317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers

    Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers
    • Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers
    • Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers
    • Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers
    • Buy cheap 317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod from wholesalers

    317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19
    Certification : ISO
    Price : 2400 - 3500 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod

    317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod

    ProductsStainless Steel Bar
    Grade317L
    Diameter5 - 350mm
    Length6m or custom cutting any length as request
    FinishingBright Bar / Black Surface
    Heat TreatmentSolid Solution , ageing
    Surface ProcessPolishing , Peeling
    Other Grade

    201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431

    2205 2507 904L 254SMO 416 440A/B/C.etc

    MOQ500 Kgs
    Loading PortShanghai Port
    ProcessingCutting
    PackingWooden box or cutting as request

    Alloy 317L (UNS S31703) is a molybdenum-bearing austenitic stainless steel with greatly increased resistance to chemical attack as compared to the conventional chromium-nickel austenitic stainless steels such as Alloy 304. In addition, Alloy 317L offers higher creep, stress-to-rupture, and tensile strength at elevated temperatures than conventional stainless steels. It is a low carbon or "L" grade which provides resistance to sensitization during welding and other thermal processes.


    Alloy 317L (UNS S31703) is a lowcarbon corrosion resistant austenitic chromium-nickel-molybdenum stainless steel. The high levels of these elements assure the alloy has superior chloride pitting and general corrosion resistance to the conventional 304/304L and 316/316L grades. The alloy provides improved resistance relative to 316L in strongly corrosive environments containing sulfurous media, chlorides, and other halides.

    The low carbon content of Alloy 317L enables it to be welded without intergranular corrosion resulting from chromium carbide precipitation enabling it to be used in the as-welded condition. With the addition of nitrogen as a strengthening agent, the alloy can be dual certified as Alloy 317 (UNS S31700).

    Alloy 317L is non-magnetic in the annealed condition. It cannot be hardened by heat treatment, however the material will harden due to cold working. Alloy 317L can be easily welded and processed by standard shop fabrication practices.

    Chemical Composition of 317L Stainless Steel

    NiCrMoMnSiCNSPFe
    11.0 - 15.0
    18.0 - 20.0
    3.0 - 4.0
    2.0 Max
    .75 Max
    0.03 Max
    0.1 Max
    0.03 Max
    0.045 Max
    Balance

    Mechanical Properties of 317L Stainless Steel

    Minimum Specified Properties, ASTM A276

    Ultimate Tensile Strength, ksi Minimum.2% Yield Strength, ksi MinimumElongation PercentHardness Max.
    75
    30
    35
    217 Brinell

    What are the characteristics of 317L Stainless?

    • Improved general and localized corrosion to 316L stainless
    • Good formability
    • Good weldability

    Forms of 317L Stainless Steel Available at Mega Mex

    • Sheet
    • Plate
    • Bar
    • Pipe & Tube (welded & seamless)
    • Fittings
      • Elbows, tees, stub-ends, returns, caps, crosses, reducers, pipe nipples, etc.
    • Weld Wire (AWS E317L-16, ER317L)

    Applications

    • Air Pollution Control — flue gas desulfurization systems (FGD)
    • Chemical and Petrochemical Processing
    • Explosives
    • Food and Beverage Processing
    • Petroleum Refining
    • Power Generation — condensers
    • Pulp and Paper

    317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod317L Stainless Steel Bar ASTM A276 Hot Rolled Cold Drawn Bright Polished Stainless Rod
