Uns N04400 Nickel Cooper Monel 400 Plate Nickel Based Alloy Plate /
Sheet
Products Specification
| Product Name | Nickel Alloy Plate & Sheet |
| Thinckness | Cold rolled:0.3mm-3mm Hot rolled: 3.0mm-30mm |
| Standard Size | Cold Rolled 1000*2000mm 1219*2438mm 1500*3000mm |
| Hot Rolled 1500*6000mm 1800*6000mm 2000*6000mm |
| Service | Cutting (laser cutting, plasma cutting, cutting machine), Bending,
forged produce |
| Surface Service | Raw finishing (2B NO.1) Finishing(HL 8K Checkered.etc) |
| Standard | ASTM, AISI, DIN, EN, GB, JIS |
| Mainly Grade | ASTM Grade: Incoloy 800 / 800H ,Incoloy 825,Inconel 600 , Inconel
625 , Inconel690,Hastelloy B , Hastelloy B-2 , Hastelloy C276 ,
Hastelloy C4, Hastelloy C2000,
ASME Grade: N08800 N08810 N08825 N06600 N06601 N06690 N10001 N10665
N10276 N06455 N06625
EN 1.4588 2.4858 2.4817 2.4642 2.4617 2.4819 2.461 2.4856 |
| Brand | TISCO BAOSTEEL ZPSS LISCO JISCO |
1. Monel 400 Plates, Sheets & Coils
ASTM B127 Monel UNS No. N04400 / 5500 Chequered Plate, Shim Sheet &
Coils, Circles Suppliers.
We are Manufacturers, Supplier and Exporters of Monel Plates,
Sheets & Coils that are using high quality raw materials in Mumbai,
India. We also offer a wide range of Monel 400, Monel K500 Plates,
Sheets & Coils as per the clients requirements. These Monel sheets,
plates and coils are manufactured in national & international
standards. These are widely used in various application industry
like Chemicals, Fats, & Fertilizers, Sugar Mills & Distilleries,
Cement Industries, Ship Builders, Paper Industries etc. We are
offering these plates, sheets & coils in below mentioned technical
specifications.
2. Monel 400 Plates, Sheets & Coils Specification :
| Products | Monel 400 Alloy Plate & Sheet |
| Standards | ASTM GB DIN EN JIS |
| Type | Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring
etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8),
SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle),
Ring (Flange) etc. |
| Grades | Monel 400 Plates, Sheets & Coils - UNS N04400, Monel K500 Plates,
Sheets & Coils - UNS N05500 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NU-30M | NA 13 | МНЖМц 28-2,5-1,5 | NiCu30Fe |
| Monel K500 | 2.4375 | N05500 | - | - | - | - | - |
Chemical Properties of ALLOY 400 (UNS N04400)
| C | MN | P | S | Si | Cr | Ni | Mo | Cu | Co | Cb+Ta | Fe | other |
| .3 max | 2.0 max | .02 max | . 024 max | .5 max | | 63.0 max | | 28-34 max | | | 2.5 max | |
Mechanical Properties Of Monel Alloy 400 Plates :
| Condition | Tensile (ksi) | .2% Yield (ksi) | Elongation (%) | Hardness (HRB) |
| Annealed | 70-85 | 28-50 | 50-35 | 60-76 |
Stock Informations of our Monel 400 Products
| Products | Size | Type | Note |
| Monel 400 Sheet & Plate | 0.6 - 3.0mm x 1219 x 2438mm
4.0 - 20.0mm x 1500 x 6000mm | cold rolled
hot rolled | Laser cutting service |
| Monel 400 bar | Diameter 6 - 50mm x 6m length
Diameter 12 - 250mm x 6m Length | Bright Bar
Black Bar | Cutting any length |
| Monel 400 Pipe | DN6-DN300 x SCH10-SCH160 | Seamless pipe | Cutting as request |
| Monel 400 Strip | 0.6 - 3.0mm x Width 10 - 1219mm x C | slit cutting | any size as request |
