ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers

    Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers
    • Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers
    • Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers
    • Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers
    • Buy cheap ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates from wholesalers

    ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates

    Ask Lasest Price
    Brand Name : TISCO
    Model Number : 2205 / 1.4462 / UNS S32205 / UNS S31803
    Certification : ISO
    Price : 2500-3500 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 1 Ton
    • Product Details
    • Company Profile

    ISO Certificate Duplex 2205 Stainless Steel Plate UNS S31803 S32205 EN 1.4462 Plates

    Duplex Stainless Steel Sheet Duplex Stainless Steel 2205 0.5 - 40.0mm Cold Rolled & Hot Rolled


    Products Specification


    Products Nameduplex stainless steel plate
    Grade2205 / S31803 / S32205 / 1.4462
    ThicknessCold Rolled 0.6 - 3.0mm , Hot Rolled 3.0 - 80.0mm
    Width1000mm 1219mm 1500mm 1800mm 2000mm
    Standard Size1000*2000mm 1219*2438mm 1500*6000mm 1800*6000mm 2000*6000mm or cutting as request
    BrandPOSCO TISCO BAOSTEEL JISCO ESS
    Other Grade304 316L 309S 310S 321 347 2507 904L 254SMO.etc
    ServiceCutting

    Standard Size of our 2205 Duplex Stainless Steel Plate in Stock


    Cold Rolled 2205 duplex stainless steel sheet
    0.4*1219*2438mm0.5*1219*2438mm0.6*1219*2438mm0.8*1219*2438mm1.0*1219*2438mm
    1.2*1219*2438mm1.5*1219*2438mm2.0*1219*2438mm2.5*1219*2438mm3.0*1219*2438mm
    Hot Rolled 2205 duplex stainless steel plate
    3.0*1500*6000mm4.0*1500*6000mm5.0*1500*6000mm6.0*1500*6000mm8.0*1500*6000mm
    10.0*1500*6000mm12.0*1500*6000mm14.0*1500*6000mm16.0*1500*6000mm20.0*1500*6000mm
    6.0*2000*6000mm8.0*2000*6000mm10.0*2000*6000mm12.0*2000*6000mm14.0*2000*6000mm
    16.0*2000*6000mm

    2205 duplex stainless steel 2205

    Duplex 2205 stainless steel (both ferritic and austenitic) is used extensively in applications that require good corrosion resistance and strength. The S31803 grade stainless steel has undergone a number of modifications resulting in UNS S32205, and was endorsed in the year 1996. This grade offers higher resistance to corrosion.

    At temperatures above 300°C, the brittle micro-constituents of this grade undergo precipitation, and at temperatures below -50°C the micro-constituents undergo ductile-to-brittle transition; hence this grade of stainless steel is not suitable for use at these temperatures.


    Duplex 2205, also known as UNS S32205, is a nitrogen-enhanced stainless steel. Users choose Duplex 2205 for its excellent corrosion resistance along with its high strength. It is important to note that Duplex 2205, offers much higher levels of corrosion resistance than most other austenitic stainless steels. Other benefits include:

    • High resistance to pitting and crevice corrosion
    • Excellent in most caustic environments
    • Good weldability

    Compositional ranges for grade 2205 duplex stainless steel.


    GradeCMnSiPSCrMoNiN
    2205 (S31803)

    Min

    Max

    -

    0.030

    -

    2.00

    -

    1.00

    -

    0.030

    -

    0.020

    21.0

    23.0

    2.5

    3.5

    4.5

    6.5

    0.08

    0.20

    2205 (S32205)

    Min

    Max

    -

    0.030

    -

    2.00

    -

    1.00

    -

    0.030

    -

    0.020

    22.0

    23.0

    3.0

    3.5

    4.5

    6.5

    0.14

    0.20

    Mechanical Properties of duplex 2205 stainless steel

    The typical mechanical properties of grade 2205 stainless steels are listed in the table below. Grade S31803 has similar mechanical properties to that of S32205.

    GradeTensile Str
    (MPa) min
    Yield Strength
    0.2% Proof
    (MPa) min
    Elongation
    (% in 50mm) min
    Hardness
    Rockwell C (HR C)Brinell (HB)
    22056214482531 max293 max

    Grade 2205 Specification Comparison

    Table 4 provides the grade comparison for 2205 stainless steels. The values are a comparison of functionally similar materials. Exact equivalents may be obtained from the original specifications.

    GradeUNSENBSJISSS
    2205S31803/S322051.4462X2CrNiMoN22-5-3318S13SUS329J3L2377
    Application of duplex 2205 stainless steel

    This unique mix of materials makes Duplex 2205 the right choice for a number of different critical applications in a range of industries, including:

    • Chemical processing, transport, and storage
    • Marine and Land cargo tanks
    • Biofuel production
    • Food processing
    • Pulp and Paper manufacturing
    • Oil and gas exploration and processing
    • Waste management
    • High chloride environments

    About Our Company

    1. Our company is a large company integrating wholesale of duplex steel and material processing.

    2. Domestic partners: TISCO, BAOSTEEL, POSCO, JISCO, LISCO, TSINGSHAN, ESS.etc

    3. Foreign Partners: COLUMBUS ,NAS,OUTOKUMPU,Nippon metal,NipponYakinKogyoNSC. etc.

    4. Our duplex steel main products: 2205, 2507 duplex stainless steel, 254SMO austenitic stainless steel

    5. The products are mainly used in: ship washing tower equipment, roadbed desulfurization tower, cooling tower, and many other industries.

    6. Processing equipment: Imported from Italy, hot rolling machine, strip machine, high level water cutting machine, plasma cutting machine, large CNC milling machine, boring machine and many other imported processing equipment.


    Logistic and Packing Informations

    Packing Informations:
    Packing Method: wooden pallets and waterproof paper packing
    Packing Size:1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm or as request
    Packing Weight: about 2 - 3 Tons each packing

    Container loading:
    20ft container: 2.2mm width * 2.2m height * 5.8m Length , each container loading 25 Tons
    40ft container:2.2mm width * 2.2m height * 11.6m Length , each container loading 25 Tons
