    ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 201 304 316L 321 310S 314 347 2205 2507 904L.etc
    Certification : ISO
    Price : 2400 - 3500 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area

    ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area

    Products Specification


    StandardASTM A213, ASTM A269, ASME SA213, ASME SA269
    Pipe TypeBright Annealed Stainless Steel Tubing
    Grades304, 304L, 316, 316L, 321, 310S, 2205, 2507
    DimensionsOuter Diameter (OD): 1.00 mm to 76.2 mm
    Wall Thickness0.2 mm to 6.0 mm
    LengthUp to 12 meters (custom lengths available upon request)
    Manufacturing ProcessCold Drawn, Bright Annealed, Seamless
    Material Surface FinishBright Annealed (BA), Mirror Polished, No. 4 Finish
    End TypePlain End (PE), Beveled End (BE), Threaded End (TE)
    CertificationsISO 9001, EN 10204 3.1 / 3.2, PED, ASME

    Bright Annealed Stainless Steel 316L Pipe, SS 316L Bright Annealed Seamless Pipes, SS 316L BA Pipes, Stainless Steel 316L Bright Annealed Welded Tube Distributors, SS 316L Bright Annealed Tubing, SS UNS S31603 Bright Annealed Tube Exporter , SUS 316L BA Seamless Tube, AISI 316L Steel BA Welded Pipe Manufacturer, 316L Stainless Steel Bright Annealing Seamless Pipe, DIN 1.4404 / 1.4435 BA Tubes Supplier

    Stainless Steel 316L BA Pipe, SS 1.4404 / 1.4435 Bright Annealed Pipe, SS 316L Bright Annealed Seamless Tube Traders , SS 316L BA Seamless Pipe, Stainless Steel S31603 BA Tubing, ASTM A312 Stainless Steel 316L Bright Annealed Pipe, ASTM A249/ A269 / A270 Stainless Steel 316L Bright Annealed Tube, Stainless Steel AISI 316L Bright Annealing Welded Pipe Stockists , Stainless Steel 316L Bright Annealed Piping Stockholders, Bright Annealed SS 316L Tube Dealers, 316L SS BA Welded Tube Manufacturers

    SS 316L Bright Annealed Pipe and Tube Equivalent Grades

    STANDARDUNSWERKSTOFF NR.AFNORENJISBSGOST
    SS 316LS316031.4404 / 1.4435Z3CND17‐11‐02 / Z3CND18‐14‐03X2CrNiMo17-12-2 / X2CrNiMo18-14-3SUS 316L316S11 / 316S1303Ch17N14M3 / 03Ch17N14M2

    Stainless Steel 316L BA Pipes and Tubes Chemical Composition

    GradeCMnSiPSCrMoNiFe
    SS 316L0.035 max2.0 max1.0 max0.045 max0.030 max16.00 - 18.002.00 - 3.0010.00 - 14.0068.89 min

    Bright Annealed SS 316L Pipe and Tubing Mechanical Properties

    Tensile StrengthYield Strength (0.2%Offset)ElongationHardness
    Rockwell B (HR B) maxBrinell (HB) max
    Psi – 75000 , MPa – 515Psi – 30000 , MPa – 20535 %95217

    Stainless Steel Tube Bright Annealing Marking & Packing

    • Marking according to MPS and Standard
    • Stainless Steel Tubes Ends with Caps according to PO
    • In Seaworthy Wooden Cases With Plastic Paper protect
    • In Plywood Cases With Plastic Paper Protect(Recommend, All Plywood Cases made by ourselves with lower cost.)
    • Steel Racks Package
    • Hexagonal packing in Bundles

    ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
