    AISI 309 Stainless Steel Sheet 309S 0.6-16.0mm 1500mm 1219mm 1000mm

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Model Number : 309S
    Certification : ISO
    Price : 2100-5300 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    AISI 309 Stainless Steel Sheet 309S 0.6-16.0mm 1500mm 1219mm 1000mm

    AISI309 Stainless Steel Plate Alloy 309S Stainless Plate Thickness 0.6 - 16.0mm Cutsom Cutting

    Stainless steel 309 309S 310 310S grade:

    The 309 stainless steel has a higher corrosion resistance and strength compared to 304 stainless steel. This product is versatile and known for its high heat treatment capabilities.Great ductility, weldability, and high-temperature properties make 310 Stainless Steel the ideal choice for projects that require service at temperatures up to 1150 degrees Celsius. Grade 310 resists oxidation and is also used at temperatures up to 1040 degrees Celsius intermittently. Similar to other austenitic steel grades, toughness down to cryogenic temperatures is another feature of 310.


    AISI309 309S stainless steel plate Specification


    ItemDescription
    StandardASTM A240 / AISI / DIN / JIS / GB


    Grade
    201/202
    304/304L/304H/309S/310S/316L/316Ti/317L/321//S31803/S32205/904L
    409L/410S/420J1/J2/430 439 441 444 446
    Thickness0.3-6.0mm for cold sheet scope; 3.0-100mm for hot rolled scope
    Width&Length1000mm/1219mm/1500mm/1800mm/2000mm
    Length from cutting, as requirement
    SurfaceMill surface: 2B/BA/No.1
    Processing surface: 8k mirror/Hairline/No.4 Satin/Bead blast/Color etched
    ProtectionTransparent film/ Blue fulm/PVC film or laser film
    PackageStandard export package with metal pallet + angle bar protection +
    ProcessingEdging/Laser(Plasma/Water Jet) cutting/Leveling/Slitting

    Regular Size of our 309S Stainless Steel Plate in stock


    Thickness/mmSize 1 / mmSize 2 / mmSize 3 / mm
    0.6mm1000*2000mm1219*2438mm/
    0.8mm1000*2000mm1219*2438mm1500*3000mm
    1.0mm1000*2000mm1219*2438mm1500*3000mm
    1.2mm1000*2000mm1219*2438mm1500*3000mm
    1.5mm1000*2000mm1219*2438mm1500*3000mm
    2.0mm1000*2000mm1219*2438mm1500*3000mm
    2.5mm1000*2000mm1219*2438mm1500*3000mm
    3.0mm1000*2000mm1219*2438mm1500*6000mm
    4.0mm//1500*6000mm
    5.0mm//1500*6000mm
    6.0mm//1500*6000mm
    8.0mm//1500*6000mm
    10.0mm//1500*6000mm
    12.0mm//1500*6000mm
    14.0mm//1500*6000mm
    16.0mm//1500*6000mm

    Stainless steels are a family of iron based alloys that contain a minimum of 10.5% chromium (CR). The presence of chromium creates an invisible surface film that resists oxidation and makes the material passive or corrosion resistant (stainless). There are multiple families of stainless steel which are designed for various applications and uses. Stainless grades can be further modified to meet various processing, corrosion, temperature and strength conditions.

    About 309/309S Stainless Steel

    Type 309 (UNS S30900)
    Description
    Type 309 is a high temperature chromium nickel austenitic stainless steel that resists oxidation at temperatures up to 1900˚F in dry air at constant temperature. Under thermal cycling conditions this grade resists oxidation up to a temperature of approximately 1850˚F. Type 309 has good sulfidation resistance but low resistance to carburization and should not be used in highly carburizing atmospheres. Type 309 is non-magnetic in the annealed and cold worked conditions and is as resistant to corrosion as Type 304/304L.


    Chemical Composition of 309/309S Stainless Steel

    Element309
    Carbon0.20
    Chromium22.0-24.0
    Nickel12.0-15.0
    Manganese2.00
    Silicon0.75
    Phosphorus0.045
    Sulfur0.030


    Mechanical Properties of 309/309S Stainless Steel

    Property309
    Yield Strength, min. (ksi)30
    Tensile Strength, min. (ksi)75
    Elongation, min. (%)40
    Hardness, max. (Rb)95


    Physical properties of 309/309S stainless steel


    Property309
    Density, lb/in30.285
    Modulus of Elasticity, psi29.0 x 106
    Coefficient of Thermal Expansion, 68-212˚F, /˚F8.7 x 10-6
    Thermal Conductivity, Btu/ft hr ˚F9.0
    Specific Heat, Btu/lb ˚F0.12
    Electrical Resistivity, Microohm-in30.7

    Features

    • Corrosion Resistance: 309 stainless stands-up excellently in a range of atmospheric environments even when exposed to corrosive elements.
    • Heat Resistance: Can be hot worked at 1177C and then can be quenched rapidly.
    • Easy to weld by using fusion or resistance welding methods (preferably not oxyacetylene though).
    • Can be headed, upset, drawn, and stamped even though it has high work hardening rate.

    Applications
    The 309 can be applied to a range of applications including a variety of accessories and equipment such as boiler baffles, furnace components, oven linings, fire box sheets, and other high temperature containers.
    AISI309 309S stainless steel plate
