    Bright Anneal / Hot Rolled 904L Stainless Steel Pipe DIN 1.4539 SS Pipe in 3m 6m Length

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 904L
    Certification : ISO
    Price : 4650-5760 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Bright Anneal / Hot Rolled 904L Stainless Steel Pipe DIN 1.4539 SS Pipe in 3m 6m Length

    Bright Anneal / Hot Rolled 904L Stainless Steel Pipe DIN 1.4539 SS Pipe in 3m 6m Length


    Product NameStainless Steel Pipe
    StandardJIS, AISI, ASTM, GB, DIN
    Outer Diameter6mm-530mm (1/8"-20") or as the customers' requirements
    Length1000-6000mm or as the customers' requirements
    GradeTP201, TP304, TP304L, TP310S, TP316, TP316L, TP317L, TP321, TP309S, TP410, TP420, TP430, TP904L
    Thickness1mm-60mm
    Typeweld
    SurfacePickled , Bright
    manufactureHot Rolled/Cold Rolled
    ApplicationConstruction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat ex-changer, machinery and hardware fields ,etc.
    PackingWeaving bag, non-woven fabric, seaworthy bundle,wooden case if required
    Delivery timeWithin 7 - 10 working days, according to customers' quantity
    PaymentL/C or T/T
    MOQ1 Ton
    QualityHigh Quality.SGS inspection is accepted if needed
    Productivity1000 Tons/Month


    904L stainless steel is a superaustenitic stainless steel grade, Alloy 904L (UNS N08904) contains high levels of chromium and nickel with additions of molybdenum and copper to provide superior corrosion resistance.


    The combination of high chromium and nickel content, coupled with additions of molybdenum and copper, assures good to excellent corrosion resistance, and moderate to high corrosion resistance in a wide range of process environments, containing dilute sulfuric acid. It also offers good resistance to other inorganic acids such as hot phosphoric acid as well as most organic acids.


    Chemical Compositions

    Element% Present (in product form)
    Carbon (C)0.02
    Silicon (Si)0.70
    Manganese (Mn)2.00
    Phosphorous (P)0.03
    Sulfur (S)0.01
    Chromium (Cr)19.00 - 21.00
    Nickel (Ni)24.00 - 26.00
    Nitrogen (N)0.15
    Molybdenum (Mo)4.00 - 5.00
    Copper (Cu)1.20 - 2.00
    Iron (Fe)Balance

    Mechanical properties (at room temperature in annealed condition)

    Product Form
    CHPLLTW/TS
    Thickness (mm) Max.8.013.5751602502)60
    Yield StrengthRp0.2 N/mm22403)2203)2203)2304)2305)2306)
    Rp1.0 N/mm22703)2603)2603)2603)2603)2503)
    Tensile StrengthRm N/mm2530 - 7303)530 - 7303)520 - 7203)530 - 7304)530 - 7305)520 - 7206)
    Elongation min. in %Jmin (Longitudinal)-100100100-120
    Jmin (Transverse)-6060-6090

    Reference data on some physical properties

    Density at 20°C kg/m38.0
    Thermal Conductivity W/m K at20°C12
    Modulus of Elasticity kN/mm2 at20°C195
    200°C182
    400°C166
    500°C158
    Specific Thermal Capacity at 20°C J/kg K450
    Electrical Resistivity at 20°C Ω mm2/m1.0

    Processing / Welding

    Standard welding processes for this steel grade are:

    • TIG-Welding
    • MAG-Welding Solid Wire
    • Arc Welding (E)
    • Laser Bean Welding
    • Submerged Arc Welding (SAW)

    Application of 904L Stainless Steel

    Chemical plant, oil refinery, petrochemical plants, bleaching tanks for the paper industry, combustion gas desulfurisation plants, application in sea water, sulphuric and phosphoric acid. Due to the low C-content, the resistance to intergranular corrosion is also guaranteed in the welded condition.
