| Seamless Stainless Steel Heat Exchanger Tube Standard | ASTM A213/ ASME SA 213, ASTM A269 / ASME SA 269, ASTM A789/ ASME SA
789 / ASTM A268/ ASME SA 268 |
| Welded Stainless Steel Heat Exchanger Tube Standard | ASTM A249/ ASME SA 249, ASTM A269/ ASME SA 269, ASTM A789/ ASME SA
789 |
| Stainless Steel Heat Exchanger Tubes grades | TP304 / 304L, TP316, TP316L, TP 309S, TP310S, TP321, TP321H, TP347,
TP347 H, Duplex 2205 / S31803 |
| Delivery Condition | Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold
Drawn, MF |
| Size Range | 6.53 to127 mm |
| Length | up to 20 m (65.62 ft) or Custom as required |
| Stainless Steel Heat Exchanger Tubes Bending radii | 1.25 x OD up to 1700mm |
| Wall Thickness Range | 0.5 - 5 mm |
| Tolerance | +/-0.05 Mm |
| Value Added Services for Stainless Steel Heat Exchanger Tubes | - Cutting
- Beveling
- Threading
- Polishing (Electro & Commercial)
- Draw & Expansion as per required Size & Length
- Destructive and Non Destructive
- Ultrasonic Testing
- Annealed & Pickled Bending
|
| END | Plain End, Beveled End, Treaded |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting, Moulding |
| Technique | Cold drawn, Cold rolled, Hot rolled, Extrusion Tube manufacturer in
India |
| Marking on Stainless Steel Heat Exchanger Tubes | - Specification
- Material Grade
- Nominal Size
- Schedule or Wall Thickness
- Method of Manufacturing (Seamless / Welded)
- Heat Number
- Manufacturer’s Name or Custom Logo - on request
|
| SS Heat Exchanger Tubes Test Certificate | - DFARS compliant
- EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test
Certificates (MTC)
- 100% Radiography Test Report
- Raw Materials Certificate
- Third Party Inspection Report
- Fumigation Certificates
- Heat Treatment Charts
- HS Code Commercial Invoice
- Form A for Generalized System of Preferences (GSP)
- Manufacturer Test Certificate
- Moisture testing
- Surface roughness measurement
- Laboratory Test Certificate from Govt. Approved Lab
|
| Packaging | Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or
Standard seaworthy export packing or as per customers' request |
| Port | Mumbai, India |
| Uses & Application | - Heat Exchanger
- Boiler
- Condenser
- Cooling, Heating
- Air-conditioning industry
- Coolers
- Solar industry
- Water heater industry
|
| Manufacturer of | - Stainless Steel Condenser Tubes
- Titanium Heat Exchanger Tubes
|
