ASTM B444 Inconel 625 Seamless Pipe UNS N06625 Alloy For Harsh Environments

Ask Lasest Price
Brand Name :	DELTA
Model Number :	inconel 625
Certification :	ISO
Price :	40-45 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

ASTM B444 Inconel 625 Seamless Pipe UNS N06625 Alloy For Harsh Environments

ASTM B444 Inconel 625 Seamless Pipe – UNS N06625 Alloy for Harsh Environments

Products Specification

Model	Nickel Tubes Pipes
Material Grade	Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc
Diameter	a) Capillary Tube Outer Diameter: 0.2mm-6.mm Welding Tube Outer Diameter: 6.mm- 840mm Seamless Tube Outer Diameter: 6mm-630mm
	b) Capillary Tube Wall Thickness: 0.02mm-2mm Welding Tube Wall Thickness: 0.5-150mm Seamless Tube Wall Thickness: 0.5-60mm
	c) Length: ≤500mm Or in coil
Tolerance	a) Outer Diameter: +/- 0.01mm
	b) Thickness: +/- 0.01mm
	c) Length: +/- 0.1mm
Surface Treatment	Polishing,Annealing, Bright, Pickling
Type	Welded,Seamless
Shape	Round,Square,Irregular
Application	medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.

Inconel 625 Seamless Pipe proposal different dimensions of extraordinary temperature excellence, location obstacle, ingesting and breakdown opposition in a wide scope of natural and inorganic acids just as sulfides and chlorides. Inconel 625 Seamless Pipe according to AMS 5581 is only a case of cold drawn tubing frequently shaped by suppliers Combined. Similarly Inconel 625 Welded Pipe is the tradename of Singular Metals Group of Businesses and comparable to NR 2.4856, UNS N06625 etc.

Composition Standard of Nickel Alloy 625 Pipe

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 625	0.10 max	0.50 max	0.50 max	0.015max	–	5.0 max	58.0 min	20.0 – 23.0

Mechanical Properties Chart of Inconel 625 Pipe

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Inconel 625	8.4 g/cm3	1350 °C (2460 °F)	Psi – 1,35,000 , MPa – 930	Psi – 75,000 , MPa – 517	42.5 %

Material Equivalent of Alloy 625 Pipe

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Inconel 625	2.4856	N06625	NCF 625	NA 21	ХН75МБТЮ	NC22DNB4MNiCr22Mo9Nb	NiCr23Fe

Specification of Inconel Alloy 625 Pipe

UNS:	N06625
Specifications:	ASTM B444, ASTM B751, ASTM B829, ASTM B775, ASTM B705, ASTM B704, AMS 5581
international Specifications:	ISO 6207, VdTüV 499, BS 3074NA21, DIN 17751, WERKSTOFF Nr 2.4856

Grade of Nickel Alloy Pipes we can supply

N08020 , INCOLOY Alloy 20 , N08028 , INCOLOY Alloy 28 , N08330 , INCOLOY , Alloy 330 ,
N08800, Paduan INCOLOY 800 , N08810 , Paduan INCOLOY 800H , N08825 , Paduan INCOLOY 825 ,
N06600, Inconel 600, N06601, Inconel 601, N06625, Inconel 625, INCOLOY Alloy 625 ,
N07718 , Inconel 718 , INCOLOY Alloy 718 , N07750 , Inconel X750 , N04400 , MONEL400 ,
Nickl200 , S66286 , N10276 , Hastelloy C-276 , N06455 , Hastelloy C-4 , N06022 , Hastelloy C-22 ,
N10665 , Hastelloy B-2 , N10675 , Hastelloy B-3 , N06030 , Hastelloy G-30 , INCOLOY Alloy A286 ,
N08926, Paduan INCOLOY 25-6Mo, dll.
2.4060,1.4980,1.4529,2.4460,1.4563,1.4886,1.4876,1.4876,2.4858,2.4816 ,
2.4851,2.4856,2.4856,2.4668,2.4669,2.4360,2.4375,2.4819,2.4610,2.4602 ,
2.4617,2.4660 , dll.
