    ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 201 304 316L 321 310S 314 347 2205 2507 904L.etc
    Certification : ISO
    Price : 2400 - 3500 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321

    ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321

    Products Specification


    StandardASTM A213, ASTM A269, ASME SA213, ASME SA269
    Pipe TypeBright Annealed Stainless Steel Tubing
    Grades304, 304L, 316, 316L, 321, 310S, 2205, 2507
    DimensionsOuter Diameter (OD): 1.00 mm to 76.2 mm
    Wall Thickness0.2 mm to 6.0 mm
    LengthUp to 12 meters (custom lengths available upon request)
    Manufacturing ProcessCold Drawn, Bright Annealed, Seamless
    Material Surface FinishBright Annealed (BA), Mirror Polished, No. 4 Finish
    End TypePlain End (PE), Beveled End (BE), Threaded End (TE)
    CertificationsISO 9001, EN 10204 3.1 / 3.2, PED, ASME

    Stainless Steel BA Tube is a part of stainless steel annealing process which is conducted in atmosphere of hydrogen protection or vacuum. The thermal process technology delivers resistance to oxidation and certain brightness to surface. Therefore, inner surface roughness is less than 0.4μm, and outer surface is less than 0.6μm.This product is the time-verified pipe fitting for ultra-pure and special gas piping system. It also finds extensive applications in industries of photoelectricity, semi-conductor, solar chemical, medicine and food, etc. Furthermore, BA pipe is the base material for EP pipe.


    Features

    • Better corrosion
    • Smoothest finished, Mirror like finish
    • Enhance flow characteristics
    • Improved product purity
    • Improved hygiene

    Industries Applied

    • Semiconductor,
    • Solar Photovoltaics Energy
    • Poly-silicon industries.
    • Pharmaceuticals,
    • Laboratory engineering,
    • High purity gas industry,
    • Health Industry

    Finish Process Classifications

    • AP Finish - Annealed and Pickled
    • BA Finish - Bright Annealed
    • EP Finsh - Electro Polished/ Electro Polishing
    • MP Finsh - Mechanical Polished / Mechanical Polishing

    General Information


    Outside Diameter (OD)6.35 to 44.5mm, Other Sizes as Per Requested
    Wall Thickness (WT)0.71 to 3.05 mm, Other Sizes as Per Requested
    TypeSeamless, Round Tubes
    Delivery ConditionAnnealed and Pickled, Stress Relived, Hardened, Tempered, Cold Drawn or Cold rolled
    LengthSingle Random, Double Random & Required Length
    EndPlain End, Beveled End, Treaded
    Outside FinishElectropolish, Bright Annealed, Passivated, Mechanical Polished as per customer Requirements
    Material CertificationsManufacture Test Certificates EN10204 3.1/3.2; Third Party Inspection SGS, TUV, DNV, LLORDS, ABS etc.
    PackingPacked in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests

    Product Standards:

    DesignationSpecification
    ASTM, ASME Standards
    A213/SA213Seamless ferritic and austenitic alloy steel boiler, superheater and heat exchanger tubes
    A269/SA269-15Seamless and welded austenitic stainless steel tubing for general service
    A312/SA312Seamless and welded austenitic stainless steel pipes
    A/789/SA789Seamless and welded ferritic-austenitic stainless steel tubing for general service
    A790/SA790Seamless and welded ferritic-austenitic stainless steel pipe
    DIN Standards
    DIN 17456General purpose seamless circular stainless steel tubes
    DIN 17458Seamless circular Austenitic stainless steel tube subject to special requirement
    DIN 28180Stainless steel heat exchanger tubes
    DIN 17459Seamless Circular High Temperature Austenitic Stainless Steel Tube Subject To Special Requirement
    European Standards
    EN 10216-5Seamless steel tubes for pressure purposes
    JIS Standard
    JIS G 3459Stainless steel pipes
    JIS G 3463Stainless steel boiler and heat exchanger tubes
    GOST Standards
    GOST 9941Seamless stainless steel tubes, cold and hot finished
    TU 14-3-460Seamless Steel Pipes for Steam Boilers and Pipelines

    Typical Material Grades and Chemical Composition


    AusteniticNearest equivalent standardTypical Chemical composition
    ASMEAISI UNSGBENJISCmaxCrNiMoCuOthers
    TP304S304000Cr18Ni91.4301SUS 3040.0818.0–20.08.0–11.0
    TP304LS3040300Cr19Ni101.4307SUS 304L0.03518.0–20.08.0–12.0
    TP304HS3040307Cr19Ni101.4948SUS 304H0.04-0.118.0–20.08.0–11.0
    TP321S321000Cr18Ni10Ti1.4541SUS 3210.0817.0–19.09.0–12.05(C+N)<Ti< 0.7
    TP321HS321001Cr18Ni9Ti1.4878SUS 3210.04-0.117.0–19.09.0–12.04(C+N)<Ti< 0.7
    TP347S34700Cr18Ni11Nb1.455SUS 3470.0817.0–20.09.0–13.010×C<Nb<1
    TP347HS347091Cr19Ni11Nb1.4912SUS 3470.04-0.117.0–19.09.0–13.08×C<Nb<1.10
    TP316S316000Cr17Ni12Mo21.4401SUS 3160.0616.0–18.010.0–14.02
    TP316LS3160300Cr17Ni14Mo21.4404SUS 316L0.0316.0–18.010.0–14.02
    TP316HS3160907Cr17Ni12Mo21.4919SUS 316H0.04-0.116.0–18.011.0–14.02
    TP316 TiS316350Cr18Ni12Mo2Ti1.4571SUS 316Ti0.0316.0–18.010.0–14.02N0.015(C+N)<Ti< 0.7
    TP317S317000Cr19Ni13Mo31.4438SUS 317L0.0818.0–20.011.0–15.03
    TP317L3170300Cr19Ni13Mo31.4438SUS 317L0.0318.0–20.011.0–15.03
    TP309SS3090806Cr23Ni131.4833SUS 309S0.822.0–24.012.0–15.0
    TP310S3100020Cr25Ni201.4841SUS 3100.0824.0–26.019.0–22.0
    TP310SS310080Cr25Ni201.4845SUS 310S0.124.00-26.019.00-22.0
    TP310HS310091.4845SUS 310H0.0824.0–26.019.0–22.0
    TP904LN08904015Cr21Ni26SiMo5Cu21.4539SUS 904L0.0219.0 – 23.023.0 – 28.041.0-2.0
    Austenitic Ferritic Steel / Duplex Stainless Steel
    2101S321011.4162DP20.0420.0-23.01.0-3.00.10.1N 0.20
    2205S32205022Cr23Ni5Mo3N1.4462DP20.0321.0-23.04.5-6.53N 0.14
    S31803S31803022Cr22Ni5Mo3N1.4462DP20.0321.0-23.04.5-6.52.5N 0.08
    2304S323041.4362DP20.033<0.05-0.60.6N 0.2
    2507S32750022Cr25Ni7Mo4N1.441DP20.0324.0-26.06.0-8.030.5N 0.32

    Demension Range

    (WT)mm
    (OD)mm
    0.6-0.8
    0.9-1.21.3-1.61.7-2.22.3-2.93-4.54.6-5.55.6-7.57.6-99.1-1212.1-1616.1-2424.1-32
    5-7
    8-10
    11-16
    17-25
    26-35
    36-45
    6-56
    57-65
    66-76
    77-100
    101-114
    115-133
    134-159
    160-219
    220-273
    274-325

    ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321ASME SA269 Stainless STeel BA Pipe Tube SS Tube TP304 TP304L TP316L TP310S TP321
