| Titanium Plate Specification | MSRR, AMS, BS, ASTM B265 / ASME SB265 |
|---|
| ASTM B265 Titanium Sheet | - ASTM B265 Ti Grade 1 Sheet
- ASTM B265 Ti Grade 2 Sheet
- ASTM B265 Ti Grade 3 Sheet
- ASTM B265 Ti Grade 4 Sheet
- ASTM B265 Ti Grade 5 Sheet
- ASTM B265 Ti Grade 6 Sheet
- ASTM B265 Ti Grade 7 Sheet
- ASTM B265 Ti Grade 9 Sheet
- ASTM B265 Ti Grade 11 Sheet
- ASTM B265 Ti Grade 12 Sheet
- 6-2-4-2 Ti Sheet
|
|---|
| ASTM B265 Titanium plate | - ASTM B265 Ti Grade 1 Plate
- ASTM B265 Ti Grade 2 Plate
- ASTM B265 Ti Grade 3 Plate
- ASTM B265 Ti Grade 4 Plate
- ASTM B265 Ti Grade 5 Plate
- ASTM B265 Ti Grade 6 Plate
- ASTM B265 Ti Grade 7 Plate
- ASTM B265 Ti Grade 9 Plate
- ASTM B265 Ti Grade 11 Plate
- ASTM B265 Ti Grade 12 Plate
- 6-2-4-2 Ti Plate
|
|---|
| Titanium Plate Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x
3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm,
1500 mm x 3000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", Cut to
size available |
|---|
| Titanium Foil Sheet Thickness | 0.1mm to 100 mm Thk |
|---|
| Titanium Plate Width | 10-2500mm |
|---|
| Titanium Sheet AMS | AMS 4901, AMS 4902, AMS 4911, AMS 4900 |
|---|
| Titanium Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
|---|
| Temper | Annealed |
|---|
| Condition | Polished on both sides |
|---|
| Titanium Plate Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8),
SATIN (Met with Plastic Coated) |
|---|
| Titanium Plate Stock in form of | Titanium Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim
Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling
Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled,
annealed, soft annealed, descaled, sheared, tread plate, Checker
Plate |
|---|
| High Quality Titanium Sheet | - Huge Stock, Timely delivery
- Raw Materials Certificate
- EN 10204/3.1B
- 100% Radiography Test Report
- High special strength, high melt point
- Third Party Inspection Report, etc
- Excellent corrosive resistance, good thermal resistance
- Customer support after-sales service
- Strict Control from Raw Material to Finished Titanium Plate
|
|---|
| Titanium profiling | To provide a full profiling service we use numerous profiling
methods including: - Plasma Plate Cutting
- Laser Plate Cutting
- Oxy-propane Flame Cutting
|
|---|
| Specialized in | - Titanium Sheet: material under 3/16" [5.00 mm] in thickness and 24"
[600 mm] and over in width
- Titanium Plate: material 3/16" [5.00 mm] and over in thickness and
over 10" [250 mm] in width
- Titanium Strip: cold-rolled material under 3/16" [5.00 mm] in
thickness and under 24" [600 mm] in width
- Titanium Clad plate: Titanium Clad plate is a composite steel plate
made by bonding Titanium plate, etc.
- Free Quote, Inquiry answered within 24 hours
|
|---|
