SS316L Seamless Stainless Steel Hollow Tube Pipe ASTM EN DIN JIS 40mm

Ask Lasest Price
Brand Name :	DELTA
Model Number :	304 316L 321 310S 314 347 2205 2507 904L.etc
Certification :	ISO
Price :	2400 - 3500 USD/Ton
Payment Terms :	T/T, Western Union, L/C
Supply Ability :	10 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

SS316L Seamless Stainless Steel Hollow Tube Pipe ASTM EN DIN JIS 40mm

SS316L Stainless Steel Pipe ASTM EN DIN JIS GB Standard Seamless Stainless Steel Hollow Tube

Product Name	Stainless steel pipe
Standard	ASTM AISI DIN,EN, GB JIS
Steel Grade	200 Series: 201,202 300 Series: 301.304.304L,316,316L316Ti,317L.321.309s,310s 400 Series: 409L410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L2205,2507,21012520,2304
Outer Diameter	6-600mm(as required)
Thickness	0.3mm-40mm (as required)
Length	2000mm/2500mm/3000mm/6000mm/12000mm(as required)
Technique	Welded,Seamless
Surface	pickling / polished
Tolerance	土1%
Price Terms	FOB.CFR.CIF

STOCK SIZE RANGE AND SPECIFICATIONS:

WELDED PRODUCT	SEAMLESS PRODUCT
NPS: 1/8” through 24”	NPS: 1/8” through 8”
Schedules: 5, 10S, 10, 30, 40S, 40, 80, 80S	Schedules: 10, 40, 80, 160, XXH
Specifications: ASTM A312, ASME SA312	Specifications: ASTM A312,ASME SA312

316 / 316L STAINLESS STEEL PIPE

These grades of austenitic stainless steels are similar to 304 and 304L, but with the addition of molybdenum. The addition of molybdenum improves the alloys corrosion resistance, particularly with higher resistance to pitting and crevice corrosion in chloride environments. The austenitic structure allows excellent toughness, even down to cryogenic temperatures. These grades have excellent weld-ability, with or without the addition of filler metal.

Corrosion tested to MIL-P-24691/3 or A262 Practice E

**Typical Chemical Composition % (max values, unless noted)**
Weight %	C	Mn	P	S	Si	Cr	Ni	Mo
316	.08	2.00	.045	.030	1.00	16.0-18.0	11.0-14.0	2.0-3.0
316L	.035	2.00	.045	.030	1.00	16.0-18.0	10.0-14.0	2.0-3.0

**Typical Mechanical Properties**
Grade	Tensile
	Ultimate/Min		Yield/Min		Elongation/Min
	KSI	MPA	KSI	MPA	%
316	75	515	30	205	35
316L	70	485	25	170	35
