    ASTM A312 254MA Stainless Steel Seamless Pipe SCH40S SCH80S SCH160S UNS S30815 SS Pipe

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : 253ma
    Certification : ISO
    Price : 4650-5760 USD/Ton
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    ASTM A312 254MA Stainless Steel Seamless Pipe SCH40S SCH80S SCH160S UNS S30815 SS Pipe

    ASTM A312 254MA Stainless Steel Seamless Pipe SCH40S SCH80S SCH160S UNS S30815 SS Pipe


    SpecificationsASTM / ASME A312 / SA312
    Seamless Pipes & Tubes Sizes1 / 2" NB - 8" NB
    Welded Pipes & Tubes Sizes6" NB - 24" NB
    Outer Diameter6.0-630mm
    ScheduleSCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
    Thickness0.3mm – 50 mm
    TypeSeamless / ERW / Welded/ Fabricated
    FormRound Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tubes
    LengthSingle Random, Double Random & Cut Length
    EndPlain End, Beveled End, Treaded

    253MA (UNS S30815) stainless steel is an austenitic, chromium-nickel stainless steel alloyed with nitrogen and reactive elements and suitable for a wide range of fabrication at the high temperatures. It resists oxidation at temperatures up to 1150°C


    Alloy 253MA s30815 Pipe Chemical Analysis


    %CrNiSiCMnPSNCeFe
    Min20101.40.05---0.140.03Balance
    Max221220.10.80.040.030.20.08-


    Physical properties of 253MA grade stainless steel Pipe


    Density (kg/m3)Elastic Modulus (GPa)Mean Coefficient of Thermal Expansion (mm/m/°C)Thermal Conductivity (W/m.K)Specific HeatElectrical Resistivity (nW.m)
    0-100°C0-600°C0-1000°Cat 20°Cat 1000°C0-100°C (J/kg.K)
    78002001718.519.51529500850


    Stainless steel S30815 Mechanical Properties


    Tensile Str (MPa) minYield Str 0.2% Proof (MPa) minElongation (% in 50mm) minHardness
    Rockwell B (HR B) maxBrinell (HB) max
    6003104095217


    Equivalent Grades of 253MA Stainless steel


    GradeUNSWERKSTOFF NR.ENSS
    253MA(UNS S30815)S308151.4835X9CrNiSiNCe21-11-22368
    ASME SA312 /ASTM A312Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
    Material GradeS20400TPXM-19S20910TPXM-11S21900
    TP304NS30451TP304LNS30453S30600
    S30941S31002TP310SS31008TP310H
    TP316S31600TP316LS31603TP316H
    S31725S31726TP321S32100TP321H
    TP347LNS34751TP348S34800TP348H
    TPXM-29S21904TP304S30400TP304L
    S30615 S30815TP309SS30908TP309H
    S31009TP310CbS31040TP310HCbS31041
    S31609TP316NS31651TP316LNS31653
    S32109S32615S32654S33228S34565
    S34809S35045S35315TPXM-15S38100
    S30403TP304HS30409S30415TP347
    S30909TP309CbS30940TP309HCbS34700
    S31060S31254S31272S31635TP347H
    TP317S31700TP317LS31703S34709
    NO8367NO8926NO8904
    Size1/2''~48''
    ThicknessSCH5~SCHXXS
    EndBeveled End,Plain End
    LengthAs per your requirement.
    PackingExport Standard packing or as per your requirements.
    Applications
    including burners, retorts, conveyor belts, fans, jigs and baskets, rollers, walking beams, radiant tubes, electric heater elements, refractory anchors, hoods, flues, grates, expansion bellows.
    Petrochemical and refinery tube hangers.
