ASTM A790 Stainless Steel Pipe S31803 / S32750 / S32760 SS Tubing

ASTM A790 Stainless Steel Pipe Grade S31803 / S32750 / S32760 SS Pipe Tubing

Name	stainless steel pipe
Standard	ASTM, GB, JIS, DIN, EN, AISI
Material Grade	TP304 TP304L TP316 TP316L TP347 TP347H TP321 TP321H TP310 TP310S
	TP410 TP410S 17-4PH 254SMO 253MA
	S31803/S32205 S32750 S32760
Outer Diameter	Seamless Pipe: 4mm-812.80mm
Outer Diameter	Welded Pipe: single slit(Φ8mm-Φ630mm); girth(Φ630mm-Φ3000mm),
Thickness	Seamless Pipe: 0.5mm - 60mm
Thickness	Welded Pipe: single slit(0.5mm-25mm);girth(3mm-45mm)
Length	5.8-6.1 m or as customers' request
Tolerance	Acording to the Standard.
Surface	180G, 320G, 400G Satin / Hairline
Surface	400G, 500G, 600G or 800G Mirror finish
Test	UT, ET, HT, RT,ect, and others according to the standard,or as the requests of the customers
Certificate	ISO9001-2008,ASME, PED
Delivery Time	7-30 Days, Depends on quantity

Duplex Stainless Steel Pipe Specification

Standard Item	ASTM A789		ASTM A790		EN 10216-5
Grade	S31803 S32205 S32750		S31803 S32205 S32750		1.4301 1.4307 1.4948 1.4315 1.4401 1.4404 1.4571 1.4541 1.4941 1.4845 1.4449 1.4438 1.4550 1.4912 1.4462 1.4410
Yield Strength (Mpa)	≥450；≥485；≥550		≥450；≥450；≥550		---
Tensile Strength (Mpa)	≥620；≥655；≥800		≥620；≥655；≥800		---
Elongation(%)	≥25；≥25；≥15		≥25；≥25；≥15		---
Hydrostatic Test					The hydrostatic test shall be carried out at a test pressure of 7MPa or at a test pressure calculated using the following formula P=2St/D S=70%Rp0.2
Intergranular Corrosion Test	Usually use Pitting Corrosion Test.		Usually use Pitting Corrosion Test.		EN ISO 3651-2 (Optional)
Eddy Current Test	Could be replaced by HT.		Could be replaced by HT.		EN 10246-3
O.D. Tolerance (mm)	O.D.	O.D.Tolerance	O.D.	O.D.Tolerance	O.D. Tolerance Class
	D<12.7	+/-0.13	10.3≤D≤48.3	+0.40/-0.80	D3	+/-0.75% or +/-0.3mm
	12.7≤D<38.1	+/-0.13	48.3<D≤114.3	+0.80/-0.80
					whichever is the greater
	38.1≤D<88.9	+/-0.25	114.3<D≤219.1	+1.60/-0.80	D4	+/-0.5% or +/-0.1mm
	88.9≤D<139.7	+/-0.38	219.1<D≤457.0	+2.40/-0.80
					whichever is the greater
W.T. Tolerance (mm)	O.D.	W.T.Tolerance	O.D.	W.T.Tolerance	W.T. Tolerance Class
	D<12.7	+/-15%	10.3≤D≤73.0	+20.0%/-12.5%	T3	+/-10% or +/-0.2mm
	12.7≤D<38.1	+/-10%
			88.9≤D≤457.0 t/D ≤5%	+22.5%/-12.5%	whichever is the greater
	38.1≤D<88.9	+/-10%			T4	+/-7.5% or +/-0.15mm
			88.9≤D≤457.0 t/D >5%	+15.0%/-12.5%
	88.9≤D<139.7	+/-10%
					whichever is the greater

ASTM A789 / ASME SA789 covers grades of average wall thickness, or, if specified on the order, minimum wall thickness, of stainless steel tubing for services requiring general corrosion resistance, with particular emphasis on resistance to stress corrosion cracking. These steels are suscep- tible to embrittlement if used for prolonged periods at elevated temperatures.

The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard. Within the text, the SI units are shown in brackets. The inch-pound units shall apply unless the M designation of this specification is specified in the order.

Ordering Information

Orders for product under this specification should in- clude the following, as required, to describe the desired material adequately:
Quantity (feet, metres, or number of lengths),
Name of product (seamless or welded tubes),
Grade
Size (outside diameter and average wall thickness, unless minimum wall thickness is specified),
Length (specific or random),
Optional requirements (for product analysis, see Section for hydrostatic or nondestructive electric test, see Section 10
Test report required (see the Inspection section of Specification A1016/A1016M
Specification designation, and
Special requirements.

ASTM A789 Duplex Steel Chemical Composition

The steel shall conform to the chemical requirements prescribed in Table 1.

UNS
Designation	C	Mn	P	S	Si	Ni	Cr	Mo	N	Cu	Others
S31200	0.030	2.00	0.045	0.030	1.00	5.5–6.5	24.0–26.0	1.20–2.00	0.14–0.20	. . .	. . .
S31260	0.030	1.00	0.030	0.030	0.75	5.5–7.5	24.0–26.0	2.5–3.5	0.10–0.30	0.20 –0.80	W 0.10 –0.50
S31500	0.030	1.20 –2.00	0.030	0.030	1.40 –2.00	4.3–5.2	18.0–19.0	2.50–3.00	0.05–0.1	. . .	. . .
S31803	0.030	2.00	0.030	0.020	1.00	4.5–6.5	21.0–23.0	2.5–3.5	0.08–0.20	. . .	. . .
S32001	0.030	4.00 –6.00	0.040	0.030	1.00	1.0–3.0	19.5–21.5	0.60	0.05–0.17	1.00	. . .
S32003	0.030	2.00	0.030	0.020	1.00	3.0-4.0	19.5-22.5	1.50-2.00	0.14-0.20	. . .	. . .
S32101	0.040	4.0-6.0	0.040	0.030	1.00	1.35-1.70	21.0-22.0	0.10-0.80	0.20-0.25	0.10 -0.80	. . .
S32202	0.030	2.00	0.040	0.010	1.00	1.00–2.80	21.5–24.0	0.45	0.18–0.26	. . .	. . .
S32205	0.030	2.00	0.030	0.020	1.00	4.5–6.5	22.0–23.0	3.0–3.5	0.14–0.20	. . .	. . .
S32304	0.030	2.50	0.040	0.040	1.00	3.0–5.5	21.5–24.5	0.05–0.60	0.05–0.20	0.05 –0.60	. . .
S32506	0.030	1.00	0.040	0.015	0.90	5.5–7.2	24.0–26.0	3.0–3.5	0.08–0.20	. . .	W 0.05 –0.30
S32520	0.030	1.50	0.035	0.020	0.80	5.5–8.0	23.0–25.0	3.–5.	0.20–0.35	0.50 –3.00	. . .
S32550	0.04	1.50	0.040	0.030	1.00	4.5–6.5	24.0–27.0	2.9–3.9	0.10–0.25	1.50 –2.50	. . .
S32707	0.030	1.50	0.035	0.010	0.50	5.5–9.5	26.0–29.0	4.0–5.0	0.30–0.50	1.0 max	Co 0.5 –2.0
S32750	0.030	1.20	0.035	0.020	0.80	6.0–8.0	24.0–26.0	3.0–5.0	0.24–0.32	0.50	. . .
S32760	0.030	1.00	0.030	0.010	1.00	6.0–8.0	24.0–26.0	3.0–4.0	0.20–0.30	0.50 –1.00	W 0.50 –1.00
S32808	0.030	1.10	0.030	0.010	0.50	7.0–8.2	27.0–27.9	0.80–1.20	0.30–0.40	. . .	W 2.10 –2.50
S32900	0.08	1.00	0.040	0.030	0.75	2.5–5.0	23.0–28.0	1.00–2.00	. . .	. . .	. . .
S32906	0.030	0.80 –1.50	0.030	0.030	0.80	5.8–7.5	28.0 –30.0	1.50–2.60	0.30–0.40	0.80	. . .
S32950	0.030	2.00	0.035	0.010	0.60	3.5–5.2	26.0–29.0	1.00–2.50	0.15–0.35	. . .	. . .
S33207	0.030	1.50	0.035	0.010	0.80	6.0–9.0	29.0–33.0	3.0–5.0	0.40–0.60	1.0	. . .
S39274	0.030	1.00	0.030	0.020	0.80	6.0–8.0	24.0–26.0	2.5–3.5	0.24–0.32	0.20 –0.80	W 1.50 –2.50
S39277	0.025	0.80	0.025	0.002	0.80	6.5–8.0	24.0–26.0	3.00–4.00	0.23–0.33	1.20 –2.00	W 0.80 –1.21
S82011	0.030	2.0 –3.0	0.040	0.020	1.00	1.00–2.00	20.5–23.5	0.10–1.00	0.15–0.27	0.50	. . .
S82441	0.030	2.50 –4.00	0.035	0.005	0.70	3.0–4.5	23.0–25.0	1.00–2.00	0.20–0.30	0.10 –0.80
