Stainless Steel 302 SS Sheet Plate Cold Rolled 302 Stainless Steel
Sheet UNS S30200
| Product Name | Stainless Steel Sheet & Plate |
| Thinckness | Cold rolled:0.3mm-3mm Hot rolled: 3.0mm-80mm |
| Standard Size | Cold Rolled 1000*2000mm 1219*2438mm 1500*3000mm |
| Hot Rolled 1500*6000mm 1800*6000mm 2000*6000mm |
| Service | Cutting (laser cutting, plasma cutting, cutting machine), Bending |
| Surface Service | Raw finishing (2B NO.1) Finishing(HL 8K Checkered.etc) |
| Standard | ASTM, AISI, DIN, EN, GB, JIS |
| Mainly Grade | 200 series: 201, 202 300 series: 301302 304 309S 310S 316L 316Ti 317L 321 347 400 series: 409, 409L, 410, 420, 430, 431, 439,441 , 443 , 444
Special grade: duplex 2205 2507 , 904L 254SMO 253MA 17-4PH
Nickel Alloy : C276 C4 Monel400 500 600 625 800 825.etc |
| Brand | TISCO BAOSTEEL ZPSS LISCO JISCO |
| Application range | Decoration, Industry ,Kitchenwave ,Building, Elevator |
The grade 302 stainless is a slightly higher carbon version than
grade 304 alloy that is widely found in strip and wire forms. This
product is a standard specification for chromium and
chromium-nickel stainless steel sheet, plate, and strip used for
pressure vessels as well as for general applications.
Alloy 302 is a variations of the 18% chromium / 8% nickel
austenitic alloy, which is the most familiar and the most
frequently used in the stainless steel family. Alloy 302 is a
slightly higher carbon version of 304, often found in strip and
wire forms. It is a tough, ductile grade that demonstrates
comparable corrosion resistance, is non-magnetic, and is not
hardenable by heat treatment. Alloy 302 is usually used in its
annealed condition and has a high ease of fabrication and
formability.
Chemical Properties of 302 stainless steel sheet
| C | Mn | Si | P | S | Cr | Ni | N |
|---|
| 302 | max: 0.15 | max:2.0 | max: 0.75 | max: 0.045 | max: 0.03 | min: 17.0 max: 19.0 | min: 8.0 max: 10.0 | max: 0.10 |
Mechanical Properties of 302 Stainless Steel Sheet
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell B) MAX |
|---|
| 302 | 75 | 30 | 40 | 92 |
Inventory
302 Stainless Steel Sheet, 302 SS Sheet
Common Trade names
302 Stainless, 302 Stainless Steel
Features
- Easy to weld with excellent weldability capabilities.
- Excellent strength and toughness in high temperatures.
APPLICATION OF 302 STAINLESS STEEL SHEET
Although many applications have shifted to 304 and 304L due to
advances in melting technology, availability, and cost, Alloy 302
is still used in a variety of industries. Some examples include:
- Stamping
- Spinning
- Wire forming
- Formed into all types of washers, springs, screens, and cables
- Food and beverage industry
- Pressure containing applications
- Sanitary or cryogenic applications
