dimension (mm)	0.5 X 1000 X 2000	0.7 X 1219 X 3048	0.9 X 1219 X 3048	1.2 X 1219 X 3048	1.6 X 1200 X 3048	2.0 X 1219 X 3048	3 X 1200 X 3000	3.18 X VARIOUS ANN
