Decorative 304 Stainless Steel Checker Plate 0.5-3mm

Ask Lasest Price
Brand Name :	TISCO
Model Number :	201 304 316L 2205 321.etc
Certification :	ISO
Price :	2400 - 3500 USD/Ton
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	10Ton per week
Delivery Time :	5 - 12 days based on the quantity
MOQ :	1 Ton

Add to Cart

Product Details
Company Profile

Decorative 304 Stainless Steel Checker Plate 0.5-3mm

Stainless Steel Checkered Plate 304 Decorative Stainless Steel Sheet 304 Checkered Plate 0.5-3mm

We are a leading manufacturer and supplier of Stainless Steel Diamond sheets/ Checker Sheets/ Embossed Sheets/Sheets/ Floor Sheets. We can provide different grades of stainless steel to meet various needs of all industrial purposes.

The stainless steel checker plate has a raised diamond lug pattern that provides excellent skid resistance for a wide range of applications. It has various styles with a strong three-dimensional effect. It has the excellent characteristics of anti-rust, no cracking, no scratching, no leakage, easy to clean. It’s an ideal choice for elevators and cabinet panels.

ASTM A240/JIS Standard 4304

3.1 MTC is available once order confirmed,all of our products are conformed with JIS G4304 and ASTM A240 standard.

ASTM A240

JIS 4304

ASTM A240 Chemical Standard

Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other


S30400	8.0~10.5	17.5~19.5	0.07	0.75	2	0.045	0.03	–	–	N: 0.1 Max.
S30403	8.0~12.0	17.5~19.5	0.03	0.75	2	0.045	0.03	–	–	N: 0.1 Max.
S31603	10.0~14.0	16.0~18.0	0.03	0.75	2	0.045	0.03	2.0~3.0	–	N: 0.1 Max.
S43000	0.75	16.0~18.0	0.12	1	1	0.04	0.03	–	–	–

Steel Grade	N/mm 2 MIN.	N/mm 2 MIN.	% MIN.	HRB MAX.	HBW MAX.	Bendability:	Bendability:


	Tensile Stress	Proof Stress	Elongation	Hardness	Hardness	Bending Angle	Inside Radius
S30400	515	205	40	92	201	No Require	–
S30403	485	170	40	92	201	No Require	–
S31603	485	170	40	95	217	No Require	–
S43000	450	205	22A	89	183	180°	–

Thickness	Width	Length	Surface Finish


15~85 mm	914, 1219, 1524 mm	3048, 6069 mm Max.10M	Black
3~8 mm	20~2000 mm	3048, 6069 mm Max.10M	No.1
8 up ~ 60 mm	30~2000 mm	Max. 6096 mm	No.1
0.23-3.0mm	30-1524-2000mm	Max. 10M	2B/No.4/HL/8K

Available Grade

Great Britain BS970	U.S.A AISI/SAE	Germany W-Nr Din	Italy UNI	Japan JIS	France AFNOR	Spain UNE


17/4PH	ASTM A564 Grade 630	50049 1.4542	–	–	Z7CNU 17-04	–
303S31	303	1.4305 X10CrNiS18-9	X10CrNiS1809	SUS303	Z8CNF 18-09	F.5308
304S11	304L	1.4307 1.4306 X10CrNiS18-9	X3CrNi1811 X2CrNi1811	SCS19 SUS304L	Z1CN18-12 Z2CN18-10	F.3503
304S15	304	1.4301 X5CrNi1810	X5CrNi1810	SUS304	Z4CN19-10FF Z5CN17-08	F.3504
316S31	316	X5CrNiMo17133	X5CrNiMo1713 X8CrNiMo1713	SUS316	Z6CND18-12-03	–
316S11	316L	1.4404 X2CrNiMo17132	X2CrNiMo1713 X8CrNiMo1713	SUS316L	Z2CND17-12 Z2CND18-13	F.3533 F.3537
321S31	321	1.4541 X6CrNiTi18-10	X6CrNiTi1811	SUS321	Z6CNT18-10	F.3523
310	310 310S	1.4845 X12CrNi25-21	X6CrNi2521	SUH310 SUS310S	Z8CN25-20 Z12CN25-20	–
416S21	416	1.4005 X12CrS13	X12CrS13	SUS416	Z11CF13	F.3411
420S29	–	1.4024 X15Cr13	–	SUS410J1	Z13C13	F.3415
