ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers

    Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers
    • Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers
    • Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers
    • Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers
    • Buy cheap ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm from wholesalers

    ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Model Number : 2205
    Certification : ISO
    Price : 2100-5300 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    ASTM A240/240M UNS S32205 Stainless Steel Sheet Coil Duplex 3.0-16.0mm

    ASTM A240/240M UNS S32205 Duplex Stainless Steel Plate Thickness 3.0 - 16.0mm Custom Cutting SS Plate


    Specification of our 2205 duplex stainless steel plate


    Product Nameduplex 2205 Stainless Steel Plate/Sheet
    Technical StandardJIS,AISI, ASTM,GB,DIN,EN
    Steel Grade2205 / S32205 / S31803 / 1.4462
    TypeStainless steel sheet/ plate/coil
    ThicknessCold rolled:0.4~3.0mm
    Hot rolled:3mm~100mm
    Width1000mm 1219mm 1500mm 2000mm or custom cutting as request
    Lengthcustom as clients request
    SurfaceNO.1 2B or process other finishing
    QualityCertificateMill Test Certificate
    PackageWater proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
    Trade termFOB CIF CFR
    Loading portShanghai Port, China

    Alloy 2205 duplex stainless steel is an alloy developed from the initial Super Duplex Stainless Steel. It is supplied in the solution annealed condition.

    As a form of duplex stainless steel, alloy 2205 was designed as comprising 22% chromium, 3% molybdenum, and 5-6% nickel nitrogen. Alloy 2205 combines the desirable aspect of properties of both austenitic and ferritic grades. The high chromium, molybdenum and nitrogen mixture results in a Pitting Resistance Equivalent number (PREN) of 33-34, providing pitting and crevice corrosion resistance superior to Alloy 316L or Alloy 317L austenitic stainless steels in almost all corrosive media.

    As a result of its excellent corrosion properties, it is well-suited to environments containing chlorides and hydrogen sulphide, for use in oil and gas extraction from sour wells, in refineries and in process solutions contaminated with chlorides.

    It also has good erosion fatigue properties as well as lower thermal expansion and higher thermal conductivity than austenitic steels. The yield strength is about twice that of austenitic stainless steels, allowing a designer to save weight and make the alloy more cost-competitive when compared to Alloy 316L or Alloy 317L.


    Composition ranges for 2205 grade stainless steels

    GradeCMnSiPSCrMoNiN
    2205 (S31803)

    Min

    Max

    -

    0.030

    -

    2.00

    -

    1.00

    -

    0.030

    -

    0.020

    21.0

    23.0

    2.5

    3.5

    4.5

    6.5

    0.08

    0.20

    2205 (S32205)

    Min

    Max

    -

    0.030

    -

    2.00

    -

    1.00

    -

    0.030

    -

    0.020

    22.0

    23.0

    3.0

    3.5

    4.5

    6.5

    0.14

    0.20

    Mechanical properties of 2205 grade stainless steels

    GradeTensile Str
    (MPa) min
    Yield Strength
    0.2% Proof
    (MPa) min
    Elongation
    (% in 50mm) min
    Hardness
    Rockwell C (HR C)Brinell (HB)
    22056214482531 max293 max

    Grade specification comparisons for 2205 grade stainless steels


    GradeUNS
    No
    Old BritishEuronorm

    Swedish

    SS

    Japanese

    JIS

    BSEnNoName
    2205S31803 / S32205318S13-1.4462X2CrNiMoN22-5-32377SUS 329J3L

    Features of Duplex 2205 Stainless Steel

    • Higher strength than standard stainless steels
    • Higher corrosion resistance than Alloy 316L stainless steel in a wide variety of corrosive chemicals including sulphuric, phosphoric and nitric acids
    • Good resistance to pitting and crevice corrosion in seawater
    • High stress corrosion resistance
    • Lower thermal expansion than austenitic stainless steels
    • Higher thermal conductivity than austenitic stainless steels

    Applications of duplex 2205 stainless Plate

    • Process industry components in sulphuric acid, nitric acid, phosphoric acid, ethylene oxide, polypropylene & PVC production
    • Equipment handling organic & fatty acids, chemical storage, tankers, heat exchangers
    • Marine industry and shipbuilding propellers, shafts, rudders, shaft seals, pumps, bolts, fasteners, valves, instrumentation
    • Oil and chemical tankers
    • Oil & Gas industry pumps, valves, pipe, vessels, wellhead equipment, subsea equipment, separators, heat exchangers
    • Pollution control systems, effluent scrubbing, flue gas desulphurisation (FGD)
    • Waste water treatment, sour water purification
    • Pulp & paper industry applications such as pulp liquor heaters, bleach tower linings, digesters, brownstock washers
    • Food industry applications including brewery piping, evaporators, hot liquor tanks, presses
