ASTM A240 317L Stainless Steel Plate and Sheet UNS S31703 Stainless
Steel 0.4 - 20.0mm SS Plate
Quick Detail
grade 317L stainless steel plate
size: 1500 x 3000mm 1500 x 6000mm thickness: 3.0mm - 120mm
Brand: TISCO BAOSTEEL AUTO KUMPO
high quality and fast deliver
317L stainless steel plate
| PRODUCTS | 317L stainless steel plate | Brand | TISCO BAOSTEEL |
size | 1500x3000mm
1500x6000mm
Or as required |
surface | original: NO.1
traetment: NO.4 mirror |
| thickness | 3.0-120mm | Certificate | SGS, BV |
Description of 317L stainless steel
| Material | 317L Stainless steel plate |
| Standard | AISI, ASTM, EN, GB, DIN, JIS |
| Technology | Cold Rolled Or Hot Rolled |
| Thickness | 0.4 - 20.0mm |
| Width | 1000mm 1219mm 1500mm (tolerances ±6.00mm) |
| The sizes or thicknesses of stainless steel coil can be customized,
if you need additional information, please don't hesitate to
contact us at any time. |
Feather and Applications
317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum
austenitic stainless steel. It with conventional chrome - nickel
austenitic stainless steel, such as, compared to 304 alloy has the
stronger ability of resistance to chemical corrosion. In addition,
compared with the conventional stainless steel, 317 l alloy has
higher ductility, resistance to stress corrosion performance,
compressive strength and resistance to high temperature
performance. It is a low carbon level or L level, this level has
during the welding and heat treatment process the sensitization
effect of resistance.
Specifications
Relative 316 l, 317 l steel has excellent water resistance and
resistance to SCC, used for Chemical ships, Chemical products, such
as Reactor should be high corrosion-resistant Chemical equipment.
SUS317L mechanical properties
| YS (Mpa) | TS (Mpa) | EL (%) | HV |
| >=176 | >=480 | >=40 | <=200 |
SUS317L chemical composition
| C | Mn | Si | P | S | Cr | Ni | Mo |
| <=0.030 | <=2.00 | <=1.00 | <=0.045 | <=0.030 | <= 18.0 ~ 20.0 | <= 11.0 ~ 15.0 | <=3.0 ~ 4.0 |
Density(g/cm3) : 7.93
Typical Applications - Stainless Steel 317L
- Flue gas desulfurization scrubber systems
- Chemical and petro-chemical processing equipment
- Pulp and paper plants
- Food processing equipment
- Textile equipment
Design Features - Stainless Steel 317L
- A molybdenum bearing austenitic chromium nickel steel with an alloy
content somewhat higher than the 316 grades.
- Superior corrosion resistance in difficult environments.
- Higher creep, stress-to-rupture and tensile strengths than other
stainless steels.
- Reduced intergranular precipitation of chromium carbides during
welding and stress relieving as well as minimized possibility of
corrosion failure from intergranular attack due to low carbon
content.
- Resistance to pitting and crevice corrosion making 317L a
successful life-cost product in a variety of highly corrosive
environments.
