    High Hardness ASME Stainless Steel Plate Hot Rolled 420 440C 17 - 4PH 17 - 7PH

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Model Number : 201 304 316L 321 310S 347 410 420 430 431.etc
    Certification : ISO
    Price : 2100-5300 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    High Hardness ASME Stainless Steel Plate Hot Rolled 420 440C 17 - 4PH 17 - 7PH

    Hot Rolled High Hardness Stainless Steel Plate Grade 420 440C 17-4PH 17-7PH SS Plate

    Our Stainless Steel Sheet Specification Chart

    DescriptionASTM A240 / ASME SA240 Stainless Steel Plates, ASTM A240 Hot Rolled Stainless Steel Plates
    StandardASTM, ASME, BS, DIN, EN
    Material310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L,
    302, 301, 201, 202, 403, 405, 409, 409L, 410, 410S, 420, 430, 631, 904L, Duplex, etc
    SpecificationCold rolled: 1219mm * 2438mm (4′ x 8′), 1219mm * 3048mm (4′ x 10′), 1220mm * 2440mm, 1250mm * 2500mm or as your requirement.

    Hot rolled: 1500mm * 2000mm, 1000mm * 3000mm, 1500mm * 4000mm, 1500m * 6000mm or as your requiremnt.

    TechniqueHot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
    FormShim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Etc.
    Surface2B, 2D, BA, NO. 1, NO. 4, NO.8, 8K, Mirror, Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
    ServiceLaser Cutting, Water Cutting, Fire Cutting, Bending
    Thickness0.25-200mm, 0.3mm to 120mm
    Width1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm
    Length2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm
    PackageStandard Export Seaworthy Package, or as required.
    Value Added ServicesCladding,Heat Treatment,Annealed, Pickling, Polish,Rolling,Cutting,Bending,Forging,Minor Fabrication Etc.
    MTCMill Test Certificate, Available as per EN 10204 3.1

    Stainless steel coil plate – ASTM A240M
    The most efficient route for a stainless steel production mill to produce plate (5mm and over) is in coil form. The coil is then further downstream processed by the mill or through a service centre with equipment to flatten (often called ‘levelling’) and cut to length.

    The maximum plate width produced by mills from coil is 2000mm and the maximum thickness is 13mm for hot rolled and 8mm for cold rolled.

    GradeThickness (mm)Coil width (mm)Finish
    304/304L5.015002B
    316/316L6.02000No. 1
    304/304L8.01500No. 1
    316/316L10.02000
    12.0
    3CR125.01250No. 1

    Stainless steel quarto plate products – ASTM Aa240M
    Another method of producing stainless steel plate within and beyond the thickness range of coil production is from a slab of steel that is rolled in the flat condition to a specified length, width and thickness. The product of this process is commonly referred to as quarto plate and is available from mills in thickness from 5mm and above and widths to 4000mm in some thicknesses.

    The standard grades and thickness for quarto plate are as follows:

    Grades304/304L, 316/316L, 3CR12.
    Thickness (mm)5.0, 6.0, 8.0, 10.0, 12.0, 16.0 & 20.0.
    Width (mm)1500 & 2000.
    Length (mm)6000.
    FinishNo. 1 (HRAP).

    Quarto plate is commonly stocked as a dual certified grade, i.e. 304/304L and 316/316L.

    Stainless steel chequer (floor) plate

    Grades304.
    Thickness (mm)3.18 & 4.76 .
    Width (mm)1219 & 1250.
    Length (mm)2438.
