Nickel Alloy Plate Sheet Hastelloy C276 UNS N10276 Plate 12206000mm 15006000mm

Ask Lasest Price
Brand Name :	DELTA
Model Number :	hastelloy C276
Certification :	ISO
Price :	40-45 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

Nickel Alloy Plate Sheet Hastelloy C276 UNS N10276 Plate 12206000mm 15006000mm

Nickel Alloy Plate Sheet Hastelloy C276 UNS N10276 Plate 1220*6000mm 1500*6000mm

Introduce of Hastelloy C276 Nickel Alloy

Hastelloy C-276 Alloy has excellent resistance to a wide variety of chemical process environments, including strong oxidizers such as ferric and cupric chlorides, hot contaminated media (organic and inorganic), chlorine, formic and acetic acids, acetic anhydride, and seawater and brine solutions. It is used in flue gas desulfurization systems because of its excellent resistance to sulfur compounds and chloride ions encounted in most scrubbers. C-276 alloy has excellent resistance to pitting and to stress-corrosion cracking. It is also one of the few materials that withstands the corrosive effects of wet chlorine gas, hypochlorite, and chlorine dioxide.

Products Specification

Type		Nickel Alloy Sheet/Plate
Thickness		1.0-20.0mm
Length		2000mm 2438mm 6000mm
Width		1000mm,1219mm,1500mm
Standard		ASTM,AISI,JIS,DIN,EN
Application		Construction,Ship,Boiler,Machinery,etc
Certification		ISO,SGS,TUV
Technique		Cold Rolled/Hot Rolled
Edge		Mill Edge/ Silt Edge
Grade		Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc
		Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC
		Incoloy: Incoloy 800/800H/800HT/825/925/926;etc
		GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc
		Monel: Monel 400/K500/R405,etc
		Nitronic 40/50/60/75/80A/90/A263 ;etc
Specification		Wire: 0.01-10mm /Strip: 0.055.0-5.0250mm /Bar: φ4-50mm;Length 2000-5000mm /Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm /Sheet: δ1.0-20.0mm;Width 1000-1500mm;Length 2000-6000mm
Cutting Type		Laser cutting;water-jet cutting;flame cutting

Hastelloy C276 Plate /Sheet Thickness

Cold rolled Hastelloy C276 ASTM B575 thin Plates	1.0-3.0mmmm
Hot rolled ASTM B575 C276 Alloy medium Plates	4-20mm
Hot rolled ASTM B575 UNS N10276 thick Plates	20-60mm
Hot rolled Alloy C276 extra thick Plates	60-115mm

2.4819 Alloy C 276 Plate equivalent

	Europe	America	Japan	Russia	Europe	Russia
STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Alloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760

Hastelloy Alloy C276 sheet stock

Explore a wide stock of hastelloy c276 material in the form of Sheet, Plate, Coil, Strip, Circles and Foil with an online updated Price list. Aslo Check Hastelloy c276 price per KG in India and Hastelloy C276 Lining plate Size chart

2.4819 Hastelloy C-276 Polished Plate	C276 Hastelloy Checkered Plate
Hastelloy C276 SB575 Foil	2.4819 Alloy C276 Embossed Plate
Alloy C276 ASTM B575 Plate	Hastelloy UNS N10276 Flat Sheet
2.4819 Hastelloy C-276 Sheet	C276 Alloy Quarto Plate
DIN 2.4819 C-276 Foil Rolls	ASTM B575 Expanded Sheet
Hastelloy C276 Coil	ASME SB575 Bbq Plate
2.4819 Alloy C 276 10mm Plate	Hastelloy C276 Alloy Plasma Cutting Plate
Hastelloy C276 N10276 Hot Rolled Sheet	2.4819 Hastelloy C-276 Tisco Plate
C276 Alloy Slitting Coils	2.4819 Alloy C 276 Design Sheet
ASTM B575 C276 Hastelloy Clad Plate	SB 575 Hastelloy C276 Floor Sheet
ASTM B575 N10276 Alloy C276 Hastelloy Cold Rolled Plate	ASTM B575 UNS N10276 Hastelloy C276 Patterned Sheet
C276 Alloy Chequered Plate	Hastelloy Alloy C276 Shims
Alloy C276 2b Finish Sheet	SB 575 Hastelloy C276 Corrugated Sheet
ASTM B575 C276 Hastelloy Sheet No 4 Finish	Hastelloy C276 Checker Plate
Hastelloy C276 N10276 Plate Mirror Finish	2.4819 Alloy C276 Perforated Plate
C-276 UNS N10276 Cold Rolled Sheet	C276 SB575 Tread Plate
2.4819 Alloy C 276 Perforated Sheet	Alloy C276 N10276 Shim Stock
UNS N10276 Chequered Plate	C-276 UNS N10276 Hairline Sheet
2.4819 Alloy C276 Flat Strip	Hastelloy C276 ASTM B575 Thin Plate
Hastelloy C-276 UNS N10276 Plate Brushed Finish	UNS N10276 Laser Cut Plate
C276 ASTM B575 Strips	ASTM B575 N10276 Alloy C276 Hastelloy Custom Cut Plate
SB 575 Hastelloy C276 Shim Sheets	Hastelloy C276 N10276 1/4 Inch Plate
ASTM B575 UNS N10276 Hastelloy C276 Shim Sheet	Alloy C276 Precision Strip
Alloy C276 Hot Rolled Plate	ASTM B575 C276 Diamond Plate
ASTM B575 UNS N10276 Hastelloy C276 Sheet Mirror Finish	ASTM B575 C276 Rolls Sheet
Alloy C276 Sheet Brushed Finish	ASTM B575 UNS N10276 Hastelloy C276 Chequer Plate
ASTM B575 N10276 Alloy C276 Hastelloy Sheet Hairline Finish	Alloy C276 B. Q. Profile
C276 Hastelloy Plate 2b Finish	ASTM B575 N10276 Alloy C276 Hastelloy Etching Sheet
2.4819 Alloy C276 Plate Mill Finish	C276 Hastelloy Rolling Plate

Hastelloy C276 ASTM B575 chemical composition

Hastelloy C276	Analysis
Ni	Bal
Mo	15 – 17
Cr	14.5 – 16.5
Fe	4 – 7
W	3 – 4.5
Co	2.5 max
Mn	1.0 max
C	0.01 max
v	0.35 max
P	0.04 max
S	0.03 max
Si	0.08 max

UNS N10276 Plates mechanical properties

Density	8.89 g/cm3
Melting Range	1370 °C (2500 °F)
Tensile Strength	Psi – 1,15,000 MPa – 790
Yield Strength (0.2%Offset)	Psi – 52,000 MPa – 355
Elongation	40 %

Nickel Alloy Plate Sheet Hastelloy C276 UNS N10276 Plate 1220*6000mm 1500*6000mm
