    Flat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch Copper

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : UNS C11000
    Certification : ISO
    Price : 10 - 12 USD/Kg
    Payment Terms : T/T, L/C
    Supply Ability : 5 Ton per week
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Flat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch Copper

    Flat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch Copper


    UNS C11000 electrolytic tough pitch copper is ductile, has excellence resistance to corrosion, and has a conductivity of 101% IACS. The following datasheet will discuss in detail about UNS C11000 electrolytic tough pitch copper.


    Products Specification


    Material
    Copper and Copper alloy products
    Grade
    ASTM
    C10100,C11000,C12200,C21000,C22000,C23000,C24000,C26000,
    C27000,C26800,C27200,C27400,C28000,C36500,C33000,C35300,
    C35600,C36000,C38500,C44300,C46400,C52100,C54400,C62300,
    C65500,C67500,C67600,C86300,C90700,C93200,C95400 etc.
    G/B
    TU1,T2,TP2,H96,H90,H85,H80,H70,H65,H63,H62,H59,HPb63-3,
    HPb66-0.5,HPb62-2,HPb62-3,HPb59-3,HSn70-1,HSn62-1,QSn8-0.3, QSn4-4-4,QAl9-4,QSB-1 etc.
    JIS
    C 1011,C 1100,C 1220,C3604,C 2100,C 2200,C 2300,C 2400, C 2600,
    C 2700,C 2680,C 2720,C 2800,C 4430,C 4640,C 5210, C 5441, CAC304 etc
    BS
    Cu-OFE,C 101,Cu-DHP,CZ 125,CZ 101,CZ 102,CZ 103,CZ 106,CZ 107, CZ 108,CZ 109,CZ 123,CZ 124,CZ 121,CZ 111,CZ 133, Pb 104,
    CS 101, CuSn10P etc.
    DIN/ISO
    CuZn5,CuZn10,CuZn15,CuZn20,CuZn30,CuZn35,CuZn33,CuZn36,
    CuZn37,CuZn40,CuZn40Pb,CuZn37Pb2,CuZn36Pb3,CuZn39Pb3,
    CuZn28Sn1,CuZn38Sn1,CuSn8,CuSn4Pb4Zn3,CuSi3Mn,CuZn25Al5,
    CuSn10, CuSn7Zn3Pb7 etc.
    Shape
    Round, Square, Flat, Hexagon, Oval, Half-round or Customized
    Dimension
    Bar/Rod
    Standard(Diameter 5-160 mm) or Customized
    Wire
    Standard(Diameter 0.02-6 mm) or Customized
    Plate/Sheet
    Standard(T 0.2-50 mm/W 200-3000 mm/L 6000 mm) or Customized
    Strip
    Standard(T 0.05-1.5 mm/W 20-600 mm/L 20000 mm) or Customized
    Tube/Pipe
    Standard(OD 3-360mm/Wall thickness 0.5-50 mm) or Customized
    Standard
    GB/T,JIS,ASTM, ISO, DIN, BS, NF etc.
    Hardness
    1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard.
    Package
    Plastic film + Wooden case or as per customer requirement
    Surface
    Polished,bright,oiled,hair line,brush,mirror,or as required
    Deliver time
    According to order's quantity.
    Shipment
    By sea, by air, DHL, UPS, FedEx etc. or as required
    Application
    Electric light industry, machinery manufacturing, Building industry ,defense industry, and other fields Manufacturing industrial

    Chemical Composition of C11000 Copper


    The following table shows the chemical composition of UNS C11000 copper.

    ElementContent (%)
    Cu99.90

    Physical Properties of C11000 Copper

    The physical properties of UNS C11000 copper are given in the following table.

    PropertiesMetricImperial
    Density8.89 g/cm30.322 lb/in3
    Melting point1065 - 1083°C1949°F

    Mechanical Properties of C11000 Copper

    The mechanical properties of UNS C11000 copper are tabulated below.

    PropertiesMetricImperial
    Hardness, Rockwell F (hard temper)80.080.0
    Poisson's ratio0.340.34
    Elastic modulus115 - 117 GPa16969 ksi

    Standard Specification of C11000 Copper Products

    The designations that are equivalent to the UNS C11000 copper are outlined in the following table.

    ASME SB133ASTM B173ASTM B228ASTM B33ASTM B49ASTM F467
    ASTM B1ASTM B174ASTM B229ASTM B355ASTM B496ASTM F468
    ASTM B101ASTM B187ASTM B246ASTM B370ASTM B506MIL B-20292
    ASTM B116ASTM B188ASTM B272ASTM B447ASTM B556MIL C-12168
    ASTM B124ASTM B189ASTM B283ASTM B451ASTM B638MIL W-6712
    ASTM B133ASTM B2ASTM B286ASTM B47ASTM B694QQ B575
    ASTM B152ASTM B224ASTM B298ASTM B470ASTM B738SAE J461
    ASTM B172ASTM B226ASTM B3ASTM B48ASTM B8SAE J463

    Welding

    Welding techniques such as soldering, brazing, gas shielded arc welding, oxyacetylene welding and butt welding are recommended for C11000 copper. Other welding techniques such as coated metal arc welding, spot welding and seam welding are not preferred.

    Forging

    C11000 copper is forged at hot working temperatures ranging from 760 to 871°C (1400 to 1600°F). The hot forgeability rate of this metal is 65%.

    Hot Working

    C11000 copper has excellent hot working property.

    Cold Working

    C11000 copper has excellent cold working property.

    Annealing

    Annealing of C11000 copper is performed at temperatures ranging from 371 to 649°C (700 to 1200°F).

    Applications

    UNS C11000 copper is best suited for plumbing fittings and other electrical components that do not require prolonged machining performance.


    Flat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch CopperFlat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch CopperFlat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch CopperFlat UNS C11000 Copper Plate Sheet Electrolytic Tough Pitch Copper
