    Custom-Sized Forged Stainless Steel Plates Perfect for Welding & Forming F321 Alloy

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Certification : ISO
    Price : 1200-1400 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Custom-Sized Forged Stainless Steel Plates Perfect for Welding & Forming F321 Alloy

    Custom-Sized Forged Stainless Steel Plates Perfect for Welding & Forming F321 Alloy


    Products Specification


    GradesStainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc
    Thickness10 - 150.0mm
    Width1250 -1500mm or custom other size as request
    Length2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT
    Type of MaterialLaser Cutting
    FormPlate / coil
    Test CertificateYes.
    FinishNO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA.
    BrandTISCO, LISCO,BAOSTEEL , POSCO, JISCO

    Forged F321 Stainless Steel Plate – High-Temperature & Corrosion-Resistant Solution

    1. Product Overview

    Forged F321 stainless steel plate is a titanium-stabilized austenitic stainless steel (similar to 304 but with superior resistance to intergranular corrosion). The forging process enhances its mechanical strength, fatigue resistance, and structural integrity, making it ideal for high-stress, high-temperature applications.


    2. Key Parameters & Chemical Composition

    PropertyF321 (UNS S32100)
    StandardASTM A182 / A240 / ASME SA182
    CompositionCr: 17-19%, Ni: 9-12%, C: ≤0.08%, Ti: 5×C% min
    Tensile Strength≥515 MPa (75 ksi)
    Yield Strength≥205 MPa (30 ksi)
    Elongation≥40%
    Hardness≤192 HB (Annealed)
    Density8.0 g/cm³
    Thermal StabilityExcellent (up to 800°C)
    Corrosion ResistanceResists oxidation, intergranular corrosion, and acidic environments

    3. Available Specifications

    • Thickness: 10mm – 300mm (custom forgings available)

    • Width: 1000mm – 2500mm (or as per requirement)

    • Length: 2000mm – 6000mm (or cut-to-size)

    • Surface Finish:

      • Forged & annealed

      • Machined, ground, or polished (No.1, 2B, BA)

      • Pickled or blasted (upon request)


    4. Standards & Certifications

    • ASTM: A182 (Forged Fittings), A240 (Plates)

    • ASME: SA182, SA240

    • EN: 1.4541 (European Equivalent)

    • Other: NACE MR0175 (for sour service), PED 2014/68/EU


    5. Key Features & Advantages

    ✔ Superior High-Temperature Performance – Resists carbide precipitation (due to Ti stabilization), ideal for 800°C+ environments.
    ✔ Enhanced Strength via Forging – Improved grain structure vs. cast/cold-rolled plates.
    ✔ Excellent Corrosion Resistance – Resists intergranular, pitting, and stress corrosion cracking (SCC).
    ✔ Weldability & Formability – Low carbon content minimizes sensitization during welding.
    ✔ Customizable – Available in different heat treatment conditions (annealed, solution-treated).


    6. Typical Applications

    • Oil & Gas: Pressure vessels, heat exchangers, flare stacks

    • Chemical Processing: Reactors, piping, acid storage tanks

    • Aerospace: Exhaust systems, turbine components

    • Power Plants: Boilers, superheater tubes

    • Automotive: Exhaust manifolds, turbocharger parts


    7. Packaging & Delivery

    • Standard Packaging:

      • Wooden crates + waterproof wrapping (for海运)

      • Steel strapping + edge protection (for heavy plates)

    • Custom Options:

      • VCI (Vapor Corrosion Inhibitor) coating for long-term storage

      • Labeling with heat numbers & material certs (MTC 3.1/3.2)

    • Export Compliance: ISO 10474, EN 10204 certification


    8. Why Choose Our Forged F321 Plates?

    • Strict Forging Process Control – Ensures uniform density & mechanical properties.
    • Full Traceability – Mill test reports (MTR) with chemical & mechanical data.
    • Competitive Pricing – Direct factory supply, no middlemen.
    • Global Logistics Support – Fast delivery to EU, Americas, Middle East.

    Contact us for quotes, technical data sheets (TDS), or custom dimensions!


    SEO & Technical Notes:

    • Keywords: *"Forged 321 stainless steel plate supplier," "high-temperature F321 forged plate," "ASTM A182 F321 stainless steel."*

    • Add testing details (PMI, UT, hardness tests) if required.

    • Specify MOQ, lead time, or special certifications (e.g., NORSOK, DNV) if applicable.

    Let me know if you need modifications!
