EN 1.4418 Hot Rolled Forged Alloy Round Bar Bright Bar Alloy 1.4418 Shaft

Ask Lasest Price
Brand Name :	DELTA
Model Number :	1.4418
Certification :	ISO
Price :	40-45 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

EN 1.4418 Hot Rolled Forged Alloy Round Bar Bright Bar Alloy 1.4418 Shaft

EN 1.4418 Hot Rolled & Forged Alloy Round Bar Bright Bar Alloy 1.4418 Shaft

Form	Nickel Alloy Bars
Grade	1.4418
Outer Diameter	6mm-300mm or according to customer’s requirement
Length	custom cutting any length as request
Standard	ASTM, ASME, EN, JIS, DIN, GB/T, etc
Process Method	Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar & Rod
Surface Finish	Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline
Other Grade	Hastelloy : B2 B3 C22 C276 G30 X Incoloy: 800 800H 800HT 825 925 A286 330 Inconel: 600 601 617 625 718 725 X-750 Monel: 400 k-500
Price Item	EXW FOB CFR CIF
Payment	30% TT inadvance, 70% TT Balance against copy of B/L
Delivery Time	It depends on your bars order total quantity and stock of these mother origin materials. Usually from the start of the order to the completion of production is about 3-4 weeks
Quality Requirement	Mill test certificate will be offered with shipment, the third party inspection is available
Main Markets	Europe, North America, Middle East, Southeast Asia
Metal Test	High or low temperature impact test, metallographic analysis
Chemical Analysis	As nickel alloy 718 bars standard

About 1.4418 Alloy

1.4418 stainless steel is a high-strength, low-carbon martensitic stainless steel. Its composition consists of 80% Martensite, 10% Austenite & 10% Ferrite, allowing for a low-carbon structure after quenching & tempering.

Supplied Condition (where applicable):

We supply 1.4418 quenched (hardened) & tempered to QT900
Specifications: EN 10088-3

Chemical Composition of Alloy 1.4418

Carbon (Maximum)0.06
Phosphorus (Maximum)0.04
Silicon (Maximum)0.7
Nickel (Nominal)5
Manganese (Maximum)1.5
Sulfur (Maximum)0.03
Chromium (Nominal)16
Molybdenum (Nominal)1.2
Iron (Nominal)Balance
Nitrogen (Nominal)0.02

Properties of 1.4418 Alloy

Combine high tensile strength, excellent fatigue resistance & good weldability - high toughness is maintained even after welding
Are designed for slightly corrosive environments, better corrosion properties than most stainless martensitics
Poor weldability
Magnetic

Mechanical Properties (Specific for Bars – Condition QT900)

Dimensions (mm)	Yield strength Rp0.2, MPa	Tensile strength Rm, MPa	Elongation [%]	Hardness [HB]	Impact, Charpy-V, 20ºC [J]	Impact, Charpy-V, -40ºC [J]
< 160	≥ 700	900 – 1100	≥ 16	280 – 340	≥ 80	≥ 32
160-250	≥ 700	900 – 1100	≥ 14	280 – 340	≥ 60	≥ 32

Application of 1.4418 Alloy

Water turbine parts
Propeller shafts
Piston rods
Hydro power station equipment
Spindles
Bolts
Shear pins
