TISCO BAOSTEEL 316L Stainless Steel Plate SS Plate 0.4 - 80.0mm
1.4404 Stainless Steel
Type 316L is a variant of Type 316 and differs by having a lower
Carbon content as well as slightly lower yield and tensile
strengths. Type 316L offers improved weldability and also reduces
the possibility of lower corrosion resistance around welded areas.
1. Products Details
| Commodity | 300 Series 316 Stainless Steel Plate |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-3.0mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin,
Embossed,brush,No.4,HL,matt,pvc film,laser film. |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
2. Chemical Properties:
| C | Mn | Si | P | S | Cr | Mo | Ni | N |
316
(S31600) | 0.08
max | 2.0
max | 0.75
max | 0.045
max | 0.03
max | min: 16.0
max: 18.0 | min: 2.0
max: 3.0 | min: 10.0
max: 14.0 | 0.10
max |
316L
(S31603) | 0.03
max | 2.0
max | 0.75
max | 0.045
max | 0.03
max | min: 16.0
max: 18.0 | min: 2.0
max: 3.0 | min: 10.0
max: 14.0 | 0.10
max |
Mechanical Properties:
| Grade | Tensile Strength
ksi (min) | Yield Strength
0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness
(Rockwell B) MAX |
316
(S31600) | 75 | 30 | 40 | 217 | 95 |
316L
(S31603) | 70 | 25 | 40 | 217 | 95 |
3. 316L 316 316Ti PROCESSING OF Laser Cutting
And compared to traditional oxygen acetylene, such as plasma
cutting technology, laser cutting speed, narrow kerf width, small
heat affected zone, vertical degree good, trimming smooth kerf
edge, at the same time can be variety of laser cutting materials,
including carbon steel, stainless steel, alloy steel, wood,
plastic, rubber, cloth, quartz, ceramic, glass, composite
materials, etc.With the rapid development of market economy and the
progress of science and technology, laser cutting technology has
been widely used in automobile, machinery, electricity, hardware
and electrical appliances and other fields.
About Our Company
Our company is a professional stainless steel trading company
integrating sales, processing, distribution and storage. We always
carry out the "high efficiency, mutual benefit, service first"
business philosophy and service purpose, adhere to reasonable and
preferential prices, beyond customer expectations of service, to
provide the society with a variety of inexpensive quality stainless
steel products. The company specializes in the distribution of
domestic and imported cold and hot rolled stainless steel coils and
plates, operating steel types: 201, 202, 304, 321, 316L, 444, 409,
430,309S,310S and so on, the products come from shanxi tisco,
guangzhou lianzhong, zhangjiagang pohang, ningbo baoxin,
AvestaPolarit, Outokumpu; POSCO, etc., at the same time for
customers to open, grinding, slitting, shearing and other
processing. The company's products are widely used in: chemical
machinery, pharmaceutical machinery, food machinery, drying
equipment, environmental protection equipment, metallurgical
machinery, pressure vessels, kitchen equipment, etc.
