    Nickel Alloy 625 Seamless Tube Superior Oxidation Pitting Resistance

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : inconel 625
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Nickel Alloy 625 Seamless Tube Superior Oxidation Pitting Resistance

    Nickel Alloy 625 Seamless Tube – Superior Oxidation & Pitting Resistance


    Products Specification


    Model
    Nickel Tubes Pipes
    Material Grade
    Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
    Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
    Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc
    Diameter
    a) Capillary Tube Outer Diameter: 0.2mm-6.mm
    Welding Tube Outer Diameter: 6.mm- 840mm
    Seamless Tube Outer Diameter: 6mm-630mm
    b) Capillary Tube Wall Thickness: 0.02mm-2mm
    Welding Tube Wall Thickness: 0.5-150mm
    Seamless Tube Wall Thickness: 0.5-60mm
    c) Length: ≤500mm Or in coil
    Tolerance
    a) Outer Diameter: +/- 0.01mm
    b) Thickness: +/- 0.01mm
    c) Length: +/- 0.1mm
    Surface Treatment
    Polishing,Annealing, Bright, Pickling
    Type
    Welded,Seamless
    Shape
    Round,Square,Irregular
    Application
    medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.

    Inconel 625 Pipe is a nickel chromium super alloy pipe that is made up of 58% nickel, 20% chromium, carbon, manganese, silicon, iron, sulfur, aluminum and titanium in the composition. The pipes are highly corrosion resistant. Navstar Steel is a leading manufacturer and supplier of the Inconel 625 Pipe and tubes. The material has 517MPa minimum yield strength and 930MPa minimum tensile strength.

    The Alloy 625 Seamless Tubing comes in sizes ranging from 4mm to 219mm. There are welded, fabricated and LSAW pipes as well. The welded and EFW pipes range from 5mm to 1219.2mm in size. The wall thickness of the Inconel 625 Seamless Pipe ranges from 0.5mm 20mm. The pipes are specified for larger diameters with schedules ranging from 5 to 160. The pipes come in different forms such as round and hydraulic pipes. The lengths of the pipes vary as single random, double random and cut to lengths.


    UNS N06625 Tube Schedules

    1/8" IPS(.405"O. D.)3 1/2" IPS( 4.000"O. D.)
    SCH 40, 80SCH 10, 40, 80, 160, XXH
    1/4" IPS(.540"O. D.)4" IPS(4.500"O. D.)
    SCH 10, 40, 80SCH 10, 40, 80, 160, XXH
    3/8" IPS(.675"O. D.)5" IPS( 5.563"O. D.)
    SCH 10, 40, 80SCH 10, 40, 80, 160, XXH
    1/2" IPS(.840"O. D.)6" IPS(6.625"O. D.)
    SCH 5, 10, 40, 80, 160, XXHSCH 5, 10, 40, 80, 120, 160, XXH
    3/4" IPS(1.050"O. D.)8 ” IPS(8.625"O. D.)
    SCH 10, 40, 80, 160, XXHSCH 5, 10, 40, 80, 120, 160, XXH
    1" IPS:(1.315′O. D.)10" IPS(10.750"O. D.)
    SCH 5, 10, 40, 80, 160, XXHSCH 10, 20, 40, 80 (.500), TRUE 80(.500)
    1-1/4" IPS(1.660"O. D.)12" IPS(12.750"O. D.)
    SCH 10, 40, 80, 160, XXHSCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
    1-1/2" IPS(1.900"O. D.)14" IPS(14.000"O. D.)
    SCH 10, 40, 80, 160, XXHSCH10 (.188), SCH40 (.375)
    2" IPS(2.375"O. D.)16" IPS(16.000"O. D.)
    SCH 10, 40, 80, 160, XXHSCH10(.188), SCH40(.375)
    2 1/2" IPS(2.875"O. D.)18" IPS (18.000"O. D.)
    SCH 10, 40, 80, 160, XXHSCH-40 (.375)
    3" IPS( 3.500"O. D.)
    SCH 5, 10, 40, 80, 160, XXH

    Inconel Din 2.4856 Welded Pipe Composition Standard

    GradeCMnSiFeSCr2Al-TiNi
    625min.20.058.0
    max.0.100.500.505.00.01523.00.40

    ASME SB444 Alloy 625 Hexagonal Pipe Characteristics

    GradeTensile Strength (MPa) minYield Strength 0.2% Proof (MPa) minElongation (% in 50mm) minHardness
    Rockwell B (HR B) maxBrinell (HB) max
    625Psi – 1,35,000 , MPa -930Psi – 75,000 , MPa – 51742.5
