Zinc Coated Galvanized Steel Coil Z30-Z275 Oiled Surface Treatment

Ask Lasest Price
Brand Name :	BAOSTEEL WISCO
Model Number :	DX51D SGCC
Certification :	ISO
Price :	600-860 USD/Ton
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

Zinc Coated Galvanized Steel Coil Z30-Z275 Oiled Surface Treatment

Oiled Sueface Treatment Zinc Coated Metal with Galvanized Steel Coil Z30-Z275g

Specification of our products

Products Name	Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet
Thickness	Galvanized steel sheet 0.12 - 3.0mm Thickness
	Galvalume Steel Sheet 0.25 - 3.0mm Thickness
	Prepainted Galvanized Steel Sheet 0.12 - 1.2mm Thickness
Width	914mm,1000mm,1200mm,1219mm,1220mm,1250mm Or According To Customer's Requirement
Length	Custom length as customer requirement
Coil Weight	2Ton - 8 Tons
Coil Inner Diameter	508mm or 610mm
Surface	Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275
	Galvalume Steel Sheet : AZ40 - AZ180
	Prepainted Galvanized Steel Sheet:Painting Type:PE,HDP,SMP,PVDF
Standard	AISI, ASTM, BS, DIN, GB, JIS, AS ETC

Galvanized Steel Coil

We are a leading supplier of galvanized steel sheet & coil. Galvanized steel is defined as a carbon steel sheet coated with zinc on both sides. There are two main processes used to produce galvanized steel: continuous hot dipping and electro-galvanizing.

The hot dipping process consists of passing the steel through a bath of molten zinc, while the electro-galvanizing process consists of the application of zinc through electrolytic disposition. The result is a layer of zinc tightly adhering to the base metal through an iron-zinc bonding layer. Our hot dipped galvanized products are manufactured to ASTM A653 specifications; our electro galvanized products conform to ASTM A879 specifications.

A zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.

Galvanized Steel Sheet & Coil Material Types

Commercial Steel (CS Types A, B, and C)
Forming Steel (FS Types A and B)
Deep Drawing Steel (DDS Types A and C)
Extra Deep Drawing Steel (EDDS)
Structural Steel (SS) – further designated by Grades (33,37,40,50,80)
High Strength Low Alloy Steel (HSLAS)

Galvanized Steel Coil Size Chart

Product-Coated: Hot Dipped Galvanized | ASTM:A653 | Grade: CS-B | Surface:Min Spangle | Treatment: CT-DryG6028GA (.0217 MAX - .0157 MIN)364860G3030GA (.0187 MAX - .0127 MIN)3648***

Coating	Thickness	Width	Width	Width
G90	10GA (.1472 MAX - .1292 MIN)	***	48	60
	11GA (.1323 MAX - .1143 Min)	***	48	60
	12GA (.1174 MAX - .0994 MIN)	***	48	60
	13GA (.1014 MAX - .0854 MIN)	***	48	60
	14GA (.0865 MAX - .0705 MIN)	36	48	60
	16GA (.0696 MAX - .0575 MIN)	36	48	60
	18GA (.0566 MAX - .0466 MIN)	36	48	60
	20GA (.0506 MAX - .0356 MIN)	36	48	60
	22GA (.0436 MAX - .0296 MIN)	36	48	60
	24GA (.0316 MAX - .0236 MIN)	36	48	60
	26GA (.0247 MAX - .0187 MIN)	36	48	60

Additionally, the Hot Dipped Galvanized and the Galvannealed products are available in a variety of coating weights including G-90, G-60, G-40, and G-30 for the Hot Dipped Galvanized products, and A-60 and A-40 for the Galvannealed products.

At Curtis Steel, we also offer two different finishes on our 26 & 28 gauge galvanized steel sheet & coils.

Regular Spangle

Zero Spangle

Typical Galvanized Steel Sheets & Coil Applications:

Exterior building products
Ductwork
HVAC products
Flashing
Electrical boxes and other electrical products
Roofing
Doors
Sashes

Automotive parts
Appliances
Commercial and residential steel framing
Parking lots
Truss plates
Metal building purlins
Any other products requiring a corrosion resistant material
