    Inconel 625 Seamless Pressure Tube Excellent Fatigue Creep Resistance

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : inconel 625
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Inconel 625 Seamless Pressure Tube Excellent Fatigue Creep Resistance

    Inconel 625 Seamless Pressure Tube Excellent Fatigue & Creep Resistance


    Products Specification


    Model
    Nickel Tubes Pipes
    Material Grade
    Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
    Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
    Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc
    Diameter
    a) Capillary Tube Outer Diameter: 0.2mm-6.mm
    Welding Tube Outer Diameter: 6.mm- 840mm
    Seamless Tube Outer Diameter: 6mm-630mm
    b) Capillary Tube Wall Thickness: 0.02mm-2mm
    Welding Tube Wall Thickness: 0.5-150mm
    Seamless Tube Wall Thickness: 0.5-60mm
    c) Length: ≤500mm Or in coil
    Tolerance
    a) Outer Diameter: +/- 0.01mm
    b) Thickness: +/- 0.01mm
    c) Length: +/- 0.1mm
    Surface Treatment
    Polishing,Annealing, Bright, Pickling
    Type
    Welded,Seamless
    Shape
    Round,Square,Irregular
    Application
    medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.

    What is Inconel 625 Pipe?


    Inconel 625 is an austenitic grade of steel. These pipes are designed with a superior composition of nickel, chromium, and molybdenum allowing the pipes to transport fluids and gases in corrosive and oxidative media. The alloy 625 pipes can be used in temperatures up to 1800 degrees F and are highly resistant to attacks in mild or alkaline conditions. The pipes work well in marine environments, where they are susceptible to pitting and crevice corrosion. The Inconel grade 625 pipes have good strength and showcase superior mechanical properties. These components have a minimum tensile strength of 940mpa with a minimum yield strength of 430mpa and can be elongated by 51.5%. Designed with a hardness between 32 to 40 HRC, the alloy 625 pipe is difficult to machine and process.

    What is Inconel 625 tube used for?
    The Inconel 625 tube is a versatile grade that is employed in the transportation of fluids or gases and is commonly seen in.

    • Jet engine components
    • Pollution control systems
    • Heat exchanger items
    • Marine services
    • Nuclear power plants and reactor cores
    • Oil and gas refining and processing industry
    • Electrical cable connectors for communication services

    How do I know if my Alloy 625 Tube is seamless?
    A seamless tube is produced by passing hot steel billets through an extrusion process and doesn’t show the presence of welds on the surface of the tube. These tubes are generally designed in sizes up to only 24 inches.

    Which testings are required for Inconel 625 Seamless Pipe and why?
    Inconel 625 pipe testing procedures are important in the detection of any weakness and predicting the quality of the material. The pipes are generally put through three non-destructive tests.

    • Ultrasonic testing- This test helps in detecting defects in the dimensions and help in determining the length of the grade.
    • Magnetic flux leakage testing- This is a non-destructive test where the material is tested on the ferromagnetic changes. Any leakage in the module is measured based on the magnetic flux in large caliber seamless material.
    • Eddy current testing- The process is based around the theory of electromagnetic agent that is designed without a coupling agent. It helps in the detection of bulbs and can be used in measuring seamless pipes of different configurations.

    What is ASTM B444 UNS N06625?
    ASTM B444 UNS N06625 is a standard specification of nickel, columbium, chromium, and molybdenum alloys. These components are designed in annealed and solution annealed conditions as per their grades. The items in this grade are subjected to tensile, yield, and elongation testing procedures to ensure that they work in different conditions. These alloys are ductile and can be easily electroplated or welded in place.


    Inconel Alloy 625 Round Pipe Chemical Composition

    GradeSCAl-TiMnCr2SiNiFe
    625min.20.058.0
    max.0.0150.100.400.5023.00.505.0

    ISO 6207 Inconel 625 Pipe Mechanical Properties

    GradeElongational (% in 50mm) minYield Properties 0.2% Proof (MPa) minTensile Properties (MPa) minHardness
    Rockwell B (HR B) maxBrinell (HB) max
    62542.5Psi – 75,000 , MPa – 517Psi – 1,35,000 , MPa -930
    Get Schedule 10 to SCH 40 AMS 5581 Tubing and ISO 6207 Tube at Lowest Rate with MTC, also compare our prices with any other Stockholder and Distributor of Inconel 625 Tubes

    Alloy 625 Seamless Pipe Equivalent

    GradeEuronormGOSTUNS NoJapanese JISOld British
    NoAFNORBSEn
    Inconel 6252.4856NC22DNB4MХН75МБТЮN06625NCF 625NA 21NiCr22Mo9Nb
